Errata

DS80000906G - 1

PIC32CM LE00/LS00/LS60 Family Errata

The PIC32CM LE00/LS00/LS60 family of devices that you have received conform functionally to the current

Device Data Sheet (DS60001615), except for the anomalies described in this document.

The silicon issues discussed in the following pages are for silicon revisions with the Device and Revision IDs

listed in the following tables. The silicon issues are summarized in the Silicon Issues Summary.

The errata described in this document will be addressed in future revisions of the PIC32CM LE00/LS00/LS60

family silicon.

Note: This document summarizes all silicon errata issues from all revisions of silicon, previous as well as

current.

Data Sheet and corrections (if applicable) are located in Data Sheet following theclarications Clarications,

discussion of silicon issues.

Table 1. PIC32CM LE00 Family Silicon Device Idencaon

Devices

Device ID

(DID[31:0])

Silicon Revision ID

(DID.REVISION[3:0])

A0 B0

PIC32CM5164LE00100 0x20850X00 0x0 0x1

PIC32CM5164LE00064 0x20850X01 0x0 0x1

PIC32CM5164LE00048 0x20850X02 0x0 0x1

PIC32CM2532LE00100 0x20850X04 0x0 0x1

PIC32CM2532LE00064 0x20850X05 0x0 0x1

PIC32CM2532LE00048 0x20850X06 0x0 0x1

Table 2. PIC32CM LS00 Family Silicon Device Idencaon

Devices

Device ID

(DID[31:0])

Silicon Revision ID

(DID.REVISION[3:0])

A0 B0

PIC32CM5164LS00100 0x20860X00 0x0 0x1

PIC32CM5164LS00064 0x20860X01 0x0 0x1

PIC32CM5164LS00048 0x20860X02 0x0 0x1

PIC32CM2532LS00100 0x20860X04 0x0 0x1

PIC32CM2532LS00064 0x20860X05 0x0 0x1

PIC32CM2532LS00048 0x20860X06 0x0 0x1

Table 3. PIC32CM LS60 Family Silicon Device Idencaon

Devices

Device ID

(DID[31:0])

Silicon Revision ID

(DID.REVISION[3:0])

A0 B0

PIC32CM5164LS60100 0x20870X00 0x0 0x1

PIC32CM5164LS60064 0x20870X01 0x0 0x1

Silicon Errata and Data Sheet Claricaons

PIC32CM LE00/LS00/LS60

Errata

DS80000906G - 2

...........continued

Devices

Device ID

(DID[31:0])

Silicon Revision ID

(DID.REVISION[3:0])

A0 B0

PIC32CM5164LS60048 0x20870X02 0x0 0x1

Note: Refer to the “Device Service Unit” chapter in the current Device Data Sheet (DS60001615) for detailed

information on Device and Revision IDs for your device.Identication specic

PIC32CM LE00/LS00/LS60

Errata

DS80000906G - 3
