Pagina 1/2
FS1000
®
A Harman International Company
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797 www.jbl.com
© 2005 Harman International Industries, Incorporated. All rights reserved.
JBL is a registered trademark of Harman International Industries, Incorporated.
Part No. 406-000-05066
®
Speakers not included.
2.
1.
3.
2.
1.
2.
5.
3.
4.
1.
Included
For use…
…with all JBL
SCS200,
SCS260,
SCS30 and0
DSC systems
...with all JBL
SCS115,
SCS125,
SCS135,
SCS136,
SCS138,
SCS140,
SCS145,
SCS146,
SCS150,
SCS160,
SCS180
and ESC
systems
1. Assembly
1. Insert the
loudspeaker wire
through the cable
hole at the rear of
the top of the
upright. Feed the
wire through the
upright, all the
way down. Leave
approximately
20cm (8") of wire
out of the top of
the stand.
2. Lead the wire
through the hole
in the foot of the
stand. Place the
stand upright in
the foot and use
the supplied
screws to fit the
stand to the foot.
Note that the
stand upright
needs to be
inserted in such
a way that the
side of the foot
with the JBL logo
is facing forward
and the side of
the stand upright
with the hole on
the top is facing
toward the rear
of the stand foot.
2. Attach speaker
Depending on which speakers you would like to attach,
follow the steps below.
1. Attach the
stand adaptor
on the top of
the stand
upright as
shown. Note
that the side
with the pins
needs to be
toward the rear of the stand pole.
Fasten the adaptor to the stand
upright with the screw supplied.
2. Connect the loudspeaker wire to the
loudspeaker, respecting the polarity
(“+” and “–”; refer to the owner’s
manual of your loudspeakers).
3. Place the loudspeaker securely on
the stand, using the locating pin.
1. t the standInser
adaptor inside
the top of the
stand upright, as
shown in the image.
2. Take the bracket and
make sure that the
locking ring on the
bottom of the bracket
is rotated all the way up.
3. Screw the bracket into the adaptor
in the stand upright. Just before
the bracket has been screwed in
completely, position the bracket so that
the closed side is facing rearward.
Rotate the locking ring on the bottom
of the bracket down to tighten the
bracket to the stand.
4. Take the loudspeaker wire, and split
the two leads. Insert the two leads
through the hole on the back of the
bracket. Connect the loudspeaker wire
to the loudspeaker, respecting the
polarity (“+” and “–”; refer to the
owner’s manual of your loudspeakers).
5. Attach the loudspeaker to the bracket,
using the supplied screws.
SCS200, SCS260,
SCS300 and DSC
SCS115, SCS125, SCS135, SCS136,
SCS138, SCS140, SCS145, SCS146,
SCS150, SCS160, SCS180
and ESC variants
For more than 55 years, JBL has been involved in every aspect of music and film recording and reproduction, from live performances to the recordings you
play in your home, car or office. We’re confident that the JBL products you have chosen will provide every note of enjoyment that you expected – and that
when you think about purchasing additional audio equipment for your home, car or office, you will once again choose JBL.
JBL Consumer Products
