Pagina 1/2

SIZE: 70x158mm

FCC NOTICE:

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interfer-

ence to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more

of the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the equipment and

receiver.

● Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV

technician for help.

FCC WARNING:

To assure continued operation, follow the attached

installation instructions and use only shield cables when

connecting to other devices. Changes or modifications not

expressly approved by the party responsible for

compliance could void the user's authority to operate the

equipment.

BT Version 4.1

BT Operation Distance

≧ 32 Feet in open area

Audio Power 3W per Channel (Total 6 W, RMS)

Power Source

Dusts/Water Ingress

Protection Level

Impedance of Speakers

2 x 5 W; 3 ohm

Built-in DC 3.7V, 1000 mAH(3.7WH) rechargeable Li-ion battery;

Recharge by DC 5V through Micro USB Port

POSSIBLE SOLUTION

Recharge the built-in battery as page 2.

Increase the volume by press and holding

the Button

Rise the volume level of the

paired/connected device

Reduce the volume level by press and

holding the Button

Reduce the volume level of the

connected/paired device

Pair the external BT Device to the unit as

page 2.

Place the external BT device close to the

unit

POSSIBLE CAUSE

Built in battery drained

Volume of the unit was set to

minimum position

Volume level of paired/connected

device is in low level

Volume level too high

Volume level of the

connected/paired device too high

The external BT Device had NOT

paired to the unit

The external BT device too far

from the unit

SYMPTOM

Can’t power on

No sound or sound

weak

Sound distortion

BT not functioning

2. Power on the external BT Device and enter to BT searching mode. Start pairing

following the on screen instructions from the external BT Device. After paired, the

unit will sound a prompt tone and the White Indicator will stop blinking.

3. If pairing is complete you may now play music and answer calls with your external

BT Device.

4. During playback:

● Press the ► Button on the unit to pause, press again to resume normalplayback.

● Press and holding the or Buttons to adjust volume level as desired.

● Press and release the or Buttons repeatedly to skip tracks.

● Press the M Button repeatedly to switch to other playback mode.

5. If the unit is paired to a Cell Phone and a call is incoming during an active music

session, press the ► Button to pause the music playback. Then speak to the built-

in microphone to answer the call. When your call is complete, press the ► Button

to disconnect or end the call and resume to music playback.

6. When finished listening, press and hold the Button to shut off the unit.M

Notes:

● When the external BT Device searched the unit, our model number “MMA3639” will

appear on the display of external BT Device.

● If while pairing you are asked for a code please try "0000" or "1234".

Normal operation after pairing:

1. Power on the unit by pressing and holding the Button on the top of the unit M

approximately 1 second until the White Indicator on the front of unit is illuminate

and blink. The unit will enter to BT (Bluetooth) mode automatically. (If Micro SD

Card and/or Audio Connection Cable was inserted into the unit, press the Button M

repeatedly to switch to BT mode.)

2. Wait a few seconds until the unit is automatically paired to the external BT Device.

3. After pairing is complete, the unit will sound a prompt tone and the White Indicator

will stop blinking. You may now play music and answer calls with your external BT

Device.

LINE IN:

To listen from an external Audio Player such as a MP3 Player, Discman …etc.

1. Open the Rubber Cover on the rear of unit.

2. Connect one end of the supplied Audio Connection Cable to the AUX Out/Line

Out/Phone Jack on the external Audio Player.

3. In power on mode, connect the other end of the cable to the LINE IN Jack as the

illustrated below. The unit will turn to LINE IN mode automatically.

To AUX Out/Line Out/Phone Jack

on the external Audio Player

4. Play the music on the connected Player as usual. (Make sure the volume level of

the connected Audio Player is turned to high level.)

5. During playback:

● Press the Button to mute the sound, press again to turn the sound back.

● Press and holding the or Buttons to adjust volume level as desired.

● Press the M Button repeatedly to switch to other playback mode.

6. When finished listening, press and hold the Button to shut off the unit.M

Micro SD Card:

1. Open the Rubber Cover on the rear of unit.

2. Insert the Micro SD Card into the Micro SD Card Slot with contact finger face to up

as the illustrated follows:

MODEL: MMA3639

PLEASE READ BEFORE OPERATING THIS EQUIPMENT.

OWNER'S MANUAL

OUTDOOR

WATERPROOF SPEAKER

with Bluetooth® Wireless Technology

Craig Electronics warrants this product to be free from manufacturing defects in

material and workmanship under normal use for a period of 180 days from date

of purchase. If service is required, please return the product to the store where it

was purchased for exchange; or, pack the unit in the original packing material

with all accessories if applicable, a copy of your sales receipt and a Cashier’s

check or Money Order for $12 (to cover shipping and handling costs) payable to

Craig Electronics Inc. For consumers in Canada, please make sure that the

cashier check or money order is redeemable through a U.S. bank. Ship your

product freight pre-paid. Your unit will be repaired, replaced or if the unit cannot

be repaired or replaced, a refund will be forwarded to you within four weeks of

receipt of your unit. Please ship your unit to:

Craig Electronics Inc.

1160 NW 163 Drive

Miami, Fl 33169

This warranty is void if the product has been: a) Used in a commercial application

or rental. b) Damaged through misuse, negligence, or abuse. c) Modified or

repaired by anyone other than an authorized Craig service center. d) Damaged

because it is improperly connected to any other equipment.

Note: This warranty does not cover: a) Ordinary adjustments as outlined in the

Owner’s Manual which can be performed by the customer. b) Damage to

equipment not properly connected to the product. c) Any cost incurred in shipping

the product for repair. d) Damage to the product not used in the USA.

This warranty is not transferable and only applies to the original purchase. Any

implied warranties, including the warranty of merchantability, are limited in

duration to the period of this expressed warranty and no warranty whether

expressed or implied shall apply to the product thereafter.

