Pagina 1/32

Do not operate this equipment unless you

have read and understood the contents

of this manual! Failure to follow the

instructions contained in this manual

may result in serious injury or death.

This manual contains important safety

information concerning the maintenance,

use, and operation of this product. If

you’re unable to understand the contents

of this manual, please bring it to the

attention of your supervisor. Keep this

manual in a safe location for future

reference.

English = p 2

WARNING

No opere este equipo al menos que haya

leído y comprendido el contenido de este

manual! Cualquier falla en el seguimiento

de las instrucciones contenidas en

este manual puede resultar en un serio

lesión o muerte. Este manual contiene

importante información sobre seguridad

concerniente al mantenimiento, uso y

operación de este producto. Si usted

no puede entender el contenido de

este manual por favor pregunte a su

supervisor. Almacenar este manual en

una localización segura para la referencia

futura.

ADVERTENCIA

Ne pas utiliser cet équipement sans avoir

lu et compris le contenu de ce manuel ! Le

non-respect des instructions contenues

dans ce manuel peut entraîner de

graves blessures ou la mort. Ce manuel

contient des informations importantes

concernant l’entretien, l’utilisation et le

fonctionnement de ce produit. Si vous ne

comprenez pas le contenu de ce manuel,

veuillez le signaler à votre supérieur.

Conservez ce manuel dans un endroit

sûr pour pouvoir vous y référer plus tard.

Français = p 16

AVERTISSEMENT

hatcocorp.com

(see page 2)

S’inscrire en ligne!

(voir page 16)

Intelligent Toast-Qwik®

Conveyor Toaster • Grille-pain à convoyeur

ITQ Series • Série ITQ

Installation and Operating Manual

Manuel d’installation et d’utilisation

2Form No. ITQM-0317

English

Important Owner Information ..............................................2

Introduction 2 ...........................................................................

Important Safety Information ..............................................3

Model Description ................................................................4

Model Designation ...............................................................5

Specifications 5 .......................................................................

Plug Configurations .............................................................5

Electrical Rating Charts .......................................................5

Dimensions 6 ..........................................................................

Installation 7 .............................................................................

General 7 ................................................................................

Operation 8 ...............................................................................

General 8 ................................................................................

Touchpad Control ................................................................8

Operating the Toaster ..........................................................9

Power Save Mode ...............................................................9

Programming Menu Items .................................................10

Using the Systems Menu .................................................. 11

Maintenance 12 ........................................................................

General 12 ..............................................................................

Daily Cleaning ...................................................................12

Cleaning the Fan Filters ....................................................13

Cleaning the Bottom Element Reflector ............................13

Cleaning the Touchpad Control .........................................13

Troubleshooting Guide ......................................................14

ITQ Error Message Guide .................................................14

Options and Accessories ..................................................15

Limited Warranty ................................................................15

Authorized Parts Distributors Back Cover ...........................

IMPORTANT OWNER INFORMATION

INTRODUCTION

Hatco Intelligent Toast-Qwik® Conveyor Toasters with

Spot-On™ technology are specially-designed to automate,

accelerate, and enhance the toasting operation. Spot-On

technology senses when product is placed on the conveyor

and activates the unit. Product then passes through a heating

chamber for rapid and thorough toasting. Pre-programmed

conveyor speed and chamber temperature produce the desired

toasting color for the product being toasted.

Hatco toasters are built with quality to meet the demands

of foodservice operations and provide years of trouble-free

performance. The metal-sheathed, tubular heating elements

are guaranteed against breakage and burnout for two years.

Hatco Intelligent Toast-Qwik Conveyor Toasters are products

of extensive research and field testing. The materials used

were selected for maximum durability, attractive appearance,

and optimum performance. Every unit is inspected and tested

thoroughly prior to shipment.

This manual provides installation, safety, and operating

instructions for Intelligent Toast-Qwik Conveyor Toasters. Hatco

recommends all installation, operating, and safety instructions

appearing in this manual be read prior to installation or

operation of a unit.

