JBL SYNTHESIS®
SDA8300
SDA4600
AMPLIFIER
SYSTEM INSTALLATION GUIDE
May, 2014
P/N 070-90018 (rev A.0)
2 | J B L S y n t h e s i s S D A 8 3 0 0 / S D A 4 6 0 0 S y s t e m G u i d e
Read Me First!
IF YOU READ NOTHING ELSE IN THIS GUIDE READ THIS INFORMATION:
The SDA ampliî…·ers come pre-conî…·gured to work with the SDEC4500P using
the BLU-LINK digital audio signal over Cat5e Ethernet cables. The ampliî…·ers
should not be connected to the home network. Analog Audio input comes
IN on the SDEC4500P (up to 12 channels) and OUT on the SDA8300 and/or
SDA4600 without going through any Digital to Analog conversions (up to 20
Channels as standard, expandable to 128 channels).
Two alternate conguraons are selected by using the included selecon
trigger that plugs into the GPIO input on the rear panel. These are labeled
“Conguraon 2” and “Conguraon 3” on the plug.
The SDA8300 ampliî…·er ships conî…·gured for a simple 7-channel system. The
SDA8300 can access two (2) addional conguraons. Using combinaons
of these conguraons allows the system to output from a simple 7 x 300
Wa system to up to 16 x 300 Was with discrete DSP for each channel
with acve bi-amp outputs on the Le-Center-Right.
The SDA4600 ships congured for a 4-channel subwoofer (4 x 600 Was).
Up to two (2) addional conguraons can be accessed for bridged high
power subwoofers outputs (2 x 1200 Was with discrete channel DSP for )
each output. These are used with the Harman Patented “Sound Field
Management” in the SDEC4500P.
The controls all DSP and -AMP speaker crossover sengs and SDEC-4500P BI
must be congured with either “JBL Synthesis ARCOS” soware or “SDEC
Control Panel Soware v1.5 Go to ”. www.jblsynthesis.com to download the
correct soware.
The ONLY inputs into the SDA ampliî…·ers should be from the Cat5e cable
connected to the BLU-Link In/Out. Analog inputs are provided as a backup
only and is not recommended. DO NOT USE BOTH BLU-LINK AND ANALOG
AS UNEXPECTED RESULTS CAN OCCUR.
DO NOT CONNECT THE AMPLIFIER TO THE HOME NETWORK. THE NETWORK
CONNECTION IS FOR ADVANCED SETUP AND MONITORING. THERE ARE NO
USER CONTROLLABLE FUNCTIONS FROM THE NETWORK. ONLY THE BLU-
LINK SIGNAL CHAIN MUST BE CONNECTED USING STANDARD CAT5E
ETHERNET CABLES.
Step by Step Setup Guide. Detailed instrucons are on the next pages.
1. Connect Preamp/Surround Processor and SDEC4500P
2. Connect Blu-Link Digital Audio Link from SDEC4500P to SDA
Ampliî…°er(s) using standard Ethernet Cat5e cables
3. [Oponal] Connect Powered Subwoofers to SDEC4500P
4. Setup of SDA8300 for Single (8-channel) or Dual unit (16-
channel) conguraon and connect speakers
5. Setup of SDA4600 for Single (4-channel x 600 W) or Bridged
(2-Channel x 1200 W) or Bridged Dual unit conguraon and
connect subwoofers
Accessories
Power cords (North America and EU)
Rack screws
Analog input screw down connectors
Speaker Terminal crimp connectors
Rear Rack Rail support
Sleep trigger 3-conductor screw down connector
SDA4500XLRIC interconnect kit [PURCHASED SEPARATELY]
Auto Standby / Auto Turn On
The ampliî…·ers will go to low power standby if any channel does not receive
signal for more than 30 minutes. The individual Channel Ready light will
blink green in standby. This is on a PER CHANNEL basis. The ampliî…·er will
Auto Turn On when the signal returns above -60db in level and the Channel
Ready light will stay solid green.
Sleep Mode
This is a CONTACT CLOSURE. Only use with dry contact closure from control
systems. The amplier can be put to sleep by connecng pins 1 and 2 on the
AUX port. When applying this connecon, the amplier will shut down and
remain in sleep unl the connecon between pins 1 and 2 is open. While
the amplier is in sleep, the front panel power buon is disabled. When the
connecon between pins 1 and 2 is open, the amplier will revert to its last
conguraon and begin to output audio within 20 seconds.
3 | J B L S y n t h e s i s S D A 8 3 0 0 / S D A 4 6 0 0 S y s t e m G u i d e
Standard System [i.e., Syn-2-Array / Syn-3-Array / Syn-4 / or Similar]
Typical STANDARD system conguraon. Factory Defaults. DO NOT
INSERT THE CONFIGURATION JUMPERS. Standard systems support 7.4
with the to acve bi-amplify the Center Channel. opon
Expanded Systems [i.e., Syn-Everest / Syn-K2 / Syn-Atlas / Syn-1-Array]
Fully expanded system using Conguraon 2 and Conguraon 3 for 13.4
Channel system. Front Le-Center-Right have the opon to be bi-wired or
acvely bi-amplied.
Conguraon 2
Conguraon 2
Conguraon 3
Conguraon 3
Cong aon
Cong aon
SDA8300 #1
SDA8300 #2
SDA4600 #1
SDA4600 #2
SDA8300 #1
SDA4600 #1
SDEC-4500P
SDP PREAMP
SDEC-4500P
SDP PREAMP
