Pagina 1/51

LED LENSER® * h7R.2

Operating instructions

Bedienungsanleitung

Instrucciones de uso

Mode d‘emploi

Gebruiksaanwijzing

Istruzioni per l‘uso

Käyttöohje

Bruksanvisning

Руководство по эксплуатации

수동

取扱説明書

手册

LED LENSER® * h7R.2

English ........................................... 02-05

Deutsch .......................................... 06-09

Español .......................................... 10-13

Français ......................................... 14-18

Nederlands................................... 19-22

Italian.............................................. 23-26

Suomi ............................................. 27-30

Svenska ......................................... 31-34

Pусский ......................................... 35-39

한국어 ............................................ 40-42

日本語 ............................................ 43-45

中文 ................................................. 46-48

English | Page 02-05 GB

We are delighted that you have purchased one

of our products.

These are usage instructions to help you

familiarize yourself with your new purchase.

All the documents accompanying the product

must be read attentively before using the

product, preserved carefully and if the product

is transferred to a third party, the documents

must be handed over as well. This ensures that

maximum benefit is drawn from the product

and questions from users are anticipated

before they arise.

Above all, comply with the warnings and safety

instructions and dispose of the packaging

material properly.

Additional Information for H7R.2 with “TEST

IT” Function

Your LED LENSER H7R.2 headlamp is packaged

with a “TEST IT” function (item no. 7398). This

allows users to test the brightness while the

product is still in the package. For testing,

simply push the yellow “TEST IT” button on the

front of the package. When testing, please do

not look directly into the light.

The “TEST IT” button is connected to the

battery housing of the H7R.2 via two wires and

should be removed prior to use.

To remove the “TEST-IT” button and wires,

open the battery box rear cover and remove

4xAAA alkaline battery (see also “Changing of

the battery“ further below). Separate the two

“TEST IT” button wires from the battery housing

by pulling on each wire until it releases from

the battery housing. Insert the batteries in and

noting the correct polarity. Close the battery

box. Please dispose and recycle the packaging

and “TEST IT” button with the wires according

to the local regulations.

Product

7298, H7R.2LED LENSER®

7398, H7R.2 (Blister)LED LENSER®

Version of the operating manual: 1.5

1. Battery set:

1 x Li-ion battery pack 3.7 V (1400 mAh)

4XAAA alkaline battery (Blister)

2. ON and OFF

The H7R.2 has two switches. The front switch

is located on the right side of the headlamp

housing. This switch button is used to turn the

H7R.2 ON/OFF. It is also used to activate the

various Light Programs and Lighting Functions

(see section 5.1) and the “Transport Lock”

function (see Point 7).

The “Multi-function Wheel” switch is located on

the backside at the upper part of the battery

box. This allows you to adjust the brightness

and flash rate infinitely and to change into

different modes. In this switch is also a battery

indicator and the red rear light located (see

Section 5.2).

3. Focus

In the front, narrower region of the headlamp

housing is the reflector lens located. This lens

focused the light of the white LED through our

patented "Advanced Focus System".

The reflector lens is held by a plastic ring. You

can rotate that plastic ring using two fingers,

and thus adjust the focus quickly and easily.

This is our Turning Focus, which allows the

adjustment of the light beam’s focus.

You also can adjust the hinge of the headlamp,

depending on whether you want to illuminate

an area in the distance or in front of you. For

this, you simply tilt the part of the lamp head,

which containing the reflector lens and the

white LED. The gradual detent allows also

intermediate positions.

4. Smart Light Technology (SLT)

Smart Light Technology (SLT) is a program

that consists of computer optimized

microcontrollers which allows our products

to have various lighting functions. The H7R.2

is equipped with this technology and is

therefore able to use various Light Programs

and Functions. The front switch at the top of

the lamp head can turn the lamp On and Off,

change the brightness, and turn on functions

like the boost mode and others. Pressing the

“Multi-function Wheel" switch on the upper

part of the battery box can turn on the red light.

This “Multi-function Wheel" switch can also be

rotated to further adjust the brightness of your

headlamp light .

5. Light Programs and Light Functions

The H7R.2 is equipped with three LEDs (LED

= Light Emitting Diode), one white LED in the

front housing, and two other red LED’s in the

battery box.

The white LED is very strong and ideal for

normal use. This very bright white light may

not suitable when your eyes have become

accustomed through the dark or low ambient

light.

The red LED is not meant to illuminate a space,

but as a way to be seen or identified (see

Section 5.2).

5.1 Light Program White (Front light)

In H7R.2, there are three different modes (Easy

Low, Easy Power, Signal). The default mode is

Easy Low.

When the product is off, press the “Multi-

function Wheel” switch for 5 second. It will

achieve mode transition. Then white LED will

blink once (3Hz) to indicate that it is mode one;

then blink twice for mode two; and finally blink

thrice for mode three.

a) Light Mode one - Easy Low: when the

product is off, firmly press the front switch

button until it blinks once. The white LED will

glow at its lowest brightness (light function:

Low Power dim light). A second touch to the

button on top of the lamp will turn ion the lamp

to its full brightness (light function: Power

strong light), and third touch will turn the lamp

off.

b) Light Mode two - Easy Power: when the

product is off, firmly press the front switch

until it blinks twice. The white LED will glow at

its fullest brightness (light function: Power). A

second touch to the button on top of the lamp

will turn on the lamp to its lowest brightness

(light function: Low Power), and third touch will

turn the lamp off.

Product specificaties

Merk:	Ledlenser
Categorie:	Zaklamp
Model:	H7R.2
Kleur van het product:	Black, Red, Silver
Gewicht:	165 g
Materiaal behuizing:	Kunststof
Aantal lampen:	1 lampen
Soort lamp:	LED
Vermogen lamp:	- W
Internationale veiligheidscode (IP):	IP54
Waterdicht:	Ja
Ondersteund aantal accu's/batterijen:	1
Levensduur accu/batterij:	60 uur
Aantal per verpakking:	1 stuk(s)
Lichtstroom:	300 lm
Batterijen inbegrepen:	Ja
Batterijtechnologie:	Lithium-Ion (Li-Ion)
Type zaklamp:	Lantaarn aan hoofdband
Lichtbundelafstand (max):	160 m
