Pagina 1/2
Media Functions
˙ Fn + F1: Media Player
˙ Fn + F2: Volume Down
˙ Fn + F3: Volume Up
˙ Fn + F4: Mute
˙ Fn + F5: Previous Track
˙ Fn + F6: Next Track
˙ Fn + F7: Play/Pause
˙ Fn + F8: Stop
˙ Fn + F9: Default Browser / Homepage
˙ Fn + F10: Default E-mail App
˙ Fn + F11: My Computer
Overview
˙ Sleep Mode: Activates when no action after 5 minutes; wake up by pressing any key
˙ Battery Low Indicator: Flashes continuously to replace batteries
To re-pair the connection
˙ Connect the Wireless USB Dongle to a USB port
˙ Turn on the keyboard by inserting batteries
˙ Press and hold ESC + K near the dongle within 15 seconds and repeat until paired
Paired: Battery low indicator flashes for 8 seconds, then off
Not paired: Battery low indicator glows for 5 seconds
※ For more information, please visit MSI official website.
Introductions to Function Keys
※ This wireless keyboard uses AAA batteries.
※ Rated Voltage / Current: 3.0V 2mA; Maximum Operating Temperature: 40 °C
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modification not expressly approved by the party responsible for compliance could
void the user's authority to operate the device. Where shielded interface cables have been provided
with the product or specified additional components or accessories elsewhere defined to be used
with the installation of the product, they must be used in order to ensure compliance with FCC
regulations.
NCC警語
取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、加大功率或
變更原設計之特性及功能。低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾
現象時，應立即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理法規定作業之
無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
CE宣告：Hereby, MSI declares that the radio equipment type MS-8ZA4 is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is available
at the following internet address: www.msi.com
BSMI Statement
1. 置換可能影響安全防護的錯誤形式的電池(例: 在某些鋰電池類型的情形下);
2. 電池丟入火焰或烤箱中, 或將電池作可能導致爆炸的機械擠壓或切割;
3. 電池至於可能導致爆炸或可燃性異體或氣體洩漏的高溫環境中; 且
4. 電池承受可能導致爆炸或可燃性異體或氣體洩漏的極度低氣壓。
Specifications
Keyboard Input / 輸入：DC 3V / 2mA
Transceiver Input / 輸入：DC 5V / 30mA
Frequency Range： 2.40385 – 2.47985 GHz
Keyboard output power < 0 dBm
Transceiver outpower < 0 dBm
FCC
Wireless Keyboard 2.4GHz Dongle
NCC
IC
I4L-MS-8ZA4 I4L-WD01
3715A-MS-8ZA4 3715A-I4L-WD01
CCAH24LP6870T5 CCAH24LP7180T1
상호 : (주) 엠에스아이코리아
제품명 : 특정소출력 무선기기
(무선데이터통신시스템용 무선기기)
모델명 : MS-8ZA4
제조년월 : 2024년
제조자 및 제조국가 : MSI/중국
R-R-MSI-MS-8ZA4
상호 : (주) 엠에스아이코리아
제품명 : USB Wireless Dongle
모델명 : WD01
제조년월 : 2024 년
제조자 및 제조국가 : MSI/중국
R-R-MSI-WD01
Mise en garde
1.Remplacement de la batterie par un type incorrect pouvant contourner une protection (par exemple,
dans le cas de certains types de batteries au lithium) ;
2.Élimination d'une batterie par incinération ou dans un four chaud, ou écrasement ou découpe
mécanique d'une batterie, pouvant entraîner une explosion ;
3.Laisser une batterie dans un environnement à température extrêmement élevée, pouvant entraîner
une explosion ou la fuite de liquide ou de gaz inflammable ;
4.Exposer une batterie à une pression atmosphérique extrêmement basse, pouvant entraîner une
explosion ou la fuite de liquide ou de gaz inflammable.
5.Les températures extrêmes élevées ou basses auxquelles une BATTERIE peut être soumise
pendant son utilisation, son stockage ou son transport ;
6.low air pressure at high altitude.
ISED Compliance Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following
two conditions: (1)This device may not cause interference.(2)This device must accept any
interference, including interference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
’Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :(1)L’appareil ne doit
pas produire de brouillage; (2)L’appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d’en compromettre le fonctionnement.
CAN ICES(B)/NBM(B)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la claseee B est conforme a la norme ICES-003 du Canada.
Caution
1. Replacement of battery with an incorrect type that can defeat a safeguard (for example, in the
case of some lithium battery types);
2. Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery,
that can result in an explosion;
3. Leaving a battery in an extremely high temperature surrounding environment that can result
in an explosion or the leakage of flammable liquid or gas;
4. A battery subjected to extremely low air pressure that may result in an explosion or the
leakage of flammable liquid or gas.