Safety information that appears in this manual is identified by

the following signal word panels:

WARNING

WARNING indicates a hazardous situation which, if not

avoided, could result in death or serious injury.

CAUTION

CAUTION indicates a hazardous situation which, if not

avoided, could result in minor or moderate injury.

NOTICE

NOTICE is used to address practices not related to

personal injury.

Record the model number, serial number, voltage, and purchase

date of the unit in the spaces below (specification label located

on the back of the unit). Please have this information available

when calling Hatco for service assistance.

Model No. ________________________________________

Serial No. _________________________________________

Voltage ___________________________________________

Date of Purchase ___________________________________

Completing online warranty registration will prevent delay in

obtaining warranty coverage. Access the Hatco website at

www.hatcocorp.com, select the pull-down Parts & Service

menu, and click on “Warranty Registration”.

Business

Hours: 7:00 am pm to 5:00 Central Standard Time (CST)

(Summer Hours: June to September—

7:00 am pm to 5:00 CST Monday–Thursday

7:00 am pm to 4:00 CST Friday)

Telephone: 800-558-0607; 414-671-6350

E-mail: partsandservice@hatcocorp.com

24 Hour 7 Day Parts and Service

Assistance available in the United States

and Canada by calling 800-558-0607.

Additional information can be found by visiting our web site at

www.hatcocorp.com.

CONTENTS

Form No. ITQM-0317 3

English

IMPORTANT SAFETY INFORMATION

WARNING

ELECTRIC SHOCK HAZARD:

• Plug unit into a properly grounded electrical receptacle of

the correct voltage, size, and plug configuration. If plug

and receptacle do not match, contact a qualified electrician

to determine and install proper voltage and size electrical

receptacle.

• Put unit in standby, allow to cool, turn OFF power switch,

and unplug power cord before performing cleaning,

adjustments, maintenance, or attempting to clear a jam.

• Unit is not weatherproof. Locate unit indoors where

ambient air temperature is a minimum of 70°F (21°C) and a

maximum of 100°F (38°C).

• DO NOT submerge or saturate with water. Unit is not

waterproof. Do not operate if unit has been submerged or

saturated with water.

• Do not steam clean or use excessive water on unit.

• This unit is not “jet-proof” construction. Do not use jet-

clean spray to clean this unit.

• Do not clean unit when it is energized or hot.

• Do not allow liquids to spill into unit.

• Do not pull unit by power cord.

• Discontinue use if power cord is frayed or worn.

• Do not attempt to repair or replace a damaged power cord.

Cord must be replaced by Hatco, an Authorized Hatco

Service Agent, or a person with similar qualifications.

• Never insert a knife, fork, or similar object into toasting

chamber.

• This unit must be serviced by qualified personnel only.

Service by unqualified personnel may lead to electric

shock or burn.

• Use only Genuine Hatco Replacement Parts when service

is required. Failure to use Genuine Hatco Replacement

Parts will void all warranties and may subject operators of

the equipment to hazardous electrical voltage, resulting

in electrical shock or burn. Genuine Hatco Replacement

Parts are specified to operate safely in the environments

in which they are used. Some aftermarket or generic

replacement parts do not have the characteristics that will

allow them to operate safely in Hatco equipment.

EXPLOSION HAZARD: Do not store or use gasoline or other

flammable vapors or liquids in the vicinity of this or any other

appliance.

Make sure all operators have been instructed on the safe and

proper use of the unit.

This unit is not intended for use by children or persons with

reduced physical, sensory, or mental capabilities. Ensure

proper supervision of children and keep them away from the

unit.

If toaster overheats or cooling fans inside unit stop working,

the safety high-limit switch will shut off toaster. Contact

Authorized Service Agent or Hatco for assistance.

WARNING

FIRE HAZARD:

 • Allow a minimum clearance of 1″ (25 mm) along the

sidesandrearofunit.Allowaminimumclearanceof12″

(305 mm) in the front, measured from chamber opening

on toaster body. If safe distances are not maintained,

discoloration or combustion could occur.

 • Do notlocatetoaster undershelvingor closerthan 12″

(305 mm) from the ceiling.

