Pagina 1/5
Design by Elium Studio
LA134
TERRACE+
（A）
1
2
3
4
5
6 6
7
8
9
PRODUCT OVERVIEW
1. Lampshade
2. Rotary knob for lamp functions
3. LED indicator for Bluetooth status
4. Rotary knob for audio functions
5. Speaker
FIRST USE
We recommend you to fully charge Terrace+ before using it for the first time.
Access the USB-C charging port by gently holding the lamp base then rotate the bottom of the lamp 1.
counterclockwise (A).
Plug the provided USB Type-C cable into the USB-C charging port of Terrace+. 2.
Plug the other USB-C end into any DC 5V power supply charger.3.
A full charge cycle takes about 4 to 5 hours.
LED information (9)
OPERATING INSTRUCTIONS
Lamp features
• Press and hold the lamp knob to turn ON/OFF the lamp.
• Once switched ON, press the lamp knob 3 times to toggle between the different lighting modes:
All-color mode O
Special lighting effects mode O
Warm and cool light mode O
• When in the selected mode, press the button once to toggle among colours or effects.
• Turn the lamp knob clockwise to increase the brightness. Turn the lamp knob
counterclockwise to decrease it.
Audio features
Bluetooth pairing
1. Press and hold the audio knob to turn ON/OFF the Bluetooth mode.
2. The Bluetooth LED indicator will start flashing in blue.
3. On your mobile device, enable Bluetooth search & select LEXON TERRACE+ from the list.
4. Start playing music!
LED information (3)
Volume adjustment
• Turn the lamp knob clockwise to increase the volume.
• Turn the lamp knob counterclockwise to decrease the volume.
True Wireless Stereo (TWS technology)
Built-in TWS technology allows you to pair two Terrace+ together to enjoy stereo sound for an enhanced
audio experience:
1. Turn on both Terrace+ by long-pressing the audio knob. Make sure none of them is
connected to any other mobile device.
2. Double press the audio knob of one of the two Terrace+. It will automatically search for the second
Terrace+and connect. A sound will indicate successful connection.
3. Go into the Bluetooth
® settings of your mobile device and turn on the Bluetooth
® mode.
4. Look for the LEXON TERRACE+ speaker in the Bluetooth
® devices list.
5. Once found, tap to connect. The speaker will emit a confirmation sound
when paired with your mobile device.
Pairing another mobile device
1. Press the audio knob twice to unpair the Terrace+ speaker from any mobile device.
2. Restart pairing process with another mobile device.
Power bank function
Important note: We strongly recommend connecting your Terrace+ to a power source when you are
charging 1 or 2 devices, listening to music and/or when the lamp is switched ON.
1. Access the USB charging ports by gently holding the lamp base and rotating the bottom of the lamp
counterclockwise (A).
2. Use the 2 USB-A ports (charging output) and/or the USB-C port (charging output & input)
to recharge your mobile devices. Multiple devices can be charged simultaneously.
3. Make sure to use a power adapter (not supplied) that provides sufficient power for the number of
mobile device you want to charge and enjoy lighting & audio functions at the same time.
LED information (8 & 9)
SAFETY PRECAUTIONS
1. Use a power adapter (not supplied) that provides sufficient power for the number
of devices you want to charge.
2. Keep the product away from heat sources like radiators, heaters and air ducts.
3. Keep away from corrosive liquids.
4. Do not insert any conductive objects into the speaker, or charging port.
5. Do not attempt to repair the speaker yourself; seek for professional service.
6. Do not expose the product to water during charging, as this could permanently damage
the speaker or power source.
* may vary based on product use, light intensity set, light color selected and volume level
6. USB-A ports (charging output)
7. IN/OUT USB-C port (charging input & output)
8. LED indicator for battery status
9. LED indicator for charging status
Ready to pair
Connected
Charging (9)
Fully charged (9)
Power bank status (8)
Steady red light
OFF
LED 1: 25% battery level
LED 2: 50% battery level
LED 3: 75% battery level
LED 4: 100% battery level
Blinking blue
Solid blue
PRODUCT SPECIFICATIONS
Material: Metal / ABS
Dimensions: Ø3.94 x 8.89" / Ø10 x 22,6 cm
Weight: 1.03 lbs / 470 g
Bluetooth version: 5.0
Bluetooth range: 33 ft / 10m
Speaker power: 2x 3W
Frequency response: 180Hz-20KHz
Battery type: Li-ion 4000 mAh
Battery voltage: 3.7V
Input: 5V-2A min
Max. lumen output: 150 lm
Light power: 5W max
Color temperature:
Warm light: 2700K
Cold white: 6500K
Battery life*: Up to 12h for light only /
Up to 8h for audio only
Power bank output: 5V-2A
Operating temperature: 0°C - 40°C
International warranty: 1 year
Charging (9)
Fully charged (9)
Steady red light
OFF