5. High or low extreme temperatures that a BATTERY can be subjected to during use, storage or
transportation; and
6. Low air pressure at high altitude.
10
产品中有毒有害物质或元素的名称及含量
O O O O O印刷电路板组件* O
O O O O O外壳及附件 O
有害物质
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
（Cr(VI)）
部件名称
○：表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T11363 2006 标准 规定的限量要求以下。
×：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363 2006 标准规定的限量要求。
* 印刷电路板组件: 包括印刷电路板及其零部件、电子元器件等。
表中标有”X”的所有部件都符合欧盟 ROHS 法规。
在中华人民共和国境内销售的电子信息产品必须标示此标志，标志内的数字表示在正常的使用
状态下的产品环保使用年限。
O O O O OO
O O O O OO
O O O O OO
)
多溴聯苯
Polyb ominatedr
biphenyls
(PBB)
多溴二苯醚
Polyb ominatedr
diphenyl the e rs
(PBDE)
鉛Lead
(Pb)
汞Mer rycu
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
ch omiumr
(Cr+6
O O O O O印刷電路板 O
O O O O O上/中/下蓋 O
O O O O O按鍵 O
O O O O O導光柱 O
O O O O OUS 連接線B O
螺絲
腳墊
外箱貼紙
備考 3. "-
備考 1. 超出 0.1 t % 及 超出 0.01 w % 係指限用物質之百分比含量超出百分比含量基準值。" w " " t "
Not "Exc w " a " xc t " cates tha h pe ntag nten of thee 1: eeding 0.1 t% nd e eeding 0.01 w % indi t t e rce e co t
r str r r rce r .e icted substance exc dsee the efe ence pe ntage value of p esence condition
備考 2. ○ 係指該項限用物質之百分比含量未超出百分比含量基準值。" "
Not cates tha h pe nte 2: "O" indi t t e rce age nten of th e icted substanc does o c d the co t e r str e n t ex ee
pe ntagrce e e e of efe enc r r valu of p esence r .
係指該項限用物質為排除項目。"
Not " h "-" cates tha h e icted substance espo s to th xemptione 3 : T e indi t t e r str corr nd e e .
限用物質及其化學符號
R str e icted substances and its chemical symbols
設備名稱 t ：無線鍵盤Equipmen name
型號 (型式) Type designation (Type)：MS-8ZA4
單元 U tni
媒體功能
˙ Fn + F1: 媒體播放器
˙ Fn + F2: 音量減小
˙ Fn + F3: 音量增加
˙ Fn + F4: 靜音
˙ Fn + F5: 上一曲
˙ Fn + F6: 下一曲
˙ Fn + F7: 播放/暫停
˙ Fn + F8: 停止
˙ Fn + F9: 預設瀏覽器 / 首頁
˙ Fn + F10: 預設電子郵件應用程式
˙ Fn + F11: 我的電腦
※ 如欲獲得更多產品訊息，請至 MSI 官方網站。
功能鍵介紹
概述
˙ 睡眠模式：在5分鐘無操作後啟動；按任意鍵可喚醒
˙ 電池低電量指示燈：持續閃爍表示需更換電池
重新配對連接
˙ 將無線 USB 接收器連接到USB端口
˙ 放入電池啟用鍵盤
˙ 15 秒內，於接收器附近按住 ESC + K 15 秒，重複直到配對成功
- 已配對：電池低電量指示燈閃爍 8 秒後熄滅
- 未配對：電池低電量指示燈亮起 5 秒
※ 此無線鍵盤使用 AAA 電池
※ 額定電壓 / 電流：3.0V 2mA; 最高作業溫度：40 °C
繁體中文English
Model: MS-8ZA4
FORGE K200 WIRELESS
KEYBOARD
QUICK START GUIDE
Introductions
Overview
1. Indicator LED
2. Left Button
3. Right Button
4. Scroll Wheel
5. Side Button 1
(Default Setting: Next Page)
6. Side Button 2
(Default Setting: Previous Page)
7. Switch On/Off
8. Optical Sensor
9. Battery Compartment (AAA Battery)
10. Wireless USB Dongle
3 DPI Level Presets
• Level 1: 1000 DPI • Level 2: 1200 DPI (Default) • Level 3: 1600 DPI
Functions
• To adjust DPI: Press and hold Left Button + Scroll Wheel + Right
Button for 5 seconds
- Indicator LED flashes once: 1000 DPI
- Indicator LED flashes twice: 1200 DPI
- Indicator LED flashes three times: 1600 DPI
• Sleep Mode: Activates if the mouse is idle for 8 minutes and Optical
Sensor shuts off to conserve battery life; wake up by pressing any
button
• When Battery Low: Indicator LED flashes slowly
Re-pairing the connection
• Connect the Wireless USB Dongle to a USB port on your PC
• Turn on the mouse with the switch at the bottom
• Press and hold Right Button + Scroll Wheel for 15 seconds while
holding the mouse close to the Wireless USB dongle. Repeat this
process if necessary
- Paired: Indicator LED flashes for 8 seconds, then turns off
- Not paired: Indicator LED glows for 5 seconds
This mouse is recommended for use with a fabric mouse pad.
※ Rated Voltage / Current: 3.0V 6mA; Maximum Operating
Temperature: 40 °C
※ For more information, please visit MSI official website.
功能介紹
外觀檢視
1. 指示燈
2. 左鍵
3. 右鍵
4. 滾輪
5. 側鍵 1（預設：下一頁）
6. 側鍵 2（預設：上一頁）
7. 電源開關
8. 光學感應器
9. 電池槽（AAA 電池）
10. 無線 USB 接收器
3 段 DPI 設定
• 1 段: 1000 DPI • 2 段: 1200 DPI (預設) • 3 段: 1600 DPI
概述
• 調整 DPI：按住左按鈕 + 滾輪 + 右按鈕 5 秒
- 指示燈閃爍一次：1000 DPI
- 指示燈閃爍兩次：1200 DPI
- 指示燈閃爍三次：1600 DPI
• 睡眠模式：當滑鼠閒置8 分後啟動，為保留電量，光學感測器關閉；
按任意按鈕則可喚醒
• 電池低電量時：指示燈慢慢閃爍
重新配對連接
• 將無線 USB 接收器連接至 PC上的 USB 端口
• 開啟滑鼠底部的電源開關
• 按住右按鈕 + 滾輪約15秒內，並將滑鼠靠近無線 USB 接收器，如必要
，重複此動作直到配對成功
- 已配對：指示燈閃爍 8 秒後熄滅
- 未配對：指示燈常亮 5 秒
此款滑鼠建議搭配布質滑鼠墊使用
※ 額定電壓 / 電流：3.0V 6mA; 最高作業溫度：40 °C
※ 如欲獲得更多產品訊息，請至 MSI 官方網站。
CE宣告：Hereby, MSI declares that the radio equipment type
MS-8ZB4 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is
availableat the following internet address:
www.msi.com
BSMI Statement
1. Replacement of battery with an incorrect type that can defeat a
safeguard (for example, in the case of some lithium battery
types);
2. Disposal of a battery into fire or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an explosion;
3. Leaving a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of
