Pagina 1/20
Ph: 03 9562 3455 | E: sales@thermofilm.com.au
M
M
M
MMa
a
a
aax (
x (
x (
x (x (TH
TH
TH
THTHX)
X)
X)
X)X)
P
P
P
PPr
r
r
rro
o
o
ood
d
d
ddu
u
u
uuc
c
c
cct
t
t
tt
M
M
M
MMa
a
a
aan
n
n
nnu
u
u
uua
a
a
aal
l
l
ll
www.heatstrip.com.au
HEATSTRIP® MAX (THX)
2
March 2023 Rev 2
Innovative, High Performance Electric Heating Technology
Features & Benefits
High Output radiant heat
The Heatstrip Max range of electric radiant heaters produces a high temperature radiant warmth that travels through the
air directly to people and surfaces below – similar to the heat rays emited by the Sun. Radiant heating is the only viable
option for outdoor or tough indoor sites.
Unique low glow heating technology-
Specially designed and engineered "low glow" heating element provides a very gentle and unobtrusive glow. There no -
blinding light, like other infra red heaters, so you can enjoy the experience. Energy is directed towards producing heat, -
rather than an annoying light.
Maximum heat performance – multiple applications
The high temperature output of the Heatstrip Max is perfect for exposed outdoor sites, high ceilings and hard heat -to-
indoor and outdoor applications.
The dual element design allows for a very compact unit, and maximum efficiency. Outdoor applications include al fresco -
and dining/entertainment areas, patios, veranda's and balconies, to name a few. Indoor applications such as factories,
warehouses, showrooms, workshops and workstation spot heating are ideal for the Heatstrip Max.
Suitable for permanent outdoor mounting, no protection needed.
For outdoor applications, the Heatstrip Max is suitable for both permanently exposed (eg. courtyards and patios) and
undercover installations does not need to be fully protected from the elements.-
High Strength element – virtually indestructible
The unique metallic Incoloy element is 14mm thick, meaning it is vandal proof and will not shatter like other glass quartz “ ”
heating elements. Provides piece of mind in both commercial and domestic situations.
Commercial grade quality – years full replacement warranty 2
Constructed of extremely robust, commercial grade material, the Heatstrip Max is designed for long life and durability in all -
conditions. It is fully supported by a 2 year replacement warranty under both residential and commercial conditions.
Corrosion protection
Built from corrosion resistant alloy, it is suitable for use in most applications, including difficult corrosive environments ch su
as coastal areas.
Multi Purpose Mounting Options-
The Heatstrip Max is supplied with flexible mounting options. The standard bracket will allow both ceiling and wall
mounting, at various angles, as well as suspension by chains/wires and metal rods. Optional twin mount and end-to-end
brackets are also available.
2 models – DIY or hard wired -
2 models are available. The THX 2400 (2400W) is supplied with a lead and plug, therefore ideal for a DIY installations.
The THX 3600 (3600W) requires hard wiring to a 15amp power supply.-
3
Specifications Australia-
MODEL POWER
(WATTS)
CURRENT
(AMPS)
DIMENSIONS
(mm)
WEIGHT
(Kg)
LEAD
LENGTH
(mm)
PLUG
THX 2400 854 x 170 x 80 6 YES 2400 10 1000
THX 3600 1184 x 170 x 80 8 3600 15 1000 NO
MODEL
HEATER TYPE High intensity electric radiant, infra red overhead heater with Incoloy 840 -
element
OUTPUT Refer to model code chart above
POWER 240 Volts Nominal at — Hertz, Single Phase 230-50 60
CONNECTION 3 Core Cable 2.5mm 2
APPROVALS AUSTRALIA / NZ
MOUNTING HEIGHT MINIMUM
RECOMMENDED
MAXIMUM
2.1 m
2.3 m to 2.8 m
3.0m Outdoors and 3.5m Indoors
(For higher ceiling heights, units can be lowered
using optional bracket kits)
MOUNTING OPTIONS Suitable for ceiling, wall, beam mounting. Also available for extension
mount using rigid fixing poles and chain mount bracket, flush, twin and end
to end.
PROTECTION RATING IPX5 Protection from water ingress from all directions
MATERIALS OF CONSTRUCTION Anodised alloy casing and end caps, chromed grille
THX3600
THX2400
