McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: 607-723-3512 www.mcintoshlabs.com
ML1
Loudspeaker System
Owner’s Manual
2
The lightning ash with arrowhead, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s en-
closure that may be of su󰀩cient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING - TO REDUCE RISK OF FIRE
OR ELECTRICAL SHOCK,
DO NOT EXPOSE THIS EQUIPMENT
TO RAIN OR MOISTURE
NO USER-SERVICEABLE PARTS IN-
SIDE. REFER SERVICING
TO QUALIFIED PERSONNEL
To prevent the risk of electric shock,
do not remove cover or back.
No user-serviceable parts inside.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including ampliîšżers) that produce
heat.
9. Do not defeat the safety purpose of the polar-
ized or grounding-type plug. A polarized plug
has two blades with one wider than the other.
A grounding type plug has two blades and a
third grounding prong. The wide blade or the
third prong are provided for your safety. If
the provided plug does not îšżt into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories speciîšżed by
the manufacturer.
12. Use only with the cart, stand,
tripod, bracket, or table speci-
îšżed by the manufacturer, or
sold with the apparatus. When
a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualiîšżed service person-
nel. Servicing is required when the apparatus
has been damaged in any way, such as
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
15. Do not expose this equipment to dripping or
splashing and ensure that no objects îšżlled
with liquids, such as vases, are placed on the
equipment.
16. To completely disconnect this equipment from
the AC mains, disconnect the AC / DC adapter
from the AC receptacle.
17. The mains plug of the power supply cord
shall remain readily operable. If the AC /
DC Adapter is provided with a mains power
supply cord attachment, the plug of this power
supply cord shall remain readily operable.
18. Do not expose batteries to excessive heat such
as sunshine, îšżre or the like.
19. Connect mains power supply cord only to a
mains socket outlet with a protective earthing
connection.
WARNING:
Use this product only with
the Power Adapter provided.
Failure to do so may result
in îšżre and/or electrical shock.
IMPORTANT
SAFETY INSTRUCTIONS!
PLEASE READ THEM BEFORE
OPERATING THIS EQUIPMENT.
3
Copyright 2023 © by McIntosh Laboratory, Inc.
Thank You from all of us at McIntosh
You have invested in a precision instrument that will
provide you with many years of enjoyment. Please
take a few moments to familiarize yourself with
the features and instructions to get the maximum
performance from your equipment.
If you need further technical assistance, please
contact your dealer who may be more familiar with
your particular setup including other brands. You can
also contact McIntosh with additional questions or in
the unlikely event of needing service.
McIntosh Laboratory, Inc.
2 Chambers Street
Binghamton, New York 13903
Technical Assistance (607) 723-3512
Fax (607) 724-0549
Customer Service (607) 723-3515
Fax (607) 723-1917
Email support@mcintoshlabs.com
www.mcintoshlabs.com
Please Take A Moment
For future reference, you can write down your serial
number and purchase information here.
We can identify your purchase from this information
if the occasion should arise:
Serial Number: __________________________
Purchase Date: ___________________________
Dealer Name: ___________________________
Table of Contents
General Information .. .. .. .. .. .. .. .. .. .. .. 3
Performance Features.. .. .. .. .. .. .. .. .. .. .. 4
Introduction.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 5
ML1 Stand .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 6
ML1 Stand Dimensions . .. .. .. .. .. .. .. .. .. 6
ML1 Dimensions . .. .. .. .. .. .. .. .. .. .. .. .. 7
Input Terminals .. .. .. .. .. .. .. .. .. .. .. .. .. 8
Unpacking the Loudspeaker .. .. .. .. .. .. .. .. 8
Installation .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 9
Loudspeaker Placement.. .. .. .. .. .. .. .. .. .. 9
Home Theater Setup .. .. .. .. .. .. .. .. .. .. .. 9
Music System Setup .. .. .. .. .. .. .. .. .. .. .. 9
How to Connect Using One Amplifier .. .. .. ..10
Connection Diagram (one amplifier).. .. .. .. ..11
How to Connect Using Two Amplifiers.. .. .. ..12
Connection Diagram (two amplifiers) .. .. .. ..13
Specifications .. .. .. .. .. .. .. .. .. .. .. .. .. ..14
Packing Instructions .. .. .. .. .. .. .. .. .. .. ..14
ML1 Packing Parts List .. .. .. .. .. .. .. .. .. ..15
Stand Packing Parts List. .. .. .. .. .. .. .. .. ..15
General Information
Caution: The ML1 weight is 68.5 pounds (31.1 kg). It
requires two or more persons to safely handle it.
1. For additional connection information, refer
to the owner’s manual(s) for any component(s)
connected to the ML1.
2. The ML1 has an American Walnut veneer
which contains natural variations in wood grain
giving each speaker a unique appearance.
3. If there is an obvious lack of high, mid or low
frequencies after extended periods of overdrive,
the Protection Device(s) may have activated.
These devices will automatically reset when the
volume level is greatly reduced until the output
of the aected Loudspeaker Driver(s) returns to
normal.
4. When discarding the unit, comply with
local rules or regulations. Batteries
should never be thrown away or incinerated but
disposed of in accordance with the local regula-
tions concerning battery disposal.
5. For additional information on the ML1 and
other McIntosh products please visit the
McIntosh website at www.mcintoshlabs.com.
