Installation:
The AIS-2-NMEA Receiver is not waterproof and should be
mounted in a dry location. The unit can be fixed by the 4
mounting holes in the end flanges.
It will require connection to a marine VHF antenna via the
BNC socket at the rear or with a BNC to VHF adaptor socket.
Operation is from the boats DC supply of 12-24 Volts.
RED Positive +
BLUE Negative –
The output from the unit is NMEA 0183 and is designed to be
connected to an AIS compatible Chart Plotter.
YELLOW NMEA Output Positive +
GREEN NMEA Output Negative –
The output Baud rate is set to 38,400, if you wish to change
this to 4800 baud, disconnect the power, unscrew the two
screws to release the front cover and move the jumper
located in the middle to the 4800 position.
Operation:
On applying power the Green LED will light and the two
Channel Red LEDs will come on continuously for
approximately 10 seconds then extinguish. If you are within
range of vessels transmitting AIS data the two channels Red
LEDs will flash intermittently indicating reception of an AIS
message which will be sent out on the NMEA connection to
the Chart Plotter.
Limited Warranty:
Comar Systems Ltd warrants this product to be free from
defects in materials and manufacture for one year from the date
of purchase. Comar Systems Ltd will, at its sole option, repair or
replace any components that fail in normal use. Such repairs or
replacement will be made at no charge to the customer for parts
and labour. The customer is, however, responsible for any
transportation costs incurred in returning the unit to Comar
Systems Ltd.
This warranty does not cover failures due to abuse, misuse,
accident or unauthorized alteration or repairs.
The above does not effect the statutory rights of the consumer.
Note: Every effort has been made to ensure that all information
contained in this manual is accurate at the time of going to
press. However AIS is a new technology and the legislation is
subject to change. We therefore cannot take any responsibility
for the content of this manual and advise that you take normal
steps to ensure that the information is at its most current when
you are reading this manual.
Product Support
Comar Systems Limited
Unit 7, Medina Court
Arctic Road
Cowes
Isle of Wight, PO31 7XD
United Kingdom
Telephone: +44 (0) 1983 282400 Fax: +44 (0)1983 280402
E-mail: techsupport@comarsystems.com
Internet: www.comarsystems.com
www.busse-yachtshop.de | info@busse-yachtshop.de
Fault finding:
No power light is displayed
● Check the power supply and that the unit is connected correctly
to a 12 or 24 volt DC supply
● Check the polarity of the supply is correct (red +ve and blue
is –ve).
Channel A and Channel B lights do not flash
● Check that a VHF antenna is fitted and correctly connected.
● Check that the antenna is correctly positioned – i.e. at a suitable
location to visibly ‘see’ vessels.
Channel A and Channel B lights flash but no data is received
If the red channel lights flash then data is being received from
nearby vessels.
● Check the NMEA connections to the PC or NMEA device.
● Check on the PC application or device that the correct port is
assigned and the correct baud rate is setup. The correct baud rate
is 38400.
I can receive ships on my display but no names are shown.
● Remember that the names of ships as well as other static
information is only sent every 6 minutes or when requested by
another station.
Specification:
Dimensions Overall: 120 x 86 x 37
Power: 9-30 VDC
Current: 50mA @ 12VDC
Output: NMEA 0183
Message type: VDM
Baud Rate: 38400 (4800 by internal link)
Receiver: Dual Channel Parallel
Frequency: 161.975 and 162.025MHz
Sensitivity: -112dBm
Connections: Power/Data 1m 4 way cable
Antenna: BNC 50 Ohm
Installation
and
Quick Reference Guide
AIS-2-NMEA
Receiver