• Do not place anything on top of toaster. Do not place

toaster near or underneath curtains or other combustible

materials. Items near or on top of toaster could catch fire

causing injury and/or damage to the toaster.

• In case of fire, disconnect toaster from power source

immediately. This allows unit to cool, making it easier and

safer to put out fire.

This unit has no “user-serviceable” parts. If service is required

on this unit, contact an Authorized Hatco Service Agent or

contact the Hatco Service Department at 800-558-0607 or

414-671-6350.

CAUTION

BURN HAZARD:

• Some exterior surfaces on unit will get hot. Use caution

when touching these areas.

• Do not remove crumb trays, toast chute, or toast chute

slide for cleaning until toaster is cool.

Locate unit at proper counter height in an area that is

convenient for use. Location should be level and strong

enough to support weight of unit and contents.

Always operate toaster with crumb tray(s) and toast chute

installed.

If Warning light comes on, unit is malfunctioning due to fan

failure. Turn off unit, disconnect from power supply, and have

unit serviced by a qualified technician.

NOTICE

Do not locate unit in an area subject to temperatures above

100°F (38°C) or grease from grills, fryers, etc. Excessive

temperatures and grease could cause damage to unit.

Do not locate unit in area with excessive air movement around

unit. Avoid areas that may be subject to active air movements

or currents (i.e., near exhaust fans/hoods, air conditioning

ducts, and exterior doors).

Do not locate toaster in an area that restricts air flow around

front or rear of unit.

Do not block air flow to cooling fans. Operating issues and/or

damage to unit may occur.

Do not turn off unit while cooling fans are running. Damage

to unit may occur. Put unit in standby and allow to cool for 20

minutes before turning off.

Use non-abrasive cleaners and cloths only. Abrasive cleaners

and cloths could scratch finish of unit, marring its appearance

and making it susceptible to soil accumulation.

This unit is intended for commercial use only—NOT for

household use.

Clean unit daily to avoid malfunctions and maintain sanitary

operation.

Read the following important safety information before using this equipment to avoid serious

injury or death and to avoid damage to equipment or property.

Product specificaties

Merk:	Hatco
Categorie:	Broodrooster
Model:	Intelligent Toast-Qwik ITQ-1750-2C

Heb je hulp nodig?

Als je hulp nodig hebt met Hatco Intelligent Toast-Qwik ITQ-1750-2C stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Broodrooster Hatco

Hatco Intelligent Toast-Qwik ITQ-1750-2C Handleiding

9 Juli 2023

Hatco Toast-Qwik TQ-800HBA Handleiding

8 Juli 2023

Hatco Toast-Qwik TQ-400BA Handleiding

7 Juli 2023

Hatco Toast King TK-72 Handleiding

7 Juli 2023

Hatco Toast-Qwik TQ3-2000H Handleiding

6 Juli 2023

Hatco Toast-Qwik TQ-800H Handleiding

5 Juli 2023

Hatco Toast-Qwik TQ-1800H Handleiding

2 Juli 2023

Hatco Toast-Qwik TQ-1800 Handleiding

2 Juli 2023

Hatco Toast-Qwik TQ3-500 Handleiding

1 Juli 2023

Hatco Toast-Qwik TQ3-2000 Handleiding

1 Juli 2023

Handleiding Broodrooster

Nieuwste handleidingen voor Broodrooster

Bartscher 100201 Handleiding

22 November 2024

Morphy Richards Ascend MRRGT4 Handleiding

20 November 2024

Morphy Richards Prism 248101 Handleiding

20 November 2024

Morphy Richards Accents 242041 Handleiding

20 November 2024

Cecotec ClassicToast 15000 Handleiding

20 November 2024

Cecotec Touch&Toast Double Handleiding

19 November 2024

Cecotec TrendyToast 9000 Handleiding

19 November 2024

Cecotec Toast&Taste Extra Double Handleiding

19 November 2024

Cecotec Toast&Taste Extra Handleiding

19 November 2024

Cecotec Toast&Taste 1600 Retro Double Handleiding

19 November 2024
