INSTALLATION AND OPERATING INSTRUCTIONS.

READ INSTRUCTIONS CAREFULLY BEFORE

ATTEMPTING INSTALLATION. KEEP THESE

INSTRUCTIONS FOR FUTURE REFERENCE.

The Hozelock Cyprio air pump is designed for use

outdoors. It must not be submersed in the pond. All

electrical components are safely housed inside the

product.

The appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety. Children should

be supervised to ensure that they do not play with

the appliance.

1. WARNING: ALWAYS UNPLUG OR DISCONNECT

ALL APPLIANCES IN THE POND FROM THE

ELECTRICITY SUPPLY BEFORE PUTTING YOUR

HANDS IN THE WATER WHILST EQUIPMENT IS

BEING INSTALLED, REPAIRED, MAINTAINED OR

HANDLED.

2. Do not use the supply cable to lift the pump as

this may cause damage.

3. If the supply cable is damaged, do not operate

the pump.

4. Do not operate or leave the pump in freezing

conditions.

5. Check that the voltage marked on the pump

corresponds to the mains supply.

6. A 30mA maximum Residual Current Device (RCD)

MUST be fitted to the mains supply.

7. Do not operate this pump without the inlet filter

and cover attached. Using the pump without AN

INLET FILTER may invalidate your warranty.

1. The pump is supplied with 3m of 3-core electric

cable, which is permanently connected and sealed

to the motor. The supply cable cannot be

replaced. If the cable is damaged, the pump

should be discarded. This product is designed to

be permanently wired to the mains supply in a

dry weatherproof enclosure through a Double-

Pole Switched Fused Spur - (Disconnector) - Fitted

with a 3 or 5 Amp fuse. The installation must

conform to the national and local wiring

regulations.

2. A 30MA MAXIMUM RESIDUAL CURRENT DEVICE

(RCD) MUST BE FITTED TO THE MAINS SUPPLY.

3. WARNING: This appliance must be earthed.

4. If an extension cable is required, this should be

connected to the end of the pump cable using a

weatherproof cable connector. The joint must be

positioned in a suitable weatherproof housing.

The extension cable should be of 3 core 0.75mm

Polychloroprene rubber insulated cable (ref: HO5

RN-F) and permanently wired to the mains supply

with a 3 or 5 Amp fuse.

5. The pump cable (and extension cable) should be

adequately protected against damage especially

where contact with gardening equipment (lawn

mowers, forks etc..) children and domestic

animals may occur.

6. Always disconnect the mains power supply whilst

the equipment is being installed, repaired,

maintained or handled. Consult a qualified

electrician or local authority if in any doubt about

wiring to the mains supply.

IMPORTANT:

MAXIMUM DEPTH OF AIR STONE IN POND 2M. BY

PLACING THE AIR STONE DEEPER THAN 2M YOU

WILL FOREGO THE PRODUCT WARRANTY.

1. Place the unit near the pond, on a solid level

surface. Route the cable back to the mains supply.

Ensure that you allow for enough cable for

positioning the product in the desired location

near the pond.

2. Push the rubber outlet pipe over the outlet of the

Air Pump and fasten in place using the metal clip

provided (See Fig 1 & 2).

3. Insert the air manifold into the end of the rubber

tube and fasten in place with the clip provided

(See Fig 3 & 4).

4. Push the 4mm air tube onto the end of one of

the air outlets and ensure it is securely in place

(See Fig 5).

5. To fit the non-return valve to the air pipe, cut the

pipe and push the ends onto the inlet/outlet of

the valve. This valve only works in one direction,

which is indicated by the mark ‘OUT’ (See Fig 6).

This valve ensures that water is not sucked back

into the pump if the pump is installed below the

pond’s water level when the power supply is

turned off.

6. Cut the air tube to the desired length. This will be

determined by:

a) The location of your pump around the pond

b) The depth at which you want to position your air

stone in the pond (MAXIMUM DEPTH = 2m).

Important

Warning: Safety and Electrical

Connections

Pump Installation

7. Attach the other end of the air tube to the 50mm

air stone (See Fig 7).

8. Place the air stone in the pond or filter. Locate

the air stone(s) in a position to maximise pond

aeration. If using multiple air stones ideally

position these in different parts of the pond.

9. Attach additional air tubes, valves and air stones if

desired following the same installation process

described in steps 4-8.

10.Ensure all the manifold outlet valves that don’t

have air tube attached are closed. This can be

achieved by cutting a small length of hose and

attaching each end to an outlet, or by tying off a

small length of hose. (See Fig 8).

11.If the pump is to be used during the winter it is

advisable to raise the air stone(s) up off the

bottom of the pond to help avoid circulating cold

water.

Pump Location

The pump should be positioned on a solid flat,

horizontal surface when in use.

