SUB10 (120V)

JBL VENUE™

OWNER’S GUIDE

READ FIRST! Important Safety Precautions!

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings.

Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such

as radiators, heat registers, stoves or other

apparatus (including amplifiers) that produce

heat.

9. Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized

plug has two blades with one wider than the

other. A grounding-type plug has two blades

and a third grounding prong. The wide blade

or the third prong are provided for your safety

If the provided plug does not fit into your out-

let, consult an electrician for replacement of

the obsolete outlet.

10. Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles and the point

where they exit from the apparatus.

11.

Only use attachments/accessories

specified by the manufacturer.

12. Use only with the cart, stand, tripod,

bracket or table specified by the

manufacturer or sold with the

apparatus. When a cart is used,

use caution when moving the

cart/apparatus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lightning

storms or when unused for long periods

of time.

14. Refer all servicing to qualified service

personnel. Servicing is required when the

apparatus has been damaged in any way,

such as power-supply cord or plug is dam-

aged, liquid has been spilled or objects have

fallen into the apparatus, the apparatus has

been exposed to rain or moisture, does not

operate normally, or has been dropped.

15. Do not use attachments not recommended

by the product manufacturer, as they may

cause hazards.

16. This product should be operated only

from the type of power source indicated on

the marking label. If you are not sure of the

type of power supply to your home, consult

your product dealer or local power company.

For products intended to operate from bat-

tery power or other sources, refer to the

operating instructions.

17. If an outside antenna or cable system

is connected to the product, be sure the

antenna or cable system is grounded so as

to provide some protection against voltage

surges and built-up static charges. Article

810 of the National Electrical Code, ANSI/

NFPA 70, provides information with regard to

proper grounding of the mast and supporting

structure, grounding of the lead-in wire to

an antenna discharge unit, size of grounding

conductors, location of antenna-discharge

unit, connection to grounding electrodes, and

requirements for the grounding electrode.

See Figure A.

18. An outside antenna system should not be

located in the vicinity of overhead power

lines or other electric light or power circuits,

or where it can fall into such power lines or

circuits. When installing an outside antenna

system, extreme care should be taken to keep

from touching such power lines or circuits, as

contact with them might be fatal.

19. Do not overload wall outlets, extension

cords, or integral convenience receptacles,

as this can result in a risk of fire or electric

shock.

20. Never push objects of any kind into this

product through openings, as they may touch

dangerous voltage points or short-out parts,

which could result in a fire or electric shock.

Never spill liquid of any kind on the product.

21. The apparatus shall not be exposed to

dripping or splashing, and no objects filled

with liquids, such as vases, shall be placed

on the apparatus.

22. Do not attempt to service this product

yourself, as opening or removing covers may

expose you to dangerous voltage or other

hazards. Refer all servicing to qualified

service personnel.

23. When replacement parts are required,

be sure the service technician has used

replacement parts specified by the manufac-

turer or that have the same characteristics

as the original part. Unauthorized substitu-

tions may result in fire, electric shock or

other hazards.

24. Upon completion of any service or repairs

to this product, ask the service technician to

perform safety checks to determine that the

product is in proper operating condition.

25. The product should be mounted to a

wall or ceiling only as recommended by

the manufacturer.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock, 

do not remove cover (or back). 

No user-serviceable parts inside. 

Refer servicing to qualified service personnel.



CAUTION: To prevent electric shock,

do not use this (polarized) plug with 

an extension cord, receptacle or other outlet 

unless the blades can be fully inserted to 

prevent blade exposure.



T he lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

a lert the user to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute 

a risk of electric shock to persons.

Figure A.

Example of Antenna Grounding as per

National Electrical Code ANSI/NFPA 70

JBL®SUB10 Powered Subwoofer

For more than 60 years, JBL has been providing audio equipment to concert

halls, recording studios and movie theaters around the world, and has become

the hands-down choice of leading recording artists and sound engineers.

With the JBL Venue™Series, innovative technologies such as titanium-

laminate-dome tweeters, EOS

™waveguides and PolyPlas™transducer

reinforcement are available to you. Enjoy!

Unpacking the Subwoofer

If you suspect damage from transit, report it immediately to your dealer. Keep

the shipping carton and packing materials for future use.

PLACEMENT

Since the installation of a subwoofer can be somewhat more complicated than

installation of full-range speakers, it is essential that you read this section very

carefully prior to connecting the subwoofer to your system. Should you have

questions relating to your installation, it is advisable to call either your dealer

or JBL’s Customer Service Department for advice.

The performance of the subwoofer is directly related to its placement in the

listening room and how you align the subwoofer with its satellite speakers.

Setting the volume of the subwoofer in relationship to the left and right speakers

is also of critical importance because it is essential that the subwoofer inte-

grate smoothly with the entire system. Setting the subwoofer’s volume level

too high will result in overpowering, boomy bass. Setting the volume level too

low will negate the benefits of the subwoofer.

Here are several additional facts on installation that may prove useful.

It is generally believed by most audio authorities that low frequencies (below

125Hz) are nondirectional and, therefore, placement of a subwoofer within any

listening room is not critical. While in theory it is true that the larger wave-

lengths of extremely low frequencies are basically nondirectional, the fact is

that, when installing a subwoofer within the limited confines of a room, reflec-

tions, standing waves and absorptions generated within the room will strongly

influence the performance of any subwoofer system. As a result, specific

location of the subwoofer becomes important, and we strongly recommend

that you experiment with placement before choosing a final location.

Placement will depend upon your room and the amount and quality of bass

required (for example, whether or not your room permits placement of the

subwoofer near either satellite).

Figure 1. This example shows the subwoofer positioned behind the

right-channel satellite speaker to re-create the actual location of

bass instruments in an orchestra and/or add impact to

movie soundtracks.

SUB

RIGHT-

CHANNEL

SPEAKER

PRIMARY

LISTENING

AREA

INTRODUCTION
