Pagina 1/110

*CH350-90040*

CH350-90040

Deskjet 2050 All-in-One J510 series

Deskjet 1050 All-in-One J410 series

Black Cartridge

Tri-color Cartridge

301

Windows: Mac:

www.hp.com/support

Information

For setup information, see the setup poster. All other product information can be found in the electronic Help and Readme.

The electronic Help is automatically installed during printer software installation. Electronic Help includes instructions on

product features and troubleshooting. It also provides product speciﬁcations, legal notices, environmental, regulatory, and

support information. The Readme ﬁle contains HP support contact information, operating system requirements, and the most

recent updates to your product information. For computers without a CD/DVD drive, please go to www.hp.com/support to

download and install the printer software.

Install electronic Help

After software installation, click Start All Programs > >

HP HP Deskjet 2050 J510 HP Deskjet 1050 J410 > or >

Help.

Find Readme

Insert software CD. On software CD locate

ReadMe.chm. Click ReadMe.chm to open and then

select ReadMe in your language.

Find Readme

Insert the software CD, and then double-click the Read

Me folder located at the top-level of the software CD.

Find electronic Help

To install the electronic Help, insert the software CD in your computer and follow the on-screen instructions.

Find electronic Help

Mac OS X v10.5 and v10.6: From , choose Finder Help

Mac Help Help Viewer. In the , click and hold the Home

button, and then choose the Help for your device.

Get quicker service and support alerts by registering at http://www.register.hp.com.

English

Printed in [English]

Windows: Mac:

Ink usage

Power speciﬁcations:

Power adapter: 0957-2286

Input voltage: 100-240Vac (+/- 10%)

Input frequency: 50/60Hz (+/- 3Hz)

Note: Use only with the power adapter supplied by HP.

Note: Ink from the cartridges is used in the printing process in a number of different ways, including in the initialization

process, which prepares the device and cartridges for printing, and in printhead servicing, which keeps print nozzles

clear and ink ﬂowing smoothly. In addition, some residual ink is left in the cartridge after it is used. For more information,

see www.hp.com/go/inkusage.

Installation Troubleshooting

If you are unable to print a test page:

• Make sure the cable connections are secure.

See the setup poster.

• Make sure the printer is powered on.

The [ button] will be lit green.On

If you are still unable to print, or the Windows

software installation fails:

Installation Troubleshooting

If you are unable to print a test page:

To uninstall the software:

1. Disconnect the HP product from your computer.

2. Open the Applications: Hewlett-Packard folder.

3. Double-click . Follow the on-screen HP Uninstaller

instructions.

1. Remove the CD from the computer’s CD/DVD drive,

and then disconnect the USB cable from the

computer.

2. Restart the computer.

3. Temporarily disable any software ﬁrewall and

close any anti-virus software. Restart these programs

after the printer software is installed.

4. Insert the printer software CD in the computer’s

CD/DVD drive, then follow the on-screen instructions

to install the printer software. Do not connect the

USB cable until you are told to do so.

5. After the installation ﬁnishes, restart the computer.

Windows XP, and Windows Vista are U.S. registered trademarks of

Microsoft Corporation. Windows 7 is either a registered trademark or

trademark of Microsoft Corporation in the United States and/or other

countries.

Make sure the printer is set as your default printing

device:

• Windows® 7: From the Windows menu, click Start

Devices and Printers.

• Windows Vista® : On the Windows taskbar, click

Start, click Control Panel, and then click .Printer

• Windows XP

® : On the Windows taskbar, click

Start, click Control Panel, and then click Printers and

Faxes.

Make sure that your printer has a check mark in the

circle next to it. If your printer is not selected as the

default printer, right-click the printer icon and choose

“Set as Default Printer” from the menu.

• Make sure the cable connections are secure. See the

setup poster.

• Make sure the printer is powered on.

The [ button] will be lit green.On

To install the software:

1. Connect the USB cable.

2. Insert the HP software CD into your computer’s

CD/DVD drive.

3. On the desktop, open the CD and then

double-click .HP Installer

4. Follow the on-screen and the printed setup

instructions that came with the HP product.

If you are still unable to print, uninstall and

reinstall the software:

Note: The uninstaller removes all of the HP software

components that are speciﬁc to the device. The uninstaller

does not remove components that are shared by other

products or programs.

Power adapter: 0957-2290

Input voltage: 200-240Vac (+/- 10%)

Input frequency: 50/60Hz (+/- 3Hz)

English

Control panel

Label Icon Name and Description

On: Turns the product on or off. When the product is off, a minimal amount of power is still

used. To completely remove power, turn off the product and then unplug the power cord.

Cancel: Stops the current operation.

Start Copy Black: Starts a black-and-white copy job. Increase the number of copies (up

to 10) by pressing the button multiple times. Acts as a resume button after resolving print

problems.

Start Copy Color: Starts a color copy job. Increase the number of copies (up to 10) by

pressing the button multiple times. Acts as a resume button after resolving print problems.

Attention light: Indicates that there is a paper jam, the printer is out of paper, or some event

that requires your attention. If the attention light and both cartridge lights blink when you set

up the printer, the cartridge carriage might be obstructed. Open cartridge door and make

sure that cardboard and blue tape have been removed from inside the printer. Then press

Start Copy Black or Start Copy Color to resume.

