Quick Guide

CONTROL PANEL

1. ON/OFF button

2. START/PAUSE button with indicator light

3. WASH CYCLE PROGRESS indicator lights

4. DOOR LOCKED indicator light

5. FUNCTION buttons with indicator lights

6. DRYING ONLY button with indicator light

7. button DRYING LEVELS

8. TIME DRYING button

9. TEMPERATURE button

10. WASH CYCLE knob

11. PUSH & GO button

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump

7. Adjustable feet (4)

THANK YOU FOR BUYING A INDESIT PRODUCT

In order to receive a more complete assistance,

please register your product on

www.indesit.com/register

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed.

For more detailed instructions on how to remove them, see the Installation Guide.

DETERGENT DISPENSER DRAWER

Compartment 1:

Do not insert detergent in this compartment.

Compartment 2: Washing detergent (powder

or liquid)

Compartment 3: Additives (fabric softener, etc.)

The fabric softener must never exceed the

“max” level indicated on the central pin.

! Use powder detergent for white cotton

garments, for pre-washing, and for washing at

temperatures over 60°C.

! Follow the instructions given on the detergent

packaging.

Maximum load 8 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Drying

Maximum

load for dry-

ing (Kg)

Detergents and

Additives Recommended

detergent

Residual

dampness % (*)

Energy

consumption kWh

Total water lt

Laundry

temperature °C

Wash cycle

Temperature Maximum

spin

(r.p.m.)

Maxi-

mum

load for

washing

(Kg)

Dura-

tion

(h : m)

Wash Fabric

softener

Powder Liquid

Setting Range 2 3

1 Mixed 40°C – 40°C 1000 8,0 1:00 6,0   –– – – –

2 Cotton (2) 40°C – 60°C 1400 8,0 3:55 6,0     49 1,40 105 40

3 Synthetics (3) 40°C – 60°C 1400 4,0 2:55 4,0     35 0,80 55 43

4 White 60°C - 90°C 1400 8,0 2:45 6,0     49 0,90 90 55

5 Colours 40°C – 40°C 1400 8,0 1:50 6,0   –– – – –

6Eco 40-60 (1)

(Wash) 40 °C 40°C

1351 8,0 3:38 6,0     53 0,73 56 34

1351 4,0 2:48 3,0     53 0,55 53 34

1351 2,0 2:25 -    53 0,35 35 23

7 Sport 40°C – 40°C 600 3,5 1:35 3,5   –– – – –

8 20°C 20 °C - 20 °C 1400 8,0 1:50 6,0   –49 0,20 90 22

9 Anti Odour 40°C - 40°C 1000 3,5 1:45 3,5     – – – –

10 Delicates 30°C – 30°C 600 (**) 1 1:20 1  –– – – –

11 Wool 40°C – 40°C 800 2 1:10 2  –– – – –

12 Rapid 30’ 30°C – 30°C 1000 (**) 4,5 0:30 - -   –71 0,20 45 27

13 Wash&Dry 45 min 30°C – 30°C 1400 1 0:45 1  –– – – –

14 Air Fresh - - - - 0:30 - - - - - – – – –

Rinse + Spin - - 1400 8,0 0:55 6,0 - - - – – – –

Spin + Drain - - 1400 8,0 0:10 6,0 - - - - – – – –

  Required dosage Optional dosage

6Eco 40-60 (4)

(Wash&Drying) 40 °C 40°C 1351 6,0 9:20 6,0     0 3,80 75 33

1351 3,0 5:10 3,0     0 1,98 47 32

For all testing institutes:

2) Long cotton programme: set the “2“ programme with a temperature of 40°C.

3) Synthetic program along: set the “3“ programme with a temperature of 40°C.

After programme end and spinning with maximum selectable spin speed, in default

programme setting.

** The display will show the suggested spin speed as default value.

Note: for the Eco 40-60 program in the WASH CYCLE TABLE the value of the maximum eective

spin is shown.

This data may dier in your home due to changing conditions in inlet water temperature,

water pressure etc. Approximate programme duration values refer to the default setting of

the programmes, without options.

The values given for programmes other than the Eco 40-60

programme are indicative only.

For all Test Institutes

1) Eco 40-60 (Wash)- Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most

efficient programme in terms of energy and water consumption for washing normally soiled cotton

laundry.

