CRS326-24S+2Q+RM

CRS326-24S-2Q+RM

CRS326-24S+2Q+RM

If you are working with substantial amount of data – like providing Internet access or maintaining a huge

data center – this is the perfect upgrade for your setup. is our ﬁrst product withCRS326-24S+2Q+RM

40 Gbps QSFP+ ports for remarkably fast and stable ﬁber connection.

Overall it has two 40 Gbps QSFP+ ports and twenty four 10 Gbps SFP+ ports, which provides total non-

blocking throughput of 320 Gbps and switching capacity of 640 Gbps with forwarding rate of 252 Mpps

with most common packets.

Our fastest switch for the most demanding setups

CRS326-24S+2Q+RM is easy to manage – it has a full size USB port for conﬁguration and dual power

supply for redundancy – no unexpected downtime, your clients and colleagues will be thankful!

You can choose between our legendary feature-packed RouterOS for booting or a simpler, but still

powerful SwOS. If you would like the ability to use routing and other Layer 3 features in your CRS, use

RouterOS.

This device is great for new or existing networks – we have developed an assortment of accessories that

will help you unleash the full potential of this switch in any setup. CRS326-24S+2Q+RM – a professional’s

choice!

CRS326-24S+2Q+RM

Product code CRS326-24S+2Q+RM

CPU QCA9531, 650 MHz

Size of RAM 64 MB

Storage 16 MB ﬂash

10/100 Ethernet ports 1

10G SFP+ ports 24

40G QSFP+ ports 2

Supported input voltage AC power supply 100 - 240 V

Redundant supply Yes

USB port USB type A

Serial port RJ45

Dimensions 443 x 200 x 44 mm

Operating temperature -20°C .. +60°C

Operating system RouterOS or SwitchOS, License level 5

Max power consumption 69 W

Speciﬁcations

Included parts

2 IEC cords Screw and feet

kit (K10)

Rack ears

CRS326-24S+2Q+RM

QCA9531 CRS326-24S+2Q RouterOS v6.45

Mode Conﬁguration

1518 byte 512 byte 64 byte

kpps Mbps kpps Mbps kpps Mbps

Bridging none (fast path) 37,3 453,0 82,2 336,7 184,3 94,4

Bridging 25 bridge ﬁlter rules 450,5 47,6 195,0 50,2 25,737,1

Routing none (fast path) 37,6 456,6 69,0 282,6 94,1 48,2

Routing 25 simple queues 37,2 451,8 56,5 231,4 66,3 33,9

Routing 25 ip ﬁlter rules 26,7 324,2 29,4 120,4 30,9 15,8

QCA9531 CRS326-24S+2Q RouterOS v6.45

Mode Conﬁguration

1518 byte 512 byte 64 byte

kpps Gbps kpps Gbps kpps Gbps

Switching Non blocking Layer

2 throughput 26007,8 315,838 75187,5 307,968 240652 123,214

Switching Non blocking Layer

2 capacity 26007,8 631,677 75187,5 615,936 240652 246,428

Switching Non blocking Layer 1

throughput 26007,8 320 75187,5 320 240652 161,718

Switching Non blocking Layer 1

capacity 26007,8 640 75187,5 640 240652 323,436

CPU Layer 3 performance results

Switching test results

Like other CRS products, comes with a decent built-in CPU, that can utilize all RouterOS features, but with some CRS326-24S+2Q+RM

performance restrictions (indicated in table below).

Product specificaties

Merk:	Mikrotik
Categorie:	Niet gecategoriseerd
Model:	CRS326-24S+2Q+RM
Kleur van het product:	Wit
Breedte:	443 mm
Diepte:	183 mm
Hoogte:	44 mm
LED-indicatoren:	Ja
Frequentie van processor:	650 MHz
Vormfactor:	1U
Meegeleverde kabels:	AC
Aantal USB 2.0-poorten:	1
Vermogensverbruik (max):	69 W
Intern geheugen:	64 MB
Type processor:	Ja
Reset button:	Ja
Rack-montage:	Ja
Redundante voeding:	Ja
Flash memory:	16 MB
Power over Ethernet (PoE):	Nee
Type geheugen:	RAM
Switchingcapaciteit:	640 Gbit/s
MAC-adrestabel:	- entries
10G support:	Ja
Switch type:	Managed
Console port:	RJ-45
Netstekker:	AC-in-aansluiting
Switch-laag:	L3
Throughput:	320 Mpps
AC-ingangsspanning:	100 - 240 V
Bedrijfstemperatuur (T-T):	-20 - 60 °C
Code geharmoniseerd systeem (HS):	85176990
Aantal moduleslots SPF+:	24
Verzending snelheid:	252 Mpps
Rekbevestigingspakket:	Ja
Aantal GSFP+-moduleslots:	2
