Atmel-8961A-CPLD-ATF15xx-DK3-U-Development-Kit-UserGuide_072015

Introduction

The Atmel® ATF15xx-DK3-U Complex Programmable Logic Device (CPLD) Development/Programmer Kit is a

complete development system and an In-System Programming (ISP) programmer for the Atmel ATF15xx

Family of industry standard pin compatible CPLDs with Logic Doubling ® features. This kit provides designers a

very quick and easy way to develop prototypes and evaluate new designs with an ATF15xx ISP CPLD. The

ATF15xx Family of ISP CPLDs includes the Atmel ATF15xxAS, ATF15xxASL, ATF15xxASV, and

ATF15xxASVL CPLDs. With the availability of the different socket adapter boards to support most of the

package types(1) offered in the ATF15xx Family of ISP CPLDs, this kit can be used as an ISP programmer to

program the ATF15xx ISP CPLDs in most of the available package types(1) through the industry standard JTAG

interface (IEEE 1149.1).

Kit Contents

CPLD Development/Programmer Board (ATF15xx-DK3)

44-pin TQFP Socket Adapter Board (ATF15xxDK3-SAA44) (2)

ATF15xx USB-based JTAG ISP Download Cable (ATDH1150USB or ATDH1150USB-K)

Two Atmel 44-pin TQFP Sample Devices

Device Support

The ATF15xx-DK3-U CPLD Development/Programmer Kit supports the following devices in all currently

available Atmel speed grades and packages (except the 100-PQFP):

ATF1502AS/ASL

ATF1504AS/ASL

ATF1508ASV/ASVL

ATF1502ASV

ATF1504ASV/ASVL

ATF1508AS/ASL

1. The socket adapter board is not offered for the 100-pin PQFP.

2. Only the 44-pin TQFP Socket Adapter Board is included in this kit. Other socket adapter boards are sold separately. See

“Hardware Description” section for more information on socket adapter board ordering codes.

ATF15xx-DK3-U

CPLD Development/Programmer Kit

USER GUIDE

ATF15xx-DK3-U Development/Programmer Kit [USER GUIDE]

Atmel-8961A-CPLD-ATF15xx-DK3-U-Development-Kit-UserGuide_072015

Table of Contents

Kit Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

CPLD Development/Programmer Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Logic Doubling CPLDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

ATF15xx ISP Download Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

PLD Development Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Ordering Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

CPLD Development/Programmer Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

7-segment Displays with Selectable Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

LEDs with Selectable Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Push-button Switches with Selectable Jumpers for I/O Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Push-button Switches with Selectable Jumpers for GCLR and OE1 Pins . . . . . . . . . . . . . . . . . . . . . 9

2MHz Oscillator and Clock Selection Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

VCCIO and VCCINT Voltage Selection Jumpers and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

ICCIO and ICCINT Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Voltage Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Power Supply Switch and Power LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Power Supply Jack and Power Supply Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

JTAG ISP Connector and TDO Selection Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Socket Adapter Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Atmel ATF15xx ISP Download Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

References and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Atmel ProChip Designer Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Atmel WinCUPL Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Atmel ATMISP Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Atmel POF2JED Conversion Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3ATF15xx-DK3-U Development/Programmer Kit [USER GUIDE]

Atmel-8961A-CPLD-ATF15xx-DK3-U-Development-Kit-UserGuide_072015

Kit Features

CPLD Development/Programmer Board

10-pin JTAG-ISP Port

Regulated Power Supply Circuits for 9VDC Power Source

Selectable 5V, 3.3V, 2.5V, or 1.8V I/O Voltage Supply

Selectable 1.8V, 3.3V, or 5.0V Core Voltage Supply

44-pin TQFP Socket Adapter Board

Headers for I/O Pins of the ATF15xx Device

2MHz Crystal Oscillator

Four 7-segment LED Displays

Eight Individual LEDs

Eight Push-button Switches

Global Clear and Output Enable Push-button Switches

Current Measurement Jumpers

Logic Doubling CPLDs

ATF15xx ISP CPLD with Logic Doubling Architecture

ATF15xx ISP Download Cable

5V, 3.3V, 2.5V, or 1.8V ISP Download Cable for the Universal Serial Bus (USB) port of a PC

There are two versions of the ATF15xx USB ISP Download Cable; ATDH1150USB and

ATDH1150USB-K. They are built by two different vendors but have identical circuit design, and the

Atmel Ordering Code is ATDH1150USB. The ATDH1150USB-K is built by Kanda ( ) www.kanda.com

and it can be directly purchased from Kanda. More details are available online at

www.atmel.com/tools/ATDH1150USB.aspx.

PLD Development Software

The Atmel PLD development software tools are available online for PLD designer’s use of the ATF15xx

ISP CPLDs. Please reference the Overview document, “PLD Design Software Overview” available at:

http://www.atmel.com/images/atmel-3629-pld-design-software-overview.pdf

System Requirements

The minimum hardware and software required to program an ATF15xx ISP CPLD device designed

using the Atmel ProChip Designer Software on the CPLD Development/Programmer Board through

the Atmel ATMISP (ATF15xx CPLD ISP Software) are:

x86 or x64 Microprocessor-based Computer

Windows XP® or Windows 7

128-MByte RAM

500-MByte Free Hard Disk Space

Windows-supported Mouse

Available USB 1.1 / 2.0 / 3.0 Port

9VDC Power Supply with 500mA of Supply Current

SVGA Monitor (800 x 600 Resolution)
