Pagina 1/112

INSTRUCTION MANUAL

Rechargeable Wall Scanner

DWD181

ENGLISH: Original instructions

Read before use.

MANUAL DE INSTRUCCIONES

Escáner de Pared Recargable

ESPAÑOL: Instrucciones originales

Leer antes de usar.

Contents

Specications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3

Applicable battery cartridge -------------------------------------4

Continuous operating time per one time of charge (*) - - - - - - - - - - - - - - 4

Symbols - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

Intended Use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

Laser Beam Related Safety Standards -----------------------------6

Safety Declaration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6

Radio Standards - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6

Déclaration sur la sécurité - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9

Normes radioélectriques - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9

Safety Warnings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

Important Safety Instructions for Battery Cartridge - - - - - - - - - - - - - - - - - - 18

Tips for maintaining maximum battery life ------------------------19

Names of Parts - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 20

Names of exterior parts ----------------------------------------20

Names of operation buttons ------------------------------------21

Standard Accessories - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 21

Optional Accessories - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22

Battery - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23

Battery - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23

For long battery life - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23

Installing or Removing Battery Cartridge --------------------------24

Using the Wall Scanner - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 25

Operation ow - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 25

Startup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 26

Selecting a scan mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 27

Selecting a scene - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 28

Scanning- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 30

Scan result display - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 32

Marking the locations of buried objects --------------------------34

Shutdown - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 35

Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 36

Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 39

Searching for iron bars in concrete ------------------------------39

Searching for wiring resin pipes in concrete ----------------------41

Searching for a pillar behind a gypsum board --------------------46

Searching for iron bars in a block fence --------------------------48

To scan better - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 51

Protection System - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 55

Protective functions for the scanner and the battery - - - - - - - - - - - - - - - 55

Maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 57

Care of the product - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 57

Specications

Model

Major function DWD181

Voltage 14.4 V DC/

18 V DC

Maximum scan depth 180 mm (7 1/16") (*1)

Accuracy of depth to

object ± 5 mm (3/16") (*1, *2)

Minimum detectable

object-object distance 40 mm (1 9/16") (*1)

Scan

guide

laser

Light source Red semiconductor laser

Wavelength 645–660 nm

Optical output 0.39 mW or below (Class 1)

Operational frequency

band 732.76 MHz – 2,881.78 MHz

Transmit power -17.16 dBm

Operating temperature

range -10 °C to + 40 °C (14 °F to 104 °F)

Storage temperature

range -20 °C to + 50 °C (-4 °F to 122 °F)

Relative Humidity 5–60% (Condensation not allowed)

ESD protective measures Level: 4 (IEC61000-4-2)

Product dimensions

(L × W × H)

259 mm × 118 mm × 107 mm

(10 3/16" × 4 5/8" × 4 3/16")

(Except the battery)

Weight 1.0 kg (2.2 lbs)

(Except the battery)

Operating environment: Indoor use

Altitude: Up to 2,000 m (6,561 11/16')

Pollution degree: 2

*1 Varies by the size, shape and material of the buried material, as well as

the material, condition and internal structure of the scanned wall.

*2 When an iron bar of 150 mm (5 15/16") is detected in concrete

Applicable battery cartridge

BL1415N/BL1430B/BL1460B/BL1815N/BL1820B/BL1830B/BL1840B/

BL1850B/BL1860B

•Some of the battery cartridges listed above may not be available depending

on your region of residence.

WARNING

Only use the battery cartridges listed above.

• Use of any other battery cartridges may cause injury and/or re.

Continuous operating time per one time of charge (*)

Model

Battery DWD181

BL1860B Approx. 28 hours

•Major functions, shapes and other specications are subject to change for

improvement.

(*) The continuous operating time is for reference purposes. It varies by the

battery's charge status and the operating environment.

The denitions below describe the level of severity for each signal word and

the meaning of each symbol used in this manual.

Please read the manual and pay attention to these symbols.

: Read instruction manual.

DANGER : This indicates the risk of death or frequent serious injury.

WARNING : This indicates the risk of serious injury.

CAUTION : This indicates the risk of light injury.

NOTICE

NOTE : This indicates the risk of malfunction or damage to property.

: This indicates the risk of electric shock.

: This indicates the risk of re.

: Laser warning

: Only for EU countries Do not dispose of electric equipment

or battery pack together with household waste material! In

observance of the European Directives, on Waste Electric

and Electronic Equipment and Batteries and Accumulators

and Waste Batteries and Accumulators and their

implementation in accordance with national laws, electric

equipment and batteries and battery pack(s) that have

reached the end of their life must be collected separately

and returned to an environmentally compatible recycling

facility.

Intended Use

This product is intended to check the locations of iron bars, plastic pipes and

wires buried in concrete, and of wooden materials and such behind walls.

Symbols

WARNING

Read all safety warnings, instructions, illustrations and specications

provided with the product. Failure to follow all instructions listed below

may result in electric shock, re and/or serious injury.

Save all warnings and instructions for future reference.

WARNING - Laser safety

• Do not look directly into the laser beam on optical instruments.

• Directly looking at the laser beam by telescopic optics, magnifying glass

or similar instruments is dangerous.

• Do not stare directly at the laser beam.

• Avoid locating the path of the laser beam at eye height.

• Do not enter the path of the laser beam.

• Do not place reective objects in the path of the laser beam.

• Do not point the laser beam at other persons.

Continuously looking at laser beams may damage your eyes. If your eyes

might be impaired, immediately seek treatment by a physician.

CAUTION

• Laser light is bright and blinding - Do not shine at aircraft or vehicles at

any distance.

WARNING - Work area safety

1. Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

2. Do not operate the product in explosive atmospheres, such

as in the presence of ammable liquids, gases or dust.

Products create sparks which may ignite the dust or fumes.

3. Keep children and bystanders away while operating the product.

Distractions can cause you to lose control.

4. When working at heights, be very sure that there is no one

underneath.

5. Do not use the product in a place that may affect any equipment

or systems that can pose a direct risk of death or injury, or those

that can cause a great deal of damage to property (outer-space

equipment, submarine repeaters, nuclear control systems,

aircraft control systems, infrastructural systems of plants, military

equipment, etc.).

Safety Warnings

WARNING - Maintenance

1. Have the product serviced by a qualied repair person using

only identical replacement parts. This will ensure that the safety

of the product is maintained.

2. Service of battery packs Never service damaged battery packs.

should only be performed by the manufacturer or authorized

service providers.

3. Follow instruction for changing accessories.

4. Do not disassemble, repair, modify or retrot this product,

charger or battery. Doing so might cause ignition or abnormal

operation, which may result in injury.

5. If this product is Inspect this product for damaged parts.

operating abnormally or malfunctioning, immediately stop use.

Continued use of this product in this condition might lead to smoke

emission, ignition, electric shock, or injury.

x Power cable and power plug are abnormally hot.

x The power cable has deep scratches or is deformed.

x Power turns ON and OFF when the power cable is moved.

x There is a burning smell.

x There is a tingling feeling of electricity.

If you sense a malfunction, such as this product not functioning

even after turning the power switch ON, immediately remove

the battery and ask the store of purchase or a Makita authorized

service center for inspection and repair.

6. Do not This product complies with relevant safety standard.

modify or retrot it.

7. If repair is performed by a person without specialist

knowledge and repair skills, not only will the performance

of this product not be fully demonstrated but this might also

result in accident or injury.