Under no circumstance shall Craig be liable for any loss or consequential

damage arising out of the use of this product. This warranty gives specific legal

rights. However, you may have other rights which may vary from state to state.

Some states do not allow limitations on implied warranties or exclusion of

consequential damage. Therefore, these restrictions may not apply to you.

This product has been manufactured by and is sold under the responsibility of

Craig Electronics Inc, and Craig Electronics Inc is the warrantor in relation to this

product. MAGNAVOX and SMART. VERY SMART are registered trademarks of

Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V.

To Obtain Service on your Product

email:service@craigelectronics.com

Printed in China MMA3639_WC_E0FK1_B0WU

LIMITED WARRANTY

3. Power on the unit by pressing and holding the Button on the top of the unit M

approximately 1 second. The unit will plays the song/music on the Micro SD Card

automatically.

4. During playback:

● Press the ► Button to mute the sound, press again to turn the sound back.

● Press and holding the or Buttons to adjust volume level as desired.

● Press and release the or Buttons repeatedly to skip tracks.

● Press the M Button repeatedly to switch to other playback mode.

5. When finished listening, press and hold the Button to shut off the unit.M

Notes:

● Up to 16 GB Micro SD Card the unit support to play.

● Before replacing Micro SD Card, make sure the unit has been powered off.

● When inserting the Micro SD Card, make sure the direction you selected is correct.

Never insert violently to avoid damaging the Micro SD Card or the unit.

● If it doesn’t work, please check if the direction is correct.

● You also need to download the desired music in MP3 format into the Micro SD Card

before insert into the unit.

RESET:

If the unit is halt or abnormal operation, press the Reset Button by a small

screw driver (not included) to shut it off. Press and holding the M Button

approximate 1 second to power on it again.

TROUBLESHOOTING:

Check the following before requesting service:

SPECIFICATIONS:

PACKAGE INCLUDES:

1 x User's Manual

1 x USB Connection Cable (For charge only)

1 x Audio Connection Cables with 3.5mm Plugs

SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE

WITHOUT NOTICE.

LOCATION OF CONTROLS:

M Button 2. Button

3. Button

4. Button

5. White Indictor

6. Rubber Cover (This cover is for water

and dusts Ingress Protection; always

make sure it is completely closed)

7. LINE IN Jack

8. Micro USB Port (For charge only)

9. Micro SD Card Slot

10. Red Charging Indictor

11.

Reset Button (Inside the hole)

12. Built-in Microphone

13. Metallic Buckle

POWER SOURCE:

The unit has a built in Li-ion rechargeable battery, recharge it before use or when the

battery is drained as follows:

1. Open the Rubber Cover on the rear of unit.

2. Connect the Micro USB Plug from the supplied USB Connection Cable to the Micro

USB Port.

3. Connect the full sized USB Plug from the supplied USB Connection Cable to the

USB Port on Computer or USB Charger (Not included).Charging will automatically

start.

● During charging, the Red Charging Indicator on the rear of unit will illuminate.

When finished, it will turn off.

● During charging, you can also play and listen music at the same time.

To Computer or any USB Charger

NOTES:

The Rubber cover is for water and dusts Ingress Protection; always make sure

it is completely closed.

IMPORTANT:

Your battery will last longer if you're following these simple guidelines for charging

and storing.

A. Before first time use, charge it approximately 4 hours until the unit is fully charged.

B. Recharge and store the unit within the temperature range of 5 °C~35°(40°F~95°F).

C. Do not charge longer than 24 hours. Excessive charging or running the unit until

battery fully drains will damage battery. Battery life will be extended if you keep the

battery fully charged.

D. Battery life naturally shortens slowly over time.

E. The rechargeable battery incorporated in this product is not user replaceable.

OPERATION:

BT (Bluetooth) pairing:

First time use or re-pairing the unit to a new BT Device, pair as follows:

1. Power on the unit by pressing and holding the Button on the top of the unit M

approximately 1 second until the White Indicator on the top of unit is illuminate and

blink. The unit will enter to BT (Bluetooth) mode automatically. (If Micro SD Card

and/ or Audio Connection Cable was inserted into the unit. Unplug them from unit

before power on or press the Button repeatedly to switch to BT mode.)M

IP67

Product specificaties

Merk:	Magnavox
Categorie:	Cradle/docking station
Model:	MMA3639
Kleur van het product:	Black, Blue
Gewicht:	331 g
Breedte:	186 mm
Diepte:	65.02 mm
Hoogte:	65.02 mm
Gebruikershandleiding:	Ja
Internationale veiligheidscode (IP):	IP67
Capaciteit van de accu/batterij:	1000 mAh
Bluetooth:	Ja
Bluetooth-versie:	4.1
Connectiviteitstechnologie:	Bedraad en draadloos
Type stroombron:	Batterij/Accu
Meegeleverde kabels:	Audio (3.5mm), Micro-USB
Geïntegreerde geheugenkaartlezer:	Ja
Compatibele geheugenkaarten:	SD
Gemiddeld vermogen:	6 W
Aantal luidsprekers:	1
Ingebouwde microfoon:	Ja
Levensduur accu/batterij:	4 uur
Aanbevolen gebruik:	Universeel
3,5mm-connector:	Ja
Veiligheidsfunties:	Dust resistant, Waterproof
Audio-uitgangskanalen:	- kanalen
Frequentiebereik:	2.402 - 2.48 GHz
Signaal/ruis-verhouding:	75 dB
Productontwerp:	Overige
Wifi:	Nee
Type product:	Draadloze stereoluidspreker
Batterijtechnologie:	Lithium-Ion (Li-Ion)
Type batterij:	Ingebouwde accu