4) Eco 40-60 (Wash&Drying)-

Test

wash&

drying cycle in compliance with EU Ecodesign

regulation

2019/2014

. To access “wash and dry” cycle select “Eco 40-60” wash programme

and set “Drying” option level to

“ ”.

The most ecient programme in terms of energy and

water consumption for washing and drying normally soiled cotton laundry. At the end of

cycle the garments can be immediately stored to the cupboard.

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Mixed

For washing lightly to normally soiled resilient garments in cotton, linen,

synthetic bres and mixed bres.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Suitable for washing moderately soiled garments made of synthetic bres

(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

White

For heavily soiled whites and resistant colours.

Colours

A 30°C cycle that helps to preserve colours, suitable for cotton or

synthetic coloured garments. It allows for reducing electricity

consumption for heating the water while guaranteeing good washing

results. Suitable for lightly soiled garments.

Eco 40-60

For washing normally soiled cotton garments declared to be washable at

40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most ecient in terms of water and energy

consumption.

! The cycle runs only at 40°C as per regulation.

Sport

A cycle designed for washing lightly soiled sports clothing (tracksuits,

shorts, etc.); for best results, we recommend not exceeding the maximum

load indicated in the “Wash Cycle Table”. We recommend using liquid

detergent and adding the amount suitable for a half-load.

20 °C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Anti Odour

use programme for washing garments with bad odours (e.g. smoke,

sweat, fried food). The programme is designed to remove bad odours

while preserving the fabric bres. Synthetics fabrics or mixed loads should

be washed at 40°, and resistant cotton fabrics at 60°.

Delicates

use programme to wash very delicate garments. It is advisable to turn the

garments inside out before washing them. For best results, use liquid

detergent on delicate garments.

When selecting an exclusively time-based drying function, a drying cycle is

performed at the end of the wash cycle that is particularly delicate, thanks

to light handling and appropriate temperature control of the water jet.

The recommended durations are:

1 kg of synthetic garments --> 150 min

1 kg of synthetic and cotton garments --> 180 min

1 kg of cotton garments --> 180 min

The degree of dryness depends on the load and fabric composition.

Wool - Wool Care

The wool wash cycle of this machine has been approved by The

Woolmark Company for the washing of machine washable wool

products provided that the products are washed according to

the instructions on the garment label and those issued by the

manufacturer of this washing machine. The Woolmark symbol is

a Certication mark in many countries. M2227.

Rapid 30’

For washing lightly soiled garments in a short time. Not suitable for wool,

silk and garments to be washed by hand.

Wash&Dry 45 min

select programme for washing and drying lightly soiled garments (Cotton

and Synthetic) in a short time. This cycle may be used to wash and dry a

laundry load of up to 1 kg in just 45 minutes. To achieve optimum results,

use liquid detergent and pre-treat cus, collars and stains.

AirFresh

ideal cycle to refresh garments and remove bad odours, in particular

smoke, from cotton and synthetic items in 30’ (max 1.5kg) without the

washing phase.

Rinse + Spin

Designed for rinsing and spinning.

Spin + Drain

Designed to spin and drain the water.

WASH CYCLE PHASE INDICATOR LIGHTS

Once the desired wash cycle has been selected and has begun, the

indicator lights switch on one-by-one to indicate which phase of the cycle

is currently in progress.

Wash

Rinse

Spin/Drain

Drying

END End of Wash Cycle

DOOR LOCKED INDICATOR

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button; if the indicator light is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with detergent and no laundry, by setting the

“Auto-Clean” cycle.

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

Rapid programming

- Turn the washing machine on by pressing the ON/OFF button. All the

indicator lights will light up for a few seconds, then only the lights

corresponding to the settings for the selected wash cycle will remain lit;

the START/PAUSE indicator light will also ash.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER DRAWER

section”.

- Close the door.

STARTING CYCLE

Press the PUSH & GO.

The machine will lock the door ( symbol on)and the drum will start to

rotate; the door will be unlocked ( symbol OFF) and then locked again (

symbol on) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum

and start the washing phase once the door is locked.

