Kramer Electronics, Ltd.
Preliminary
USER MANUAL
Model:
VM-1120
1:10 Balanced Stereo Audio Distributor
Contents
i
Contents
1
Introduction 1
2
Getting Started 1
2.1
Quick Start 2
3
Overview 3
4
Your Balanced Stereo Audio Distributor 3
5
Installing the VM-1120 in a Rack 6
6
Connecting Your Balanced Stereo Audio Distributor 6
6.1
Connecting a 1:20 Mono DA 7
6.2
Connecting a 2x1:10 Mono DA 8
6.3
Connecting a 1:10 Stereo DA 9
6.4
Connecting a 2x1:5 Stereo DA 10
7
Setting the VM-1120 11
8
Technical Specifications 12
Figures
Figure 1: VM-1120 1:10 Balanced Stereo Audio Distributor 4
Figure 2: 1:20 Mono DA Configuration 7
Figure 3: 2x1:10 Mono DA Configuration 8
Figure 4: 1:10 Stereo DA Configuration 9
Figure 5: 2x1:5 Stereo DA Configuration 10
Figure 6: Using the Selector Button 11
Tables
Table 1: Front Panel VM-1120 1:10 Balanced Stereo Audio Distributor Features 5
Table 2: Rear Panel VM-1120 1:10 Balanced Stereo Audio Distributor Features 5
Table 3: VM-1120 Technical Specifications 12
Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups
1
that are clearly
defined by function.
Thank you for purchasing your Kramer VM-1120 1:10 Balanced Stereo
Audio Distributor.
This product is ideal for the following typical applications:
Audio duplication and production studios, delivering undiminished
quality duplicates
Recording studios
Broadcast studios for on-line signal distribution
The package includes the following items:
VM-1120 1:10 Balanced Stereo Audio Distributor
Power cord
2
This user manual
3
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
Review the contents of this user manual
Use Kramer high-performance high-resolution cables
4
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 We recommend that you use only the power cord supplied with this device
3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com


Product specificaties

Merk: Kramer
Categorie: Receiver
Model: VM-1120
Kleur van het product: Grijs
Gewicht: 3500 g
Breedte: 482.6 mm
Diepte: 177.8 mm
Connectiviteitstechnologie: Bedraad
Audio-uitgangskanalen: - kanalen
Signaal/ruis-verhouding: 89.3 dB
Totale harmonische vervorming (THD): 0.081 procent
XLR in: Ja
XLR out: 20
AC-ingangsspanning: 230 V
Piekvermogen per kanaal: - W
