Gigabyte H510M H V2 Handleiding

Gigabyte Moederbord H510M H V2

Lees hieronder de 📖 handleiding in het Nederlandse voor Gigabyte H510M H V2 (29 pagina's) in de categorie Moederbord. Deze handleiding was nuttig voor 32 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/29

H510M S2H V3

H510M H V2

H510M S2 V2

User's Manual

Rev. 1001

For more product details, please visit GIGABYTE's website.

https://ww w.gigabyte.com/Motherboard/H510M-S2H-V3-rev-10?m=ma#kf

https://ww w.gigabyte.com/Motherboard/H510M-H-V2-rev-10?m=ma#kf

https://ww w.gigabyte.com/Motherboard/H510M-S2-V2-rev-10?m=ma#kf

GIGABYTE will reduce paper use in order to fulll the responsibilities of a global citizen.

Also, to reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without

prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

For detailed product information, carefully read the User's Manual.

For quick set-up of the product, refer to the Quick Installation Guide on GIGABYTE's

website.

https://download.gigabyte.com/FileList/Manual/mb_manual_installation-guide_103.pdf?m=sw

For product-related information, check on our website at: https://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"

means the revision of the motherboard is 1.0. Check your motherboard revision before updating

motherboard BIOS, drivers, or when looking for technical information.

Example:

- 3 -

Table of Contents

Chapter 1 Product Introduction 4 .......................................................................................

1-1 Motherboard Layout 4 .........................................................................................

Chapter 2 Hardware Installation 5 .....................................................................................

2-1 Installation Precautions 5 ....................................................................................

2-2 Product Specications ...................................................................................... 6

2-3 Installing the CPU and CPU Cooler 9 .................................................................

2-4 Installing the Memory 10 .....................................................................................

2-5 Installing an Expansion Card ......................................................................... 11

2-6 Back Panel Connectors 12 ..................................................................................

2-7 Internal Connectors 14 ........................................................................................

Chapter 3 BIOS Setup 23 ..................................................................................................

Chapter 4 Installing the Operating System and Drivers 25 ................................................

4-1 Operating System Installation 25 ........................................................................

4-2 Drivers Installation 26 ..........................................................................................

Chapter 5 Appendix 27 ......................................................................................................

5-1 Conguring a RAID Set .................................................................................. 27

Regulatory Notices 28 ....................................................................................................

Contact Us 29 ................................................................................................................

Product specificaties

Merk:	Gigabyte
Categorie:	Moederbord
Model:	H510M H V2
Gewicht:	385 g
Breedte:	226 mm
Diepte:	185 mm
Hoogte:	52 mm
USB-connectortype:	USB Type-A
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2304 Pixels
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	4
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
HDCP:	Ja
HDMI versie:	1.4
Ondersteunt Windows:	Windows 10 x64
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Processor socket:	LGA 1200
Processorfabrikant:	Intel
Maximum intern geheugen:	64 GB
Audio-uitgangskanalen:	7.1 kanalen
ECC:	Ja
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	Intel H510 Express
Geheugen slots type:	DIMM
Meegeleverde drivers:	Ja
PCI Express x1 slots:	2
PCI Express x16 slots:	1
Geheugen kanaal:	Dubbelkanaals
Aantal displays ondersteund:	2
Ondersteunde opslagstationinterfaces:	M.2, PCI Express 3.0, SATA III
PS/2 poort(en):	2
Component voor:	PC
Aantal SATA III connectors:	4
Non-ECC:	Ja
Compatibele processors:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Aantal storage drives ondersteund:	5
Ondersteunde geheugen types:	DDR4-SDRAM
Wifi:	Nee
Ondersteunde types opslag-drives:	HDD & SSD
Moederbord chipset familie:	Intel
Moederbord form factor:	micro ATX
Aantal geheugenslots:	2
Supported memory clock speeds:	2133,2400,2666,2933,3000,3200 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	128 Mbit
ACPI version:	5.0
Systeem Management BIOS (SMBIOS) versie:	2.7
Ondersteuning voor parallel processing:	Niet ondersteund
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	2
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	FAN, Temperature, Voltage
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
EPS power connector (8-pin):	Ja
Clear CMOS jumper:	Ja
Supported processor sockets:	LGA 1200 (Socket H5)
Aantal M.2 (M) slots:	1
12V vermogen-connector:	Ja
RGB LED-aansluitrail:	Ja
Serial port headers:	1
Versie Desktop Management Interface (DMI):	2.7