If you do not wish to operate the air pump for 12

months of the year, store the air pump safely in a

dry environment and where temperatures will be

above freezing.

The Hozelock Cyprio Air Pump has been designed to

allow quick and easy maintenance. The air pump

contains rubber parts, which can wear over time.

The product has been specifically designed to make

the replacement of these parts as convenient as

possible.

THE MAINTENANCE OF THIS PRODUCT MUST BE

COMPLETED BY A TECHNICALLY COMPETENT

PERSON. IF IN ANY DOUBT PLEASE CONSULT THE

RETAILER WHERE THE PRODUCT WAS PURCHASED.

ALWAYS UNPLUG OR DISCONNECT THE PUMP

FROM THE ELECTRICITY SUPPLY BEFORE STARTING

MAINTENANCE.

1. The diffusion of air from air stones will

deteriorate over time. In order to maximise the

efficiency of air output, air stones should be

replaced every year.

2. If rubber o-rings and the diaphragm are replaced

every year, the efficiency of the pump will be

maintained at a consistently high level. A spares kit

is available from Hozelock Cyprio.

Tools Needed

- Medium sized Phillips screwdriver.

- A pair of pliers.

Replacing the Inlet Foam

1. Remove screw from the air inlet cover (See Fig 9).

2. Remove the air inlet cover (See Fig 10 & 11).

3. Remove and replace the filter (See Fig 12).

4. Replace the air inlet cover, screw and grommet.

Replacing the Outlet Foams

1. Remove the 6 screws from the base of the air

pump (See Fig 13) and remove the lid (See Fig 14).

2. Remove the four screws from the motor base and

remove (See Fig 25). Do not remove the earth

cable screw.

3. Carefully lift the cable grommet and lift the

motor unit from the base moulding (See Fig 26).

4. Replace the foams (See Fig 27).

5. Ensure seals are in place before reassembling the

motor unit into the base moulding (See Fig 28).

6. Ensure cable grommet is located correctly in the

base moulding.

7. Reassemble the pump lid ensuring that the seal is

in place between the lid and base (See Fig 15 &

14).

Replacing the Flapper Valves

1. Remove the 4 screws from the base of the air

pump and remove the lid (See Fig 13/14).

2. Locate the rubber L-tube. Detach the L-tube from

air chamber cover (See Fig 16).

3. Remove the 4 screws from the air chamber cover;

gently pull the cover away from the pump (See

Fig 17 & 18).

4. Remove the securing screw and cover plate from

the air chamber housing (See Fig 19).

5. Remove the rubber inlet and outlet covers; care

should be taken not to damage these as they act

as seals (See Fig 20).

6. Pull out the valves, when replacing the new

valves ensure they are fitted from the same

direction (See Fig 21).

7. Replace the valves by passing the spigot through

the hole and then pulling the spigot from the

other side until the lug passes through the hole

locking the valve in place (See Fig 22). Cut the

spigot back after the valve is securely in place.

8. If the diaphragms are to be replaced then move

to step 5 in the following section.

9. Reassemble the product follow the steps in

reverse order from step 7. Ensure that the rubber

seal is in place between the lid and the base.

Replacing the Diaphragm

1. Remove the 4 screws from the base of the air

pump and remove the lid.

2. Locate the rubber L-tube. Detach the L-tube from

the air chamber cover (See Fig 16).

3. Remove the 4 screws from the air chamber cover;

gently pull the cover away from the pump (See

Fig 17 & 18).

4. Remove the centre nut, washers (See Fig 23).

5. Remove and replace the diaphragm assembly

Maintenance

Product specificaties

Merk:	Hozelock
Categorie:	Waterpomp
Model:	1800
Kleur van het product:	Grijs
Gewicht:	1214 g
Breedte:	220 mm
Diepte:	168 mm
Hoogte:	95 mm
Snoerlengte:	3 m
Gewicht verpakking:	1214 g
Breedte verpakking:	220 mm
Diepte verpakking:	168 mm
Hoogte verpakking:	95 mm
Materiaal behuizing:	Metaal
Vermogen:	4 W
Ondersteuning voor plaatsing:	Bovengronds
Type stroombron:	AC
Luchtstroom:	5.3 l/min
Ingangsspanning:	230 V
Aantal:	1
Frequentie:	50 Hz
Lengte van slang:	10 m
Pompdruk:	- bar
AC-ingangsspanning:	230 V
AC-ingangsfrequentie:	50 Hz
Type product:	Luchtpomp
Vloei-snelheid:	320 L/u
Inclusief slang:	Ja
Maximale druk:	0.14 bar
Pomp:	Ja
Inclusief luchtpomp:	Ja
Slangdiameter (min):	4 mm
Waterluchtsteen:	Ja
Aantal luchtstenen:	2
Maximaal ondersteunde vijverdiepte:	1200 mm
