Kramer Electronics, Ltd.
USER MANUAL
Models:
PT-102AN,
1:2 Audio DA
PT-102SN,
1:2 s-Video DA
Contents
i
Contents
1
Introduction 1
2
Getting Started 1
2.1
Quick Start 1
3
Overview 3
3.1
About the PT102AN 1:2 Audio DA 3
3.2
About the PT-102SN 1:2 s-Video DA 3
4
Your 1:2 Distribution Amplifier 4
4.1
Your PT-102AN 1:2 Audio DA 4
4.2
Your PT-102SN 1:2 s-Video DA 5
5
Connecting the 1:2 Distribution Amplifier 5
5.1
Connecting the PT-102AN 1:2 Audio DA 6
5.2
Connecting the PT-102SN 1:2 s-Video DA 7
5.3
Increasing the Number of Inputs/Outputs 8
6
Technical Specifications 9
Figures
Figure 1: PT-102AN 1:2 Audio DA 4
Figure 2: PT-102SN 1:2 s-Video DA 5
Figure 3: Connecting the PT-102AN 1:2 Audio DA 6
Figure 4: Connecting the PT-102SN 1:2 s-Video DA 7
Figure 5: Increasing the Inputs 8
Figure 6: Increasing the Outputs 8
Tables
Table 1: Features and Functions of the PT-102AN 1:2 Audio DA 4
Table 2: Features and Functions of the PT-102SN 1:2 s-Video DA 5
Table 3: Technical Specifications of the PT-102AN / PT-102SN 9
Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups
1
that are clearly defined
by function.
Congratulations on purchasing your Kramer , PT-102AN 1:2 Audio DA
and/or which are ideal for: PT-102SN 1:2 s-Video DA
Audio/video duplication studios
Retail showrooms, home theater systems
CCTV and security systems
Each package includes the following items:
1:2 DA ( or ) PT-102AN PT-102SN
Power adapter (12V DC Input) and mounting bracket
This user manual
2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables
3
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories
and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
Product specificaties
| Merk: | Kramer |
| Categorie: | Receiver |
| Model: | PT-102SN |
| Kleur van het product: | Zwart |
| Gewicht: | 140 g |
| Breedte: | 62.2 mm |
| Diepte: | 51.8 mm |
| Hoogte: | 24.4 mm |
| S-Video ingang: | 1 |
| Ingangsspanning: | 12 V |
| Signaal/ruis-verhouding: | 76 dB |
| S-Video uitgang: | 2 |
| Bandbreedte: | 150 MHz |
| Differentiele fase: | 0.05 ° |
| Differentiele winst: | 0.05 procent |
| K-factor: | 0.05 procent |
