Gigabyte GA-AB350M-D3V Handleiding

Gigabyte Moederbord GA-AB350M-D3V

Lees hieronder de 📖 handleiding in het Nederlandse voor Gigabyte GA-AB350M-D3V (39 pagina's) in de categorie Moederbord. Deze handleiding was nuttig voor 24 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/39

To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

For more product details, please visit GIGABYTE's website.

GA-AB350M-D3V

User's Manual

Rev. 1001

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by

any means without GIGABYTE's prior written permission.

In order to assist in the use of this product, carefully read the User's Manual.

For product-related information, check on our website at: http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means

the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard

BIOS, drivers, or when looking for technical information.

Example:

Motherboard

GA-AB350M-D3V

Apr. 28, 2017

Motherboard

GA-AB 350M-D3V

- 3 -

Table of Contents

GA-AB350M-D3V Motherboard Layout 4 ...........................................................................

Chapter 1 Hardware Installation 5 .....................................................................................

1-1 Installation Precautions 5 ....................................................................................

1-2 ProductSpecications ...................................................................................... 6

1-3 Installing the CPU 9 ............................................................................................

1-4 Installing the Memory 9 .......................................................................................

1-5 Installing an Expansion Card 10 .........................................................................

1-6 Back Panel Connectors 10 ..................................................................................

1-7 Internal Connectors 12 ........................................................................................

Chapter 2 BIOS Setup 19 ..................................................................................................

2-1 Startup Screen 19 ...............................................................................................

2-2 M.I.T. .............................................................................................................. 20

2-3 System ........................................................................................................... 24

2-4 BIOS ............................................................................................................... 25

2-5 Peripherals ..................................................................................................... 28

2-6 Chipset ........................................................................................................... 30

2-7 Power ............................................................................................................. 31

2-8 Save & Exit 33 .....................................................................................................

Chapter 3 Appendix 34 ......................................................................................................

3-1 ConguringaRAIDSet .................................................................................. 34

3-2 Drivers Installation 36 ..........................................................................................

RegulatoryStatements .............................................................................................. 37

Contact Us 39 ................................................................................................................

Product specificaties

Merk:	Gigabyte
Categorie:	Moederbord
Model:	GA-AB350M-D3V
Breedte:	244 mm
Diepte:	195 mm
Gebruikershandleiding:	Ja
Ethernet LAN:	Ja
Maximum resolutie:	1920 x 1200 Pixels
Type stroombron:	ATX
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	2
VGA (D-Sub)poort(en):	1
Aantal Ethernet LAN (RJ-45)-poorten:	1
DVI-D poorten:	1
Plug and play:	Ja
Meegeleverde software:	Norton Internet Security, cFosSpeed
Ondersteunt Windows:	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 7 Enterprise x64, Windows 7 Home Basic x64, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate x64
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	3
Processor socket:	Socket AM4
Processorfabrikant:	AMD
Maximum intern geheugen:	32 GB
Audio-uitgangskanalen:	7.1 kanalen
ECC:	Ja
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	AMD B350
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	1
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC887
Meegeleverde drivers:	Ja
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	1
PS/2 poort(en):	1
Component voor:	PC
Soorten RAID:	0, 1,10
Aantal SATA III connectors:	4
Non-ECC:	Ja
Compatibele processors:	AMD A, AMD Athlon, AMD Athlon X4, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Ondersteunde geheugen types:	DDR4-SDRAM
Max. aantal SMP-processoren:	1
PCI Express x1 (Gen 2.x) slots:	2
Moederbord chipset familie:	AMD
Moederbord form factor:	micro ATX
Aantal geheugenslots:	2
Supported memory clock speeds:	2133,2400,2667 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	128 Mbit
ACPI version:	5.0
Systeem Management BIOS (SMBIOS) versie:	2.7
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	1
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	FAN, Temperature, Voltage
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
Chassis intrusion aansluiting:	Ja
S/PDIF uitgang:	Ja
Clear CMOS jumper:	Ja
Intel® Extreme Memory Profile (XMP):	Ja
Aantal M.2 (M) slots:	1
12V vermogen-connector:	Ja
Serial port headers:	1
Audioconnector:	Ja
Versie Desktop Management Interface (DMI):	2.7