flammable liquid or gas;
4. A battery subjected to extremely low air pressure that may
result in an explosion or the leakage of flammable liquid or
gas.
1. 置換可能影響安全防護的錯誤形式的電池(例: 在某些鋰電池類型
的情形下);
2. 電池丟入火焰或烤箱中, 或將電池作可能導致爆炸的機械擠壓或
切割;
3. 電池至於可能導致爆炸或可燃性異體或氣體洩漏的高溫環境中;
且
4. 電池承受可能導致爆炸或可燃性異體或氣體洩漏的極度低氣壓。
ISED Compliance Statement
CAN ICES-003(B)/NBM-003(B)
Specifications
Mouse Input / 輸入：DC 3V / 6 mA
Transceiver Input / 輸入：DC 5V / 30mA
Frequency Range： 2.40385 – 2.47985 GHz
Mouse output power < 0 dBm
Transceiver outpower < 0 dBm
FCC
Wireless Mouse 2.4GHz Dongle
NCC
IC
I4L-MS-8ZB4 I4L-WD01
3715A-MS8ZB4 3715A-WD01
CCAH24LP7070T4 CCAH24LP7180T1
상호 : (주) 엠에스아이코리아
제품명 : 특정소출력 무선기기
(무선데이터통신시스템용 무선기기)
모델명 : MS-8ZB4
제조년월 : 2024년
제조자 및 제조국가 : MSI/중국
R-R-MSI-MS-8ZB4
상호 : (주) 엠에스아이코리아
제품명 : USB Wireless Dongle
모델명 : WD01
제조년월 : 2024년
제조자 및 제조국가 : MSI/중국
R-R-MSI-WD01
This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions: (1)This device may not cause
interference.(2)This device must accept any interference, including
interference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent
appareil est conforme aux CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :(1)L’appareil ne doit pas produire de
brouillage; (2)L’appareil doit accepter tout brouillage radioélec-
trique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la claseee B est conforme a la norme
ICES-003 du Canada.
Caution
1. Replacement of battery with an incorrect type that can defeat a
safeguard (for example, in the case of some lithium battery
types);
2. Disposal of a battery into fire or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an explosion;
3. Leaving a battery in an extremely high temperature
surrounding environment that can result in an explosion or the
leakage of flammable liquid or gas;
4. A battery subjected to extremely low air pressure that may
result in an explosion or the leakage of flammable liquid or
gas.
5. High or low extreme temperatures that a BATTERY can be
subjected to during use, storage or transportation; and
6. Low air pressure at high altitude.
Mise en garde
1.Remplacement de la batterie par un type incorrect pouvant
contourner une protection (par exemple, dans le cas de
certains types de batteries au lithium) ;
2.Élimination d'une batterie par incinération ou dans un four
chaud, ou écrasement ou découpe mécanique d'une batterie,
pouvant entraîner une explosion ;
3.Laisser une batterie dans un environnement à température
extrêmement élevée, pouvant entraîner une explosion ou la
fuite de liquide ou de gaz inflammable ;
4.Exposer une batterie à une pression atmosphérique
extrêmement basse, pouvant entraîner une explosion ou la
fuite de liquide ou de gaz inflammable.
5.Les températures extrêmes élevées ou basses auxquelles une
BATTERIE peut être soumise pendant son utilisation, son
stockage ou son transport ;
6.low air pressure at high altitude.
NCC警語
取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者
均不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功
率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干
擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前述合
法通信，指依電信管理法規定作業之無線電通信。低功率射頻器材
須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾
。
—
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
多溴二苯醚
(PBDE)
多溴聯苯
(PBB)
六價鉻
(Cr+6 )
備考 1. 〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。
備考 2. 〝—〞係指該項限用物質為排除項目。
連接線
設備名稱：無線滑鼠 型號（型式）：MS-8ZB4
單元
限用物質及其化學符號
鉛
(Pb)
汞
(Hg)
O
O
O
O
鎘
(Cd)
印刷電路及
電子組件
外殼
滾輪裝置
限用物質含有情況標示聲明書 RoHS Statements
产品中有毒有害物质或元素的名称及含量
O O O O O印刷电路板组件* O
O O O O O
外壳及附件 O
有害物质
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
（Cr (VI)）
部件名称
○：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T11363 2006 标准规定的限量要求以下。
×：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T11363 2006 标准规定的限量要求。
* 印刷电路板组件: 包括印刷电路板及其零部件、电子元器件等。
表中标有 ”X”的所有部件都符合欧盟 ROHS 法规。
在中华人民共和国境内销售的电子信息产品必须标示此标志，标志内的
数字表示在正常的使用状态下的产品环保使用年限。
10
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
Any changes or modification not expressly approved by the party
responsible for compliance could void the user's authority to
operate the device. Where shielded interface cables have been
provided with the product or specified additional components or
accessories elsewhere defined to be used with the installation of
the product, they must be used in order to ensure compliance with
FCC regulations.
1
6
7
9
5
2 3
8
4
10
English 繁體中文
FORGE M200
WIRELESS MOUSE
QUICK START GUIDE
Model: MS-8ZB4