Traditional programming

- Turn the washing machine on by pressing the ON/OFF button. All the

indicator lights will light up for a few seconds, then only the lights

corresponding to the settings for the selected wash cycle will remain lit;

the START/PAUSE indicator light will also ash.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the Wash Cycle Table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER

DRAWER” section.

- Close the door.

- Set the WASH CYCLE knob to the desired cycle.

- Modify the temperature: pressing the button allows for gradually

reducing the temperature down to the cold wash level ( ).

- Select the desired wash cycle.

- Select the desired options.

STARTING CYCLE

Press the START/PAUSE button.

The machine will lock the door ( symbol on)and the drum will start to

rotate; the door will be unlocked ( symbol OFF) and then locked again (

symbol on) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum

and start the washing phase once the door is locked.

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash . If the indicator light is not lit, the door may be

opened. To start the wash cycle from the point at which it was

interrupted, press the START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the indicator light turns on to signal that the door

cannot be opened. While a wash cycle is running, the door remains locked.

To open the door while a cycle is under way, for example, to add or remove

garments, press the START/PAUSE button to pause the cycle; the

indicator light will ash . If the indicator light is not lit, the door may be

opened. Press the START/PAUSE button again to continue the cycle.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washing machine

using the START/PAUSE button (the relative indicator light will ash ),

then select the desired cycle and press the START/PAUSE button again.

! To cancel a cycle that has already begun, press and hold the ON/OFF

button. The cycle will be stopped and the machine will switch o.

END OF THE CYCLE

Once the cycle terminates the indicator light will light up; when the END

indicator light switches o, the door may be opened. Open the door,

unload the laundry and switch o the machine.If you do not press “ON/

OFF” button, the washing machine will switch o automatically after

about a 10 minutes. Close the water tap, open the door and unload the

washing machine. Leave the door ajar to allow the drum to dry.

FUNCTIONS

- If the selected option is not compatible with the set wash cycle, the

indicator light will ash and the option will not be activated.

- If the selected option is not compatible with another previously

selected option, the indicator light will ash accompanied by a buzzer,

and only the latter option will be activated; the indicator light

corresponding to the activated option will turn on.

Stain removal

This option allows for selecting the type of dirt so as to optimally adjust the

cycle for removing the stains. The following types of dirt can be selected:

- Food: for stains caused by foodstus and beverages, for example.

- : for grease and ink stains, for example.Work

- : for mud and grass stains, for example.Outdoor

! The wash cycle duration varies according to the type of selected dirt.

Slow Spin

By selecting this function, reduces the spin speed.

Extra rinse

By selecting this option, the eciency of the rinse is increased and

optimal detergent removal is guaranteed. It is particularly useful for

sensitive skin.

Temperature

Each wash cycle has a pre-dened temperature. To modify the

temperature, press the button.

Drying

Drying may be set as follows:

- Based on the desired laundry dryness level:

Iron “ ”: suitable for clothes which will need ironing afterwards. the

remaining dampness softens creases, making them easier to remove.

Hanger “ ”: ideal for clothes which do not need to be dried fully.

Cupboard “ ”: suitable for laundry which can be put back in a cupboard

without being ironed.

- Based on a set time period: between and minutes.40 180

If your laundry load to be washed and dried is much greater than the

maximum stated load, perform the wash cycle, and when the cycle is

complete, divide the garments into groups and put some of them back

in the drum. At this point, follow the instructions provided for a “Drying

only” cycle. Repeat this procedure for the remainder of the load. A

cooling-down period is always added to the end of each drying cycle.

Drying only

Press button to perform the drying-only cycle.

After selecting the desired cycle (compatible with the type of garments),

press button to exclude the washing phase and start the drying phase

at the maximum level for the selected cycle.

Push & Go

To start the Push & Go cycle press and hold the button for 2 seconds.

The indicator lights up to show that the cycle has started. The wash and

drying cycle is ideal for cotton or synthetic fabrics, as it washes them at

a temperature of 30° and a maximum spin speed of 1000 rpm. During

the drying cycle the maximum temperature is 60°C. At the end of the

cycle the residual humidity will be the same as for the “ ” level. Max

recommended load 3 kg. (Cycle duration 210’).

How does it work?

1. Load the laundry (cotton and/or synthetic garments) and close the door.

2. Pour the detergent and/or additives.

3. Start the cycle by pressing and holding the Push & Go button for 2

seconds. The relevant indicator light will turn green and the door will lock

(the DOOR LOCKED symbol is lit).

