8 Button IP PoE Control Panel Installation & Operation Manual
© MuxLab Inc. 20 A / SE A Page23 94-001000- -001000- 1/ 21
8 Button IP PoE Control Panel
Installation and Operation Manual
500816- - IP V2
8 Button IP PoE Control Panel Installation & Operation Manual
© MuxLab Inc. 20 A / SE A Page23 94-001000- -001000- 2/ 21
Intr
Intr
Intr
IntrIntroduction
oduction
oduction
oductionoduction
The 8 Button IP PoE Control Panel (Model: 500816 is a versatile wall or -IP-V2)
table top mounted control panel for MuxLab AV over IP devices, select Matrix -
Switches, and third party products. Each button is programmable. The unit supports
one (1) Ethernet port (for TCP/IP, Telnet, HTTP and UDP), two (2 232 ports, one (1) ) RS-
Infrared port, and two (2) Relay ports, for control of end devices. The 8 Button IP PoE
Control Panel can control MuxLab products including MuxLab’s AV over IP system via
the 500812 ProDigital Network Controller, MuxLab TCP/IP, Telnet and 232 ’s RS-
managed Matrix Switches, as well as third party devices such as projectors and
projector screens, displays, AV sources and other similar devices.
The 500816 supports a web interface, allowing it to be configured and -IP-V2
managed via a browser. The web interface allows the unit keys to be programmed
individually, supports IR learning and unit configuration.
P
P
P
PPanel
anel
anel
anelanel Description
Description
Description
Description Description
Front panel view:
All buttons can be programed to control each TCP/IP, Telnet, HTTP, UDP, 232, IR, RS-
and Relay controllable end device Each key supports a removable clear plastic cover, .
allowing a label to be inserted to reflect the programming of each button.
8 Button IP PoE Control Panel Installation & Operation Manual
© MuxLab Inc. 20 A / SE A Page23 94-001000- -001000- 3/ 21
Rear panel view:
1. Power: DC Power Input supporting 24VDC (12VDC@1A is recommended)12-
2. Relay #1: An electrically operated switch
3. IR output power jump jumper left 2 pin for 5V, or right 2 pin for 10V. er: s s
4. Relay #2: An electrically operated switch
5. IR: Infrared radiation digital data output
6. Rs232 #2: RS 232 data out-put
7. Rs232 #1: RS 232 data output-
8. LAN (PoE): LAN port with PoE (PD) power for b interface controlwe
Top panel view:
1. IR reader: Learning IR sensor, supporting a frequency of 38KHz
