Pagina 1/4
WHAT’S
INSIDE
Power adapter (5VDC) with regional adapters RJ45 CAT5 Ethernet Cable – 3'xPrintServerQuick Start Guide
1 BEFORE YOU BEGIN
2 QUICK CONNECT
1. Test printing from a Windows or Mac computer (from which the USB printer is directly attached) is working before proceeding.
2. Internet access is required to download printer drivers.
WHAT’S
INSIDE
Power adapte r (5VDC) with regional ada pters
RJ45 CAT5 Ethe rnet Cable – 3'xPrintServerQuick S tart Guide
1 BEFORE YOU BEGIN
2 QUICK CONNECT
1. Test printing from a Windows or Mac computer (from which the USB printer is directly attached) is working before proceeding.
2. Internet access is required to download printer drivers.
WHAT’S IN SIDE
Power adapter (5VDC) with regional adapters RJ45 CAT5 Ethernet Cable – 3'xPrintServerQuick Start Guide
Home Edition Quick Start Guide
1 BEFO R E Y OU B EG IN
2 QU IC K C O NN EC T
1. Test printing from a Windows or Mac computer (from which the USB printer is directly attached) is working before proceeding.2. Internet access is required to download printer drivers.
2. From the Printer Options menu, choose Printer to display all avail-able networked printers.1. Using your iPad, iPhone or other iOS device, Open the web page, email, photo, etc. that you wish to print and choose the icon to open the native print menu: 3. Select the appropriate printer. Then, select the number of copies and choose Print.
3 HO W TO PR IN T FRO M D EV ICESiOS
WhAt’S inSide
Home Edition Quick Start Guide
1
USB PrinterUSB Cable Network Cable
Wireless Router/Switch
2
3
1
Connect USB printer cable to USB
port of xPrintServer.
2
Connect network cable from wireless
router/switch to xPrintServer.
3
Power on the xPrintServer with
supplied power adapter.
1 Ensure USB printer has been tested and functional before proceeding.2 Internet access is required to download printer drivers.
Home Edition Quick Start Guide
1
USB Printer
USB Cable Network Cable
Wireless Router/
Switch
2
3
1Connect USB printer cable to US B
port of xPrintServer.
2
Connect network cable from wireless
router/s witch to xPrintServer.
3Power on the xPrintServer with
supplied p ower adapter.
Auto Set-Up Process: The xPrintServer will automatically set-up your printers (USB & network) as soon it is connected, as shown above. The
glowing “X” will blink quickly for about 30 seconds, then it will pulse slowly to show it’s ready for printing.
2. From the Printer Options menu,
choose Printer to display all
available networked printers.
1. Using your iPad, iPhone or other iOS device,
Open the web page, email, photo, etc. that you
wish to print and choose the icon to open the
native print menu:
3. Select the appropriate printer.
Then, select the numb er of copies
and choose Print.
3 HOW TO PRINT FROM DEVICESiOS
Home Edition Quick Start Guide
1
USB Printer
USB Cable Network Cable
Wireless Router/
Switch
2
3
1Connect USB printer cable to USB
port of xPrintServer.
2Connect network cable from wireless
router/switch to xPrintServer.
3Power on the xPrintServer with
supplied power adapter.
Auto Set-Up Process: The xPrintServer will automatically set-up your printers (USB & network) as soon it is connected, as shown above. The
glowing “X” will blink quickly for about 30 seconds, then it will pulse slowly to show it’s ready for printing.
2. From the Printer Options menu,
choose Printer to display all
available networked printers.
1. Using your iPad, iPhone or other iOS device, the web Open
page, email, photo, etc. that you wish to print and choose
the icon to open the native print menu:
3. Select the appropriate printer.
Then, select the number of copies
and choose Print.
3 HOW TO PRINT FROM DEVICESiOS
1. Go to System Preferences, Hardware and click on Print & Scan.
2. Click on the button on the lower left corner+
3. A list of printers appear. Select the printer you wish to add and
click on the button.Add
4. The printer is now added in your available list of printers and is
ready to print.
Home Edition Quick Start Guide
4 HOW TO PRINT FROM MAC OS
Instructions for Windows XP
4. The Bonjour Printer Wizard appears with a list of discovered printers.
Highlight the printer you wish to install.
5. Search and select your printer by manufacturer model and number
and click .Next
Instructions for Windows 7
4. The Bonjour Printer Wizard appears with a list of discovered
printers. Highlight the printer you wish to install.
5. Search and select your printer by manufacturer and model number
and click .Next
5 HOW TO PRINT FROM WINDOWS OS
Home Edition Quick Start Guide
BEFORE YOU BEGIN
Ensure the USB printer is working and the printer drivers are installed on the computer before proceeding.
INSTALL BONJOUR PRINT SERVICES
1. Bonjour Print Services is an Apple application that allows discovery of printers connected to the xPrintServer from a Windows PC. Go to the
web address below to download and install Bonjour Print Services for Windows v2.0.2 or higher
http://support.apple.com/kb/DL999
2. Follow the prompts to install Bonjour Print Services
3. Find the Bonjour Printer Wizard shortcut on your or in the Desktop Start/All programs menu and click to launch


Product specificaties

Merk: Lantronix
Categorie: Printserver
Model: xPrintServer Home Edition
Kleur van het product: Wit
Ingebouwd display: Nee
Gewicht: 200 g
Breedte: 60.2 mm
Diepte: 114.3 mm
Hoogte: 21.6 mm
LED-indicatoren: Ja
Stroom: 1 A
Meegeleverde kabels: LAN (RJ-45)
Aantal USB 2.0-poorten: 1
Aantal Ethernet LAN (RJ-45)-poorten: 1
Aansluiting voor netstroomadapter: Ja
Duurzaamheidscertificaten: RoHS
Ethernet LAN, data-overdrachtsnelheden: 10, 100 Mbit/s
Netwerkstandaard: IEEE 802.3, IEEE 802.3u
Ondersteunt Windows: Ja
Temperatuur bij opslag: -40 - 70 °C
Intern: Nee
Power LED: Ja
Ondersteunde netwerkprotocollen: JetDirect / AppSocket, LPD, IPP
Ondersteunt Mac-besturingssysteem: Ja
Reset button: Ja
Externe adapter: Ja
Veiligheid: UL/EN 60950-1
Andere ondersteundende systemen: iOS
DHCP client: Ja
Minimale systeemeisen: AirPrint\r\nZeroconf\r\nMicrosoft Internet Explorer, V 8 / 9\r\nFirefox V 7\r\nSafari V 5\r\nChrome V 16
Koperen ethernetbekabelingstechnologie: 100BASE-TX, 10BASE-T
AC-ingangsspanning: 100-240 V
AC-ingangsfrequentie: 50 - 60 Hz
Stroomverbruik (typisch): 1 W
Bedrijfstemperatuur (T-T): 0 - 55 °C
Relatieve vochtigheid in bedrijf (V-V): 0 - 90 procent
Netwerkconnectietype: Ethernet LAN
IPP-ondersteuning: Ja
Standaard printertalen: PCL 4, PCL 5, PCL 6, PostScript 3
