1
ERECTION INSTRUCTIONS
ALBERTA
BEFORE USE
PLEASE TAKE TIME TO READ AND UNDERSTAND THE ERECTION INSTRUCTIONS.
FAILURE TO ERECT THE TENT IN ACCORDANCE WITH THE INSTRUCTIONS MAY
RESULT IN DAMAGE TO BOTH FABRIC AND POLE SYSTEMS. SUCH DAMAGE
CANNOT BE COVERED BY THE WARRANTY.
WARNING!!
DO NOT PUSH TENT PEGS IN BY HAND, ALL TENT PEGS SHOULD BE DRIVEN HOME
USING A WOODEN OR RUBBER FACED MALLET OR SIMILAR TOOL.
TO ENSURE MAXIMUM POSSIBLE WATERPROOFING THE MAIN FLY SHEET SEAMS
HAVE BEEN TAPED. SHOULD THE TAPE BE DAMAGED AND PEEL AWAY YOU CAN
EFFECT A REPAIR BY USING SEAM SEALER AROUND THE PROBLEM AREA.
WE ALSO RECOMMEND THAT SEEM SEALER IS APPLIED TO UNTAPED SEEMS TO
PREVENT LEAKAGE.
IT IS IMPORTANT THAT YOU DO NOT ALLOW SEAM SEALER TO CONTAMINATE THE
TEETH OF ANY ZIPS AS THIS WILL PREVENT THE ZIP FROM FUNCTIONING CORRECTLY.
IF YOU DO USE SEAM SEALER IT IS BEST APPLIED WHEN THE TENT IS DRY. PICK A DRY
WARM DAY TO CARRY OUT ANY SEALING AND PLEASE ALLOW 48 HOURS FOR THE
SEALANT TO CURE PRIOR TO RE-PACKAGING THE TENT.
FAILURE TO ALLOW THE SEALANT TO DRY FULLY PRIOR TO PACKING THE TENT UP
WILL STICK THE FABRIC TOGETHER POSSIBLY CAUSING IRREPARABLE DAMAGE.
DURING USE
TENTS CONTAINING A HIGH PROPORTION OF SYNTHETIC MATERIALS ARE SOMETIMES
AFFECTED BY CONDENSATION, THIS SHOULD NOT BE CONFUSED WITH LEAKAGE AND
CAN USUALLY BE CURED BY ENSURING THAT ADEQUATE VENTILATION IS
AVAILABLE BY LEAVING DOORWAYS SLIGHTLY UNZIPPED WHEREVER POSSIBLE.
DO NOT PITCH UNDER TREES, MAKE USE OF NATURAL WIND BREAKS LIKE HEDGES
OR WALLS, FACE THE TENT DOOR AWAY FROM THE PREVAILING WIND. USE TWO
HANDS WHEN OPENING AND CLOSING ZIPS, THIS WILL HELP PREVENT PREMATURE
ZIP FAILURE.
READ AND UNDERSTAND THE FIRE PRECAUTIONS INFORMATION ATTACHED TO THE
INSIDE OF THE TENT.
CARE OF YOUR TENT WARNING!!
TENT FABRICS CAN BE WEAKENED BY PROLONGED EXPOSURE TO SUNLIGHT, UNDER
NORMAL HOLIDAY USE YOUR TENT WILL GIVE YOU LONG SERVICE BUT ERECTION
FOR EXTENDED PERIODS IN STRONG SUNLIGHT WILL CAUSE DETERIORATION.
IF YOU ARE LIKELY TO USE YOUR TENT FOR PROLONGED PERIODS IT WOULD BE WISE
TO USE A SITE WHICH IS A SHADED AS POSSIBLE.
TENTS ARE BEST STORED OPENED OUT, IF THIS IS NOT POSSIBLE AIR FULLY AND
ENSURE IT IS TOTALLY DRY BEFORE PACKING IT AWAY AT THE END OF YOUR
HOLIDAY.
STORE YOUR TENT IN A WELL VENTILATED DRY PLACE. LOOK AFTER YOUR TENT
AND IT WILL LOOK AFTER YOU.
HAVE ANY DAMAGE TO YOUR TENT REPAIRED AT FIRST OPPORTUNITY.
