Toast-Rite®and Toast King®

Electric Conveyor Toasters

TRH and TK Series

Installation and Operating Manual

P/N 07.04.290.00

(see page 2)

www.hatcocorp.com

Do not operate this equipment unless you

have read and understood the contents of

this manual! Failure to follow the

instructions contained in this manual may

result in serious injury or death. This

manual contains important safety

information concerning the maintenance,

use, and operation of this product. If

you’re unable to understand the contents

of this manual, please bring it to the

attention of your supervisor. Keep this

manual in a safe location for future

reference.

No opere este equipo al menos que haya

leído y comprendido el contenido de este

manual! Cualquier falla en el seguimiento

de las instrucciones contenidas en este

manual puede resultar en un serio lesión

o muerte. Este manual contiene

importante información sobre seguridad

concerniente al mantenimiento, uso y

operación de este producto. Si usted no

puede entender el contenido de este

manual por favor pregunte a su

supervisor. Almacenar este manual en

una localización segura para la referencia

futura.

Ne pas utiliser cet équipement sans avoir

lu et compris le contenu de ce manuel !

Le non-respect des instructions

contenues dans ce manuel peut entraîner

de graves blessures ou la mort. Ce

manuel contient des informations

importantes concernant l'entretien,

l'utilisation et le fonctionnement de ce

produit. Si vous ne comprenez pas le

contenu de ce manuel, veuillez le signaler

à votre supérieur. Conservez ce manuel

dans un endroit sûr pour pouvoir vous y

référer plus tard.

WARNING

ADVERTENCIA

AVERTISSEMENT

2Form No. TRTKM-0812

INTRODUCTION

The Hatco Toast-Riteand Toast King Electric Conveyor Toasters

are specially designed to speed the toasting operation. Products

pass through a heating chamber for rapid and thorough

toasting. Dryness, moisture, sugar content, and thickness of

bread product affect the ability to achieve the perfect toasted

product. Conveyor speed, not temperature, determines the

toasting color.

Hatco toasters are quality built to meet the demands of

foodservice operations and provide years of trouble-free

performance. The metal-sheathed tubular heating elements are

guaranteed against breakage and burnout for two years. (If

failure of one element should occur, your Hatco toaster will

continue to operate – the production may be slightly lower.)

Hatco Electric Conveyor Toasters are products of extensive

research and field testing. The materials used were selected

for maximum durability, attractive appearance, and optimum

performance. Every unit is inspected and tested thoroughly prior

to shipment.

This manual provides the installation, safety, and operating

instructions for Hatco Electric Conveyor Toasters. Hatco

recommends all installation, operating, and safety instructions

appearing in this manual be read prior to installation or

operation of a unit.

Safety information that appears in this manual is identified by

the following signal word panels:

WARNING indicates a hazardous situation which, if not

avoided, could result in death or serious injury.

CAUTION indicates a hazardous situation which, if not

avoided, could result in minor or moderate injury.

NOTICE is used to address practices not related to

personal injury.

WARNING

CAUTION

NOTICE

CONTENTS

Important Owner Information ..............................................2

Introduction...........................................................................2

Important Safety Instructions ..............................................3

Model Description.................................................................4

All Models ...........................................................................4

Toast-Rite®(TRH) Models...................................................4

Toast King®(TK) Models.....................................................4

Model Designation................................................................4

Specifications........................................................................5

Plug Configurations ............................................................5

Electrical Rating Chart—TRH Models ................................6

Electrical Rating Chart—TK Models...................................7

Dimensions—TRH Models .................................................8

Dimensions—TK Models....................................................9

Installation ...........................................................................10

General.............................................................................10

Operation .............................................................................11

General .............................................................................11

Thermostat Adjustment.....................................................11

Maintenance ........................................................................12

General.............................................................................12

Daily Cleaning ..................................................................12

Cleaning the Toasting Baskets .........................................12

Troubleshooting Guide ......................................................13

Options and Accessories...................................................14

Limited Warranty.................................................................15

Authorized Parts Distributors ............................Back Cover

Record the model number, serial number (specification label

located on the back of the unit), voltage, and purchase date of

the unit in the spaces below. Please have this information

available when calling Hatco for service assistance.

Model No. ____________________________________

Serial No. ____________________________________

Voltage ______________________________________

Date of Purchase ______________________________

Completing online warranty registration will prevent delay in

obtaining warranty coverage. Access the Hatco website at

www.hatcocorp.com, select the Parts & Service pull-down

menu, and click on “Warranty Registration”.

IMPORTANT OWNER INFORMATION

Business 8:00 to 5:00 AM PM

Hours: Central Standard Time (C.S.T.)

(Summer Hours: June to September –

8:00 AM PMto 5:00 C.S.T. Monday – Thursday

8:00 AM PMto 2:30 C.S.T. Friday)

Telephone: (800) 558-0607; (414) 671-6350

E-mail: partsandservice@hatcocorp.com

Fax: (800) 690-2966 (Parts and Service)

(414) 671-3976 (International)

24 Hour 7 Day Parts and Service Assistance

available in the United States and Canada by

calling (800) 558-0607.

Additional information can be found by visiting our web site at

www.hatcocorp.com.

Form No. TRTKM-0812 3

IMPORTANT SAFETY INSTRUCTIONS

Read the following important safety information before using this equipment to avoid serious

injury or death and to avoid damage to equipment or property.

ELECTRIC SHOCK HAZARD:

• Plug unit into a properly grounded electrical receptacle

of correct voltage, size, and plug configuration. If plug

and receptacle do not match, contact a qualified

electrician to determine and install proper voltage and

size electrical receptacle.

