Kramer Electronics, Ltd.
USER MANUAL
Model:
VP-200
XLN
XGA Line Amplifier / DA
Contents
i
Contents
1
Introduction 1
2
Getting Started 1
2.1
Quick Start 1
3
Overview 3
4
Your VP-200 XGA Line Amplifier / DA 4XLN
5
Connecting the VP-200 XGA Line Amplifier / DA 6XLN
6
Technical Specifications 7
Figures
Figure 1: VP-200 XGA Line Amplifier / DA 4XLN
Figure 2: VP-200 (Top Side Panel) 4XLN
Figure 3: VP-200 (Lower Side Panel) 4XLN
Figure 4: VP-200 XGA Line Amplifier / DA (Underside) 5XLN
Figure 5: Connecting the VP-200 XGA Line Amplifier / DA 6XLN
Tables
Table 1: VP-200 XGA Line Amplifier / DA Features 5XLN
Table 2: VP-200 XGA Line Amplifier / DA (Underside) Features 5XLN
Table 3: Technical Specifications of the VP-200 XGA Line Amplifier / DA 7XLN
Introduction
1
1 Introduction
Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video,
audio and presentation professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in 8 Groups
1
, which are clearly defined
by function. Congratulations on purchasing your Kramer TOOLS
VP-200
XLN
, which is ideal for: XGA Line Amplifier / DA
 Dual monitor systems, stores, and points of sale
 Presentation systems
The package includes the following items:
 VP-200
XLN
XGA Line Amplifier / DA
 Power adapter (12V DC Input) and this user manual
2
2 Getting Started
We recommend that you:
 Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
 Review the contents of this user manual
 Use Kramer high performance high resolution cables
3
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com


Product specificaties

Merk: Kramer
Categorie: Receiver
Model: VP-200XLN
Kleur van het product: Zwart
Gewicht: 300 g
Breedte: 120 mm
Diepte: 71.5 mm
Hoogte: 27.6 mm
LED-indicatoren: Ja
VGA (D-Sub) invoer ports: 1
Signaal/ruis-verhouding: 71 dB
Bandbreedte: 400 MHz
VGA (D-Sub) uitgang ports: 2
Maximum output niveau: 2 Vpp
Differentiele fase: 0.03 °
Differentiele winst: 0.05 procent
K-factor: 0.05 procent