2
FAILURES IN FIBERGLASS POLES NORMALLY OCCUR THROUGH INCORRECT USE,
MAKE SURE THE POLE SECTIONS ARE FULLY INSERTED INTO THEIR ADJOINING
FERULES AND DO NOT OVER STRESS THE POLE BEYOND IT’S DESIGNED CURVE. ZIPS
SHOULD BE TREATED WITH CARE TO PREVENT PREMATURE FAILURE AND THE TENT
SHOULD BE KEPT CLEAN AND DRY AFTER USE.
INSURANCE
WE HIGHLY RECOMMEND THAT YOUR TENT BE INSURED AGAINST THEFT AND STORM
OR ACCIDENTAL DAMAGE. STORM OR ACCIDENTAL DAMAGE IS NOT COVERED BY
THE WARRANTY.
CHECK YOUR EQUIPMENT BEFORE GOING AWAY WITH YOUR TENT. ENSURE THAT
YOU ARE FAMILIAR WITH THE PITCHING OF THE TENT AND THAT ALL PARTS ARE
PRESENT.
YOU SHOULD FAMILIARIZE YOURSELF WITH THE TENT, INCLUDING ANY
LIMITATIONS THAT IT MAY HAVE FOR YOUR PARTICULAR USE.
DOME TENTS ARE PORTABLE STRUCTURES WHICH UNDER MOST CIRCUMSTANCES
WILL PROVIDE COMFORTABLE SHELTER AGAINST THE ELEMENTS. THERE ARE
HOWEVER EXTREMES OF WEATHER FOR WHICH ALLOWANCES SHOULD BE MADE.
DO NOT BLAME THE TENT !
ERECTING YOUR TENT
PLEASE NOTE THE ALBERTA IS A LARGE TENT AND WE RECOMMEND IT IS
ERECTED BY A MINIMUM OF TWO ADULTS.
1: REMOVE THE CONTENTS OF THE CARRY BAG AND IDENTIFY ALL THE COMPONENT
PARTS.
• INNER TENT
• FLYSHEET
• POLE BAG AND CONTENTS
• PEG BAG AND CONTENTS
2: SELECT A SITE THAT IS CLEAR OF ANY SHARP OBJECTS, STICKS AND STONES E.T.C
3: IN THE POLE BAG, THERE SHOULD BE FIVE SETS OF MAIN SHOCKCORDED
FIBERGLASS POLES. THERE WILL ALSO BE TWO SMALLER THINNER SETS OF
SHOCKCORDED FIBREGLASS POLES.
ALL POLES WILL BE MARKED WITH A COLOURED STICKER, THIS WILL CORRESPOND
TO A COLOURED TRIM ON THE EDGE OF THE SLEEVE THAT THE POLE IS INTENDED TO
FIT THROUGH. IT IS BEST TO START AT ONE END OF THE FLYSHEET AND WORK
TOWARDS THE OPPOSITE END OF THE TENT, SO IT MAY BE USEFUL TO INDENTIFY
POLE AND SLEEVE COLOURS AND POSITION THE POLES ALONG SIDE THE TENT IN THE
CORRECT ORDER.
4: UNFOLD THE FLYSHEET AND SPREAD OUT ON THE FLOOR SO YOU ARE ABLE TO SEE
THE SLEEVE SECTIONS OF THE ROOF.
AS THIS TENT HAS A SEWN IN GROUNDSHEET IT WILL MAKE IT EASIER TO ERECT IF YOU
OPEN THE TWO DOORS ON THE TENT. THIS WILL ALLOW ARE TO FLOW FREELY INTO THE
TENT AS YOU ERECT IT.
5: STARTING WITH THE POLES THAT RUN ACROSS THE TENT FROM SIDE TO SIDE
CHOOSE ONE END OF ONE POLE AND ENGAGE THE END FERRULE INTO THE POLE
RETAINING FIXTURE OR EYELET. THIS WILL BE LOCATED AT THE BASE OF THE
FLYSHEET, NEAR TO THE SEAM RUNNING DOWN FROM THE SLEEVE, IN WHICH THE
3
POLE IS LOCATED. EACH POLE RETAINING FIXTURE WILL HAVE A METAL RING WITH
ONE OR MORE RETAINING PINS ATTACHED TO IT (DEPENDANT UPON MODEL) THE
RETAINING PIN IS DESIGNED TO SLIDE UP INSIDE THE POLE ENDS THUS SECURING THE
POLE INTO PLACE.
