Gigabyte GA-B250M-HD3 Handleiding

Gigabyte Moederbord GA-B250M-HD3

Lees hieronder de 📖 handleiding in het Nederlandse voor Gigabyte GA-B250M-HD3 (40 pagina's) in de categorie Moederbord. Deze handleiding was nuttig voor 18 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/40

To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

For more product details, please visit GIGABYTE's website.

GA-B250M-HD3

User's Manual

Rev. 1001

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or

by any means without GIGABYTE's prior written permission.

In order to assist in the use of this product, carefully read the User's Manual.

For product-related information, check on our website at: http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means

the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard

BIOS, drivers, or when looking for technical information.

Example:

Motherboard

GA-B250M-HD3

Nov. 30, 2016

Motherboard

GA-B250M-HD3

- 3 -

Table of Contents

GA-B250M-HD3 Motherboard Layout 4 .............................................................................

Chapter 1 Hardware Installation 5 .....................................................................................

1-1 Installation Precautions 5 ....................................................................................

1-2 ProductSpecications ...................................................................................... 6

1-3 Installing the CPU 9 ............................................................................................

1-4 Installing the Memory 9 .......................................................................................

1-5 Installing an Expansion Card 10 .........................................................................

1-6 Back Panel Connectors 10 ..................................................................................

1-7 Internal Connectors 12 ........................................................................................

Chapter 2 BIOS Setup 19 ..................................................................................................

2-1 Startup Screen 19 ...............................................................................................

2-2 M.I.T. .............................................................................................................. 20

2-3 System ........................................................................................................... 26

2-4 BIOS ............................................................................................................... 27

2-5 Peripherals ..................................................................................................... 30

2-6 Chipset ........................................................................................................... 33

2-7 Power ............................................................................................................. 34

2-8 Save & Exit 36 .....................................................................................................

Chapter 3 Appendix 37 ......................................................................................................

Drivers Installation 37 .....................................................................................................

Regulatory Statements 38 ..............................................................................................

Contact Us 40 ................................................................................................................

Product specificaties

Merk:	Gigabyte
Categorie:	Moederbord
Model:	GA-B250M-HD3
Breedte:	244 mm
Diepte:	174 mm
Ethernet LAN:	Ja
Type stroombron:	ATX
Aantal USB 2.0-poorten:	2
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
Hoofdtelefoonuitgangen:	1
DVI-D poorten:	1
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	4
Processor socket:	LGA 1151 (Socket H4)
Processorfabrikant:	Intel
Audio-uitgangskanalen:	7.1 kanalen
Ethernet interface type:	Fast Ethernet, Gigabit Ethernet
Chipset moederbord:	Intel® B250
Trusted Platform Module (TPM):	Ja
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC887
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	1
PCI Express x1 (Gen 3.x) slots:	2
PS/2 poort(en):	1
Component voor:	PC
Aantal SATA III connectors:	6
Non-ECC:	Ja
PCI-slots:	1
Compatibele processors:	Intel Celeron, Intel Pentium
Ondersteunde geheugen types:	DDR4-SDRAM
Max. aantal SMP-processoren:	1
Moederbord chipset familie:	Intel
Moederbord form factor:	micro ATX
Aantal geheugenslots:	2
Supported memory clock speeds:	2133,2400 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	16 Mbit
ACPI version:	5.0
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	1
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	FAN, Temperature, Voltage
Niet gebufferd geheugen:	Ja
Parallele port via interne header:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
S/PDIF uitgang:	Ja
EPS power connector (8-pin):	Ja
Intel® Core i3/i5/i7/i9 series:	i3-6xxx, i3-7xxx, i5-6xxx, i5-7xxx, i7-6xxx
Ondersteunde geheugenmodule capaciteiten:	4GB, 8GB, 16GB
Clear CMOS jumper:	Ja
Intel® Extreme Memory Profile (XMP):	Ja
Aantal M.2 (M) slots:	1
Serial port headers:	1