NB: starting the cycle through the Push & Go button activates an

automatic non-customisable wash and drying cycle recommended for

cotton and synthetic fabrics.

4. The automatic cycle can be used only for washing, excluding the drying

phase. Press the Push & Go button and then the drying button : the

drying icon of the “ ” level will switch o. Maximum load for washing-

only is 3 kg (Cycle duration 45’). The cycle cannot be customised further.

To open the door while an automatic cycle is under way, press the START/

PAUSE button. If the DOOR LOCKED symbol is o, the door may be

opened only during the washing phase. Press the START/PAUSE button

again to restart the wash cycle from the point at which it was interrupted.

5. Once the programme is nished, the indicator light turns on. END

TIPS AND SUGGESTIONS

Divide the laundry according to:

Type of fabric (cotton, mixed bres, synthetics, wool, garments to be

hand-washed). Colour (separate coloured garments from whites, wash new

coloured garments separately). Delicates (small garments – such as nylon

stockings – and items with hooks – such as bras: insert them in a fabric bag).

Empty the pockets:

Objects such as coins or lighters can damage the washing machine and

the drum. Check all buttons.

Follow the dosage recommendation / additives

It optimizes the cleaning result, it avoids irritating residues of surplus detergent

in your laundry and it saves money by avoiding waste of surplus detergent.

Use low temperature and longer duration

The most ecient programmes in terms of energy consumption are

generally those that perform at lower temperatures and longer duration.

Observe the load sizes

Load your washing machine up to the capacity indicated in the

“PROGRAMME CHART” table to save water and energy.

Noise and remaining moisture content

They are inuenced by the spinning speed: the higher the spinning speed

in the spinning phase, the higher the noise and the lower the remaining

moisture content.

CARE AND MAINTENANCE

Before performing cleaning and maintenance, switch the washing machine

o and disconnect it from the mains power. Do not use ammable liquids to

clean the washing machine. Clean and maintain your washer - dryer

periodically (at least 4 times per year).

Disconnect the water and power supplies

Close the water tap after every wash. This will limit wear on the hydraulic

system inside the washing machine and help to prevent leaks.

Unplug the washing machine when cleaning it and during all

maintenance work.

Clean the washing machine

The outer parts and rubber components of the appliance can be cleaned using

a soft cloth soaked in lukewarm soapy water. Do not use solvents or abrasives.

The washing machine has a “Auto-clean” cycle for its internal parts; it must

be run without any load in the drum.

To optimise this cycle, it is possible to use either detergent (10% of the quantity

specied for lightly soiled garments) or special additives to clean the washing

machine. We recommend running a cleaning cycle every 40 wash cycles.

To start the cycle press buttons simultaneously for 5 seconds. and

The cycle will start automatically and will run for about 70 minutes. To

stop the cycle, press the START/PAUSE button.

Clean the detergent dispenser drawer

Wash it under running water; this operation should be repeated frequently.

Care for the door and drum

Always leave the porthole door ajar in order to prevent unpleasant

odours from forming.

Check the water inlet hose

Check the water inlet hose at least once a year. If it is cracked or broken, it

must be replaced: during wash cycles, the high pressure of the water

could suddenly split the hose open.

! Never use hoses that have already been used.

Cleaning the water lter / draining residual water

Switch o and unplug the washing machine, take out the kitchen plinth before

cleaning the water lter or draining residual water.

The kitchen plinth must be mounted back all the time once the cleaning

operation is over.

If you used a hot wash programme, wait until the water has cooled down

before draining any water. Clean the water lter regularly, to avoid that the

water cannot drain after the wash due to obstruction of the lter. If the water

cannot drain, the display indicates that the water lter may be clogged.

1 . Place a container close to the pump to collect any spillage.

2 . Remove, pulling it out, the “emergency drain hose” from the base of

the washing machine .

Remove the stopper of the “emergency drain hose” at the end of the hose

and let the water ow into the container.

3 . Turn the exhaust lter handle and pull it out of the housing .

When the container of plinth is full with water, plug the stopper to the

hose end, and reinsert the small hose in the washing machine’s base . After,

empty the container .