FROM THE OPPOSITE END OF THE SAME POLE CAREFULLY PUSH THE REMAINING
POLE THROUGH THE SLEEVES SO IT ASSUMES A SEMI-CIRCULAR SHAPE. WHEN THE
END FERRULE IS LEVEL TO THE POLE RETAINING FIXTURE OR EYELET ON THIS SIDE,
ENGAGE IT INTO PLACE AS BEFORE. PLEASE NOTE ON SOME MODELS THERE MAY BE
AN ADJUSTABLE WEBBING LOOP CONNECTING THE RING TO THE BASE OF THE
FLYSHEET. THIS LOOP SHOULD BE OPENED UP TO ITS FULL LENGTH WHILE ENGAGING
THE PIN ON THE RING INTO THE POLE END. ONCE THE PIN IS INSERTED THE WEBBING
LOOP CAN BE TIGHTENED SO THE POLE IS FIRMLY LOCKED INTO THE POLE END.
ENSURE CARE IS TAKEN DURING THIS PROCEDURE, NOT TO ALLOW THE ENDS OF THE
SHOCKCORDED POLES TO DAMAGE SLEEVES OR FLYSHEET MATERIAL.
RUNNING DOWN THE SEAM, FROM THE SLEEVE, ON EACH SIDE OF THE TENT YOU
WILL NOTICE THREE FLYSHEET TO MAIN POLE WEBBING CLIPS. ALL THESE, SHOULD
SIMPLY BE CLIPPED TO THE MAIN SHOCKCORDED POLES ALLOWING THE FLYSHEET
TO TAKE FULL SHAPE. PLEASE NOTE THAT THESE ARE NOT INTENDED AS GUY POINT
FIXINGS.
6: TAKING THE SECOND AND THIRD CROSSING POLES SEPARATELY REPEAT POINT 5.
IT IS BEST TO START AT ONE END OF THE FLYSHEET AND WORK TOWARDS THE
OPPOSITE END OF THE TENT, SO IT MAY BE USEFUL TO INDENTIFY POLE AND SLEEVE
COLOURS AND POSITION THE POLES ALONG SIDE THE TENT IN THE CORRECT ORDER.
7: WITH THE MAIN THREE CROSSING POLES IN POSITION, YOU CAN PEG THE TWO
PEGGING POINTS ON EACH END OF THE TENT INTO POSITION. PLEASE NOTE YOU MAY
NEED TO REPOSITION THESE LATER. BY PEGGING THEM TEMPORALLY NOW, IT WILL
HOLD THE MAIN PART OF THE TENT INTO SHAPE AND MAKE THE FITTING OF THE 2
CROSSING POLES EASIER.
NOW REPEAT POINT 5 ON THE 2 POLES RUNNING LENGTHWAYS ALONG THE ROOF
SECTION OF THE TENT.
DURING POINTS 4 TO 7 ENSURE THAT THE POLE JOINING FERRULES DO NOT CATCH ON
THE INSIDE OR EDGE OF THE MATERIAL SLEEVES. SHOULD THIS HAPPEN CAREFULLY
FREE THE SLEEVE BEFORE CONTINUING. FAILURE TO FREE THE SLEEVE MAY CAUSE THE
MATERIAL TO TEAR AND OR STITCHED SEAMS TO BURST
8: THE FLYSHEET SHOULD NOW BE READY FOR PEGGING. POSITION THE TENT SO
THAT THE DOORS ARE FACING AWAY FROM THE PREVAILING WIND.
IF YOU TEMPORALLY PEGGED ANY GUY ROPES EARLIER ON, THEN PLEASE CHECK IF
THESE NEED TO BE REPOSITIONED.
ENSURE THAT THE OVERALL LAY OF THE FLYSHEET IS SMOOTH WHEN PEGGED. THE
FLYSHEET SHOULD BE TAUGHT, BUT NOT OVER-TENSIONED, AS THIS WILL ONLY
DISTORT THE FIBERGLASS POLES AND SUBSEQUENTLY AFFECT STABILITY.
YOU MAY FIND IT NECESSARY TO ADJUST THE POSITION OF THE TWO END PEGGING
POINTS IN ORDER TO GET THE OVERALL LAY OF THE FLYSHEET FABRIC SMOOTH AND
FREE FROM WRINKLES OR FOLDS.
ONCE YOU ARE SATISFIED WITH THE OVERALL LAY OF THE FLYSHEET YOU CAN
THEN AND ONLY THEN PEG THE REMAINING PEGGING LOOPS INTO POSITION.
