Pagina 1/24

Compact Powered Subwoofer

M TODEL WELVE

Owner’s Guide

(120V)

ii Cascade Model Twelve

Read First!

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as

radiators, heat registers, stoves or other apparatus

(including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the

polarized or grounding-type plug.A polarized plug

has two blades with one wider than the other. A

grounding-type plug has two blades and a third

grounding prong.The wide blade or the third

prong are provided for your safety. If the provided

plug does not fit into your outlet, consult an

electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on

or pinched, particularly at plugs, convenience

receptacles and the point wher they exit from thee

apparatus.

11. Only use attachments/accessories specified by

the manufacturer.

12. Use only with the cart, stand,

tripod, bracket or table specified

by the manufacturer or sold with

the apparatus. When a cart is

used, use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms

or when unused for long periods of time.

14. Refer all servicing to qualified service

personnel. Servicing is required when the

apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain

or moisture, does not operate normally, or has

been dropped.

15. Do not use attachments not recommended by

the product manufacturer, as they may cause

hazards.

16. This product should be operated only from the

type of power source indicated on the marking

label. If you are not sure of the type of power

supply to your home, consult your product dealer

or local power company. For products intended to

operate from battery power, or other sources,

refer to the operating instructions.

17. If an outside antenna or cable system is

connected to the product, be sure the antenna or

cable system is grounded so as to provide some

protection against voltage surges and built-up

static charges. Article 810 of the National

Electrical Code,ANSI/NFPA 70, provides

information with regard to proper grounding of

the mast and supporting structure, grounding of

the lead-in wir to an antenna discharge unit, sizee

of grounding conductors, location of antenna

discharge unit, connection to grounding

electrodes, and requirements for the grounding

electrode. See Figure A.

18. An outside antenna system should not be

located in the vicinity of overhead power lines

or other electric light or power circuits, or where

it can fall into such power lines or circuits. When

installing an outside antenna system, extreme

care should be taken to keep from touching such

power lines or circuits, as contact with them

might be fatal.

19. Do not overload wall outlets, extension cords,

or integral convenience receptacles, as this can

result in a risk of fire or electric shock.

20. Never push objects of any kind into this

product through openings, as they may touch

dangerous voltage points or short-out parts that

could result in a fire or electric shock. Never

spill liquid of any kind on the product.

21. Do not attempt to service this product

yourself, as opening or removing covers may

expose you to dangerous voltage or other hazards.

Refer all servicing to qualified service personnel.

22. When replacement parts are required, be sure

the service technician has used replacement

parts specified by the manufacturer or that have

the same characteristics as the original part.

Unauthorized substitutions may result in fire,

electric shock or other hazards.

23. Upon completion of any service or repairs

to this pr ask the service technician tooduct,

perform safety checks to determine that the

product is in proper operating condition.

24. The product should be mounted to a wall or

ceiling only as recommended by the manufacturer.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock, 

do not remove cover (or back). 

No user-serviceable parts inside. 

Refer servicing to qualified service personnel.



CAUTION: To prevent electric shock,

do not use this (polarized) plug with 

an extension cord, receptacle or other outlet 

unless the blades can be fully inserted to 

prevent blade exposure.



The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute 

a risk of electric shock to persons.

Figure A.

Example of Antenna Grounding as per

National Electrical Code ANSI/NFPA 70

IMPORTANT AFETY RECAUTIONSS P

iii

Cascade Model Twelve

Table of Contents

ii Important Safety Precautions

1Unpacking the Subwoofer

1Placement

2Controls and Connections

3Connections

4Operation

5Room Adaptive Bass Optimization System

™(R.A.B.O.S.

™)

6Contents of the R.A.B.O.S.Test CD

6The R.A.B.O.S. Sound-Level Meter (RSLM)

7Initial System-Level Setting

7Setting the Subwoofer Test Level

7Performing Low-Frequency Measurements

9What Does a Parametric Equalizer Do?

9Completing the Measurement Template

10 Using the Width Selector

11 Level

11 What You Measure, What to Do

14 Adjusting the R.A.B.O.S. Equalizer

15 Final System Balance

16 Maintenance and Service

17 R.A.B.O.S. Measurement Templates

19 Specifications

C M TASCADE ODEL WELVE WNERO’S UIDEG