• Turn OFF power switch, unplug power cord, and allow

unit to cool before performing cleaning, adjustments,

maintenance, or attempting to clear a jam.

• DO NOT submerge or saturate with water. Unit is not

waterproof. Do not operate if unit has been submerged

or saturated with water.

• Unit is not weatherproof. Locate unit indoors where the

ambient air temperature is a minimum of 70°F (21°C).

• Do not pull unit by power cord.

• Discontinue use if power cord is frayed or worn.

• Do not attempt to repair or replace a damaged power

cord. Cord must be replaced by Hatco, an Authorized

Hatco Service Agent, or a person with similar

qualifications.

• Do not steam clean or use excessive water on unit.

• This unit is not “jet-proof” construction. Do not use jet-

clean spray to clean unit.

• Do not clean unit when it is energized or hot.

• Do not allow liquids to spill into unit.

• This unit must be serviced by qualified personnel only.

Service by unqualified personnel may lead to electric

shock or burn.

FIRE HAZARD:

• Locate unit a minimum of 1″ (25 mm) from combustible

walls and materials. If safe distances are not

maintained, combustion or discoloration could occur.

• Do not locate toaster under shelving or closer than 12"

(305 mm) from the ceiling.

• Do not place anything on top of toaster. Do not place

toaster near or underneath curtains or other

combustible materials. Items near or on top of toaster

could catch fire causing injury and/or damage to

toaster.

EXPLOSION HAZARD: Do not store or use gasoline or

other flammable vapors or liquids in the vicinity of this or

any other appliance.

In case of fire, disconnect toaster from power source

immediately. This allows unit to cool, making it easier and

safer to put out the fire.

Make sure all operators have been instructed on the safe

and proper use of the unit.

This unit is not intended for use by children or persons with

reduced physical, sensory, or mental capabilities. Ensure

proper supervision of children and keep them away from unit.

WARNING

This unit has no “user-serviceable” parts. If service is

required on this unit, contact an Authorized Hatco Service

Agent or contact the Hatco Service Department at

800-558-0607 or 414-671-6350; fax 800-690-2966; or

International fax 414-671-3976.

BURN HAZARD:

• Some exterior surfaces on unit will get hot. Use caution

when touching these areas.

• Do not remove toast collector pan or baskets for

cleaning until toaster is cool.

Locate unit at proper counter height in an area that is

convenient for use. Location should be level to prevent unit

or its contents from falling accidentally and strong enough

to support weight of unit and contents.

Products thicker than 1-1/4" (32 mm) will cause conveyor

system to jam, which could ignite product inside toaster.

Misalignment of toasting baskets will cause conveyor to

jam. Hold down bars should be facing out and lying flat on

baskets. Incorrectly positioned bars will cause conveyor

to stop.

Always operate toaster with toast collector pan installed.

Toasting of coated or buttered products such as garlic

bread, cheese sandwiches, and sweet rolls is NOT

recommended. Residue will reduce toaster performance

and could ignite inside toaster. Using toaster with food

products listed above will void unit warranty.

Do not locate unit in an area subject to excessive

temperatures or grease from grills, fryers, etc. Excessive

temperatures could cause damage to the unit.

Do not locate toaster in an area that restricts air flow

around front or rear of unit. Do not locate toaster in direct

discharge path of air conditioning vent or makeup air vent.

Do not lay unit on the side with control panel or manual

advance knob. Damage to unit could occur.

Use non-abrasive cleaners and cloths only. Abrasive

cleaners and cloths could scratch finish of unit, marring its

appearance and making it susceptible to soil accumulation.

This unit is intended for commercial use only—NOT for

household use.

CAUTION

NOTICE

WARNING

Product specificaties

Merk:	Hatco
Categorie:	Broodrooster
Model:	Toast King TK-155B

Heb je hulp nodig?

Als je hulp nodig hebt met Hatco Toast King TK-155B stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Broodrooster Hatco

Hatco Intelligent Toast-Qwik ITQ-1750-2C Handleiding

9 Juli 2023

Hatco Toast-Qwik TQ-800HBA Handleiding

8 Juli 2023

Hatco Toast-Qwik TQ-400BA Handleiding

7 Juli 2023

Hatco Toast King TK-72 Handleiding

7 Juli 2023

Hatco Toast-Qwik TQ3-2000H Handleiding

6 Juli 2023

Hatco Toast-Qwik TQ-800H Handleiding

5 Juli 2023

Hatco Toast-Qwik TQ-1800H Handleiding

2 Juli 2023

Hatco Toast-Qwik TQ-1800 Handleiding

2 Juli 2023

Hatco Toast-Qwik TQ3-500 Handleiding

1 Juli 2023

Hatco Toast-Qwik TQ3-2000 Handleiding

1 Juli 2023

Handleiding Broodrooster

Nieuwste handleidingen voor Broodrooster

Bartscher 100201 Handleiding

22 November 2024

Morphy Richards Ascend MRRGT4 Handleiding

20 November 2024

Morphy Richards Prism 248101 Handleiding

20 November 2024

Morphy Richards Accents 242041 Handleiding

20 November 2024

Cecotec ClassicToast 15000 Handleiding

20 November 2024

Cecotec Touch&Toast Double Handleiding

19 November 2024

Cecotec TrendyToast 9000 Handleiding

19 November 2024

Cecotec Toast&Taste Extra Double Handleiding

19 November 2024

Cecotec Toast&Taste Extra Handleiding

19 November 2024

Cecotec Toast&Taste 1600 Retro Double Handleiding

19 November 2024