Cartridge light: Indicates low ink or a print cartridge problem.

• If a cartridge is low on ink, replace the cartridge when print quality is no longer

acceptable.

• If a cartridge light blinks after you install a cartridge, make sure that the pink tape has

been removed from the cartridge.

English

Product specificaties

Merk:	HP
Categorie:	Printer
Model:	Deskjet 2050A
Kleur van het product:	Zwart
Ingebouwd display:	Nee
Gewicht:	3600 g
Breedte:	427 mm
Diepte:	406 mm
Hoogte:	249 mm
Gewicht verpakking:	5220 g
USB-poort:	Ja
Ethernet LAN:	Nee
Geïntegreerde geheugenkaartlezer:	Nee
Markt positionering:	Thuis & kantoor
Afmetingen verpakking (BxDxH):	463 x 193 x 349 mm
Aantal USB 2.0-poorten:	1
Stroomverbruik (in standby):	2.3 W
Intern geheugen:	- MB
Duurzaamheidscertificaten:	ENERGY STAR
Ondersteunt Mac-besturingssysteem:	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Maximale resolutie:	4800 x 1200 DPI
Aantal printcartridges:	2
Printkleuren:	Black, Cyan, Magenta, Yellow
Papierlade mediatypen:	Envelopes, Labels, Photo paper, Plain paper, Transparencies
Printtechnologie:	Inkjet
Standaard interfaces:	USB 2.0
Modus voor dubbelzijdig afdrukken:	Handmatig
Printsnelheid (zwart, standaardkwaliteit, A4/US Letter):	5.5 ppm
Printsnelheid (zwart, concept, A4/US Letter):	20 ppm
Printsnelheid (kleur, standaard, A4/US Letter):	4 ppm
Printen:	Afdrukken in kleur
Duplex printen:	Nee
Paginabeschrijving talen:	PCL 3
Gebruiksindicatie (maximaal):	1000 pagina's per maand
Digital Sender:	Nee
Kopieersnelheid (zwart, standaard, A4):	4.5 cpm
Kopieersnelheid (standaard, kleur, A4):	2.5 cpm
Maximale kopieerresolutie:	600 x 600 DPI
Kopiëren:	Kopiëren in kleur
Scannen:	Scannen in kleur
Soort scanner:	Flatbed scanner
Optische scanresolutie:	1200 x 1200 DPI
Max. scangebied:	8.5 "
Faxen:	Nee
Totale invoercapaciteit:	60 vel
Maximum invoercapaciteit:	60 vel
Totale uitvoercapaciteit:	25 vel
Maximale uitvoercapaciteit:	25 vel
Maximale ISO A-series papierformaat:	A4
ISO A-series afmetingen (A0...A9):	A4, A5, A6
Gemiddeld stroomverbruik ( bedrijfsresultaat ):	10 W
Direct printen:	Nee
Printsnelheid (kleur, concept, A4/US Letter):	16 ppm
Geluidsdrukniveau (afdrukken):	50 dB
Type invoer papier:	Papierlade
Papierlade mediagewicht:	75 - 90 g/m²
Maximale printafmetingen:	210 x 297 mm
ISO B-series afmetingen (B0...B9):	B5
Afmetingen enveloppen:	DL
PictBridge:	Nee
Printsnelheid (zwart, presentatiekwaliteit, A4):	1.5 ppm
Printkwaliteit (zwart, beste kwaliteit):	600 x 600 DPI
Maximum uitvoercapaciteit voor transparanten:	10 vel
Standaard uitvoercapaciteit voor transparanten:	10 vel
Maximum afmetingen (B x D x H):	427 x 470 x 249 mm
Maximum invoercapaciteit voor transparanten:	15 vel
Grijsniveaus:	256
Duplex scannen:	Nee
Maximaal aantal kopieën:	10 kopieën
Dubbelzijdig kopiëren:	Nee
Dubbelzijdig faxen:	Nee
All-In-One-multitasking:	Nee
Aanbevolen gebruiksindicatie:	250 - 500 pagina's per maand
Minimale opslag schijfruimte:	250 MB
Minimale processor:	233 MHz
Kleurdiepte invoer:	24 Bit
Multifunctionele lade, mediatypen:	Wenskaarten
Afmetingen (B x D x H):	427 x 406 x 249 mm
Afmetingen pallet (B x D x H):	1219 x 1016 x 2570 mm
Hardwarematige scanresolutie:	1200 x 1200 DPI
Kleurenscans:	Ja
Foto papier afmetingen:	10x15, 13x18 cm
All-in-one-functies:	Copy, Print, Scan
Kleurenfuncties all-in-one:	copy, print, scan
Printmarge onder (A4):	14.5 mm
Printmarge links (A4):	3.2 mm
Printmarge rechts (A4):	3.2 mm
Printmarge boven (A4):	1.5 mm
Pallet brutogewicht:	459000 g
Invoercapaciteit voor enveloppen (primaire lade):	5 vel
Wifi:	Nee
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	5 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	15 - 80 procent
Kopieersnelheid (kleur, normaal, US letter):	2.5 cpm
Maximum invoercapaciteit voor 10 x 15 cm foto's:	20 vel
Kleurenkopiemogelijkheid:	Ja