Product specificaties

Merk: MSI
Categorie: Niet gecategoriseerd
Model: FORGE K200 WIRELESS

Heb je hulp nodig?

Als je hulp nodig hebt met MSI FORGE K200 WIRELESS stel dan hieronder een vraag en andere gebruikers zullen je antwoorden


Handleiding Niet gecategoriseerd MSI

MSI

MSI STRIKE 600 Handleiding

30 Januari 2025
MSI

MSI MPG A1250GS PCIE5 Handleiding

30 Januari 2025
MSI

MSI MAG CORELIQUID A15 240 Handleiding

30 Januari 2025
MSI

MSI MPG A1000GS PCIE5 Handleiding

30 Januari 2025
MSI

MSI MEG Ai1600T PCIE5 Handleiding

30 Januari 2025
MSI

MSI MAG CORELIQUID A15 360 Handleiding

30 Januari 2025
MSI

MSI HERALD-BE Handleiding

14 Januari 2025
MSI

MSI DATAMAG 20Gbps Handleiding

14 Januari 2025
MSI

MSI GeForce GT 1030 AERO ITX 4GD4 OC Handleiding

9 Januari 2025
MSI

MSI Radeon RX 6400 AERO ITX 4G Handleiding

9 Januari 2025

Handleiding Niet gecategoriseerd

Nieuwste handleidingen voor Niet gecategoriseerd

Sunding

Sunding SD-581C Handleiding

30 Januari 2025
Viking

Viking PRONGK1 Handleiding

30 Januari 2025
Creative

Creative Sound BlasterX Katana V2X Handleiding

30 Januari 2025
XTRARM

XTRARM XTR-FS5100 Handleiding

30 Januari 2025
XTRARM

XTRARM XTR-FS5050 Handleiding

30 Januari 2025
XTRARM

XTRARM XTR-FS5110 Handleiding

30 Januari 2025
XTRARM

XTRARM XTR-FS2070 Handleiding

30 Januari 2025
Sunding

Sunding SD-589 Handleiding

30 Januari 2025
XTRARM

XTRARM XTR-FS4030 Handleiding

30 Januari 2025
Viking

Viking PROLPK1 Handleiding

30 Januari 2025