Afterwards rmly close the emergency drain hose with the stopper .

4. Remove lter: Lay a cotton cloth beneath the water lter, which can

absorb a small amount of rest water . Then remove the water lter by

turning it out anticlockwise .

5 . Clean the water lter: remove residues in the lter and clean it under

running water .

6 . Insert the water lter: Reinsert the water lter again by turning it in

clockwise direction . Make sure to turn it in as far as it goes; the lter handle

must be in vertical position . To test water tightness of the water lter, you

can pour about 1 liter of water into the detergent dispenser .

Then reinstall the kitchen plinth.

LOAD BALANCING SYSTEM

Before every spin cycle, to avoid excessive vibrations before every

spin and to distribute the load in a uniform manner, the drum rotates

continuously at a speed which is slightly greater than the washing

rotation speed. If, after several attempts, the load is not balanced

correctly, the machine spins at a reduced spin speed. If the load is

excessively unbalanced, the washing machine performs the distribution

process instead of spinning. To encourage improved load distribution and

balance, we recommend small and large garments are mixed in the load.

TRANSPORT AND HANDLING

Do not lift the washing machine by gripping it from the upper section.

Unplug the appliance and close the water tap. Check that the door and

detergent dispenser drawer are tightly closed. Detach the lling hose from the

water tap then detach the drain hose. Empty all the water remaining in the

hoses and secure the latter so that they do not get damaged during transport.

Apply the transport bolts back on. Repeat, in reverse order, the transport bolt

removal procedure described in the “Health & Safety and Installation Guides”.

Product specificaties

Merk:	Indesit
Categorie:	Wasdroger
Model:	BI WDIL 861485 UK
Apparaatplaatsing:	Ingebouwd
Soort bediening:	Buttons, Rotary
Kleur van het product:	Wit
Deurscharnieren:	Links
Ingebouwd display:	Ja
Gewicht:	66000 g
Breedte:	595 mm
Diepte:	545 mm
Hoogte:	815 mm
Netbelasting:	1850 W
Type stekker:	Type G
Type lader:	Voorbelading
Deurkleur:	Wit
Materiaal trommel:	Roestvrijstaal
Snoerlengte:	1.2 m
Trommelinhoud:	58 l
Uitgestelde start timer:	Nee
Resterende tijd indicatie:	Nee
Kinderslot:	Nee
Aantal droogprogramma's:	12
Anti-kreuk functie:	Nee
Gewicht verpakking:	68000 g
Breedte verpakking:	645 mm
Diepte verpakking:	595 mm
Hoogte verpakking:	890 mm
Energieverbruik wassen:	0.545 kWu
Centrifuge-droger klasse:	B
Geluidsniveau (wassen):	70 dB
Sopschuimbewaking:	Ja
Onbalanscontrolesysteem:	Ja
Maximale centrifugesnelheid:	1400 RPM
Stroom:	13 A
Zelfreinigend:	Ja
Geluidsemissieklasse:	A
Droogcapciteit:	6 kg
Energiegebruik bij wassen & drogen:	3.072 kWu
Waterverbruik wassen & drogen:	65 l
Water verbruik wassen:	48 l
Aantal wasprogramma's:	16
Duur cyclus (snelwas programma):	30 min
Verstelbare voeten:	Ja
Land van herkomst:	Italië
Kuip materiaal:	Kunststof
Extra droog:	Nee
Half-geladen:	Nee
Kijkglas:	Ja
Energie-efficiëntieklasse (wassen):	B
Energie-efficiëntieklasse (wassen en drogen):	D
Energieverbruik per 100 cycli (wassen):	55 kWu
Energieverbruik per 100 cycli (wassen en drogen):	307 kWu
Watertoevoer:	Cold, Hot
Verlichting in trommel:	Nee
Energiezuinige modus:	Nee
Easy Iron-functie:	Nee
Duur wascyclus:	218 min
Export Control Classification Number (ECCN):	84501111
Vlekkenverwijderaarsoptie:	Nee
Nominale capaciteit (wassen):	8 kg
AC-ingangsspanning:	220-240 V
AC-ingangsfrequentie:	50 Hz
Type beeldscherm:	LED
Energie-efficiëntieschaal:	A tot F
Type motor:	Borstelloos
