Lectrosonics Venue 2 Handleiding
Lectrosonics
Receiver
Venue 2
Lees hieronder de 📖 handleiding in het Nederlandse voor Lectrosonics Venue 2 (32 pagina's) in de categorie Receiver. Deze handleiding was nuttig voor 44 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld
Pagina 1/32
Venue 2 Modular Receiver
With Built-in Multicoupler
INSTALLATION GUIDE
Rio Rancho, NM, USA
www.lectrosonics.com
Fill in for your records:
Serial Number:
Purchase Date:
Hardware/Software Installation and Configuration
Essential Setup Steps for Operation
1) Install receiver modules, connect antennas and power supply
2) Install transmitter batteries and antennas
3) Identify and set operating frequencies on the receiver using
Smart TuneTM and set frequencies on the transmitters
4) Attach microphones and adjust transmitter input gain
5) Verify operation with a walk test through the area where the
system will be used
Two versions available:
VRM2WBL tunes bands A1, B1, B2 and C1 in tuning range 470.100 to 691.175 MHz
VRM2WBM tunes bands B1, B2, C1 and C2 in tuning range 537.600 to 716.700 MHz
CAN RSS-Gen/CNR-Gen
Venue 2 Wideband Receiver
LECTROSONICS, INC.
2
Digital Hybrid Wireless ® Modular Receiver System
Rio Rancho, NM, USA 3
FCC Notice:
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Table of Contents
Introduction 4 ...........................................................................
Important Safety Instructions..............................................5
Front Panel 6 ............................................................................
Rear Panel 7 .............................................................................
Hardware Installation 8 ...........................................................
Receiver Modules 8 ...............................................................
Rack Installation 8 ..................................................................
Audio Outputs 8 .....................................................................
Connections for Computer Interface and Serial Control 9 .....
LCD Interface 10 ......................................................................
Top Menu 10 ..........................................................................
Rx Menu 10 ............................................................................
Tx Menu 10 ............................................................................
Navigating the Menus 10 ........................................................
Using Setup Screens 11 ..........................................................
Setup Details 12 .......................................................................
Direct Access to Receiver Setup 12 ......................................
Audio Output Levels Setup 12 ...............................................
Diversity Pairing 13 ................................................................
Talkback Setup 14 ..................................................................
Group Tuning .....................................................................14
About Active Alerts............................................................14
Top Menu SYSTEM INFO 15 .................................................
Resetting to Factory Defaults 15 ............................................
IR Transmitter Setup ...........................................................15
Smart TuneTM 16 .............................................................................................................................
Manual Scanning 16 ................................................................
Firmware Update 17 ................................................................
System Restore 17 ..................................................................
Wireless Designer Software and USB Driver 18 ...................
Wireless Designer Software and USB Driver 19 ...................
TOP MENU 20 .......................................................................
Menu Map 20 ............................................................................
RX MENU 22 .........................................................................
Connecting to a Network 23 ...................................................
Multi-channel System Checkout 24 .......................................
Antennas 25 .............................................................................
Use and Placement 25 ...........................................................
Using Remote Antennas 25 ...................................................
Front Mounted Antennas 26 ...................................................
Accessories and Common Replacement Parts 28 ...............
Remote Antennas 28 .............................................................
Coaxial Cable 28 ....................................................................
Coaxial RF Amplifier 28 .........................................................
Common Replacement Parts 28 ............................................
USB Cable 28 ........................................................................
Software Installer 28 ..............................................................
Specifications 29 .....................................................................
Service and Repair 30 .............................................................
Returning Units for Repair 30 ................................................
