Pagina 1/13

Kramer Electronics, Ltd.

Preliminary

USER MANUAL

Model:

TP-112HD

XGA/HD Line Transmitter - DA

Contents

1 1Introduction 

2 1Getting Started 

2.1Quick Start 2

3 3Overview 

3.1About the Power Connect™ Feature 3

3.2Shielded Twisted Pair (STP)/Unshielded Twisted Pair (UTP) 3

3.3About the TP-112HD 4

3.4Recommendations for Achieving the Best Performance 4

4 4Your TP-112HD XGA/HD Line Transmitter – DA 

5 6Configuring a 1:2 XGA/HD-to-Twisted Pair DA System 

5.1Wiring the CAT 5 LINE IN/LINE OUT RJ-45 Connectors 9

6 9Technical Specifications 

Figures

Figure 1: TP-112HD XGA/HD Line Transmitter – DA 5

Figure 2: TP-112HD (Top Side Panel) 5

Figure 3: TP-112HD (Lower Side Panel) 5

Figure 4: TP-112HD (Underside Panel) 6

Figure 5: Conﬁguring a 1:2 XGA/HD to Twisted Pair Transmitter/Receiver/DA 8

Figure 6: CAT 5 PINOUT 9

Tables

Table 1: TP-112HD XGA/HD Line Transmitter - DA Features 5

Table 2: TP-112HD (Underside Panel) Features 6

Table 3: CAT 5 PINOUT 9

Table 4: Technical Specifications of the TP-112HD (with 100m CAT 5 cable) 9

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups

1 that are clearly

defined by function.

Thank you for purchasing the Kramer TOOLS: TP-112HD XGA/HD Line

Transmitter - DA, which is ideal for:

• Presentation and multimedia applications

• Long range graphics distribution for schools, hospitals and stores

The package includes the following:

• TP-112HD XGA/HD Line Transmitter - DA

• Power supply (12V DC)

• This user manual2

2 Getting Started

We recommend that you:

• Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

• Review the contents of this user manual

• Use Kramer high performance high-resolution cables3

1 GROUP 1: Distribution Ampliﬁers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Product specificaties

Merk:	Kramer
Categorie:	Receiver
Model:	TP112-HD
Kleur van het product:	Zwart
Gewicht:	300 g
Breedte:	120 mm
Diepte:	71.5 mm
Hoogte:	27.6 mm
VGA (D-Sub) invoer ports:	1
Ingangsspanning:	12 V
Signaal/ruis-verhouding:	65 dB
RJ-45 uitgang ports:	2
Bandbreedte:	- MHz
Maximum output niveau:	1.7 Vpp
Differentiele fase:	0.3 °
Differentiele winst:	4 procent
