Orava Radio RP-141 R

Lees hieronder de 📖 handleiding in het Nederlandse voor Orava RP-141 R (10 pagina's) in de categorie Radio. Deze handleiding was nuttig voor 27 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/10

Portable FM radio receiver

with USB/SD/microSD

RP-141 R

Instruction manual

2EN

Safety instructions

Safety

• If any object enters the device, disconnect the device from the power supply and have the device

checked by an authorized service center before using it again.

• The unit is live when the AC adapter (not supplied) is plugged into an electrical socket, even if the unit

itself is turned off.

• This device is intended for use by children 8 years of age and older if they are supervised or instructed

in the safe use of the device and if they understand the dangers involved. Children must not perform

cleaning and user maintenance unless they are older than 8 years under supervision. Keep the device

and the cord out of the reach of children if they are under 8 years old.

• This device may be operated by persons with reduced physical, sensory or mental capabilities, or lack

of experience, provided they have been given supervision or instruction concerning use of the device

in a safe manner and by understanding the hazards involved. Children must not play with the device.

Location

• Do not place the device in an enclosed space, such as a bookcase or built-in cabinet.

• Make sure there is enough space around the air circulation device to prevent the device from

overheating.

• Do not place the device on a soft surface (blanket, tarpaulin, etc.) or near materials (curtains,

draperies) that could impede air circulation by blocking the ventilation holes.

• Do not place the unit near heat sources such as radiators, or in a place subject to direct sunlight,

excessive dust, mechanical vibration or shock.

• Do not place the device on an inclined surface. The device is designed for operation in a horizontal

position.

• Do not place the device near devices with strong magnets, such as microwave ovens or large

speakers.

• Do not place heavy objects on the device.

• If the unit is brought directly from a cold to a warm location, moisture may condense inside the unit

and cause damage to the optical mechanism. When switching on the device for the ﬁrst time or after

moving the device from a cold environment to a warm one, wait approx. 30 minutes before operating

the device again until the moisture generated in the device has evaporated.

Power supplies

Power supply

1 Connect a suitable 5 V/500 mA adapter cable (not supplied) to the 5 V DC (mini USB)

jack on the unit, then plug the AC adapter into an electrical socket.

2 Use the ON/OFF switch to turn on the unit and select the desired audio source.

Warning!

Use only a suitable AC adapter with the speciﬁed parameters, a suitable terminal and a 5 V

DC output voltage.

The device is powered on while the AC adapter is plugged in, even if the device itself is

turned off.

3EN

Battery powered

The device is powered by the supplied battery (3.7 V - 800 mA) and we recommend using

this power supply.

1 Open the battery cover on the back of the device.

2 Insert the supplied battery pack according to the correct polarity + and -.

3 Close the battery cover.

4 If the battery is empty, charge it by connecting the device with the supplied USB charging

cable to the USB connector on the PC, or connect a suitable AC adapter (not supplied).

Powering/charging the battery from a PC

The device can be powered (charged by its battery) from a switched on PC via the supplied

USB charging cable.

If necessary, connect the large USB connector to the USB connector on the turned on PC

and the other connector to the DC 5 V connector on the device.

The battery charges for about 2-3 hours and the device can operate on the battery for

about 3-5 hours.

Notes

• Do not insert any other objects into the battery compartment.

• If you will not be using the device for a long time, remove the battery.

Control elements

Elements on the device

Product specificaties

Merk:	Orava
Categorie:	Radio
Model:	RP-141 R
Kleur van het product:	Black, Red
Ingebouwd display:	Ja
Gewicht:	220 g
Breedte:	116 mm
Diepte:	34 mm
Hoogte:	72 mm
Stroombron:	Batterij/Accu
Capaciteit van de accu/batterij:	800 mAh
Ondersteund audioformaat:	MP3
USB-connectortype:	Mini-USB
Type aansluitplug:	3,5 mm
Meegeleverde kabels:	USB
Geïntegreerde geheugenkaartlezer:	Ja
Compatibele geheugenkaarten:	MicroSD (TransFlash)
Accu/Batterij voltage:	3.7 V
Aantal USB 2.0-poorten:	1
Ingebouwde luidsprekers:	Ja
Gemiddeld vermogen:	3 W
Aantal ingebouwde luidsprekers:	1
Volumeregeling:	Draaiknop
Hoofdtelefoonuitgangen:	1
Soort tuner:	Analoog
Soort antenne:	Extern
USB-aansluiting:	Ja
USB oplaadpoort:	Ja
MP3 afspelen:	Ja
Verpakkingsinhoud:	Instruction manual (1 pc)\nUSB power cable (1 pc)\nRechargeable battery 3.7 V/800mAh(1pc)
Ondersteunde frequentiebanden:	FM
Radio:	Draagbaar
Luidspreker soort:	1-weg
Projectie:	Nee
FM-band:	70 - 108 MHz
Type beeldscherm:	LED
Type batterij:	Ingebouwde accu
