GA-970A-DS3P FX

User's Manual

Rev. 2101

12ME-97AD3PX-2101R

To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

For more product details, please visit GIGABYTE's website.

Motherboard

GA-970A-DS3P FX

Jul. 28, 2017

Motherboard

GA-970A-DS3P FX

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or

by any means without GIGABYTE's prior written permission.

In order to assist in the use of this product, carefully read the User's Manual.

For product-related information, check on our website at: http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means

the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard

BIOS, drivers, or when looking for technical information.

Example:

- 3 -

Table of Contents

GA-970A-DS3P FX Motherboard Layout 4 ........................................................................

Chapter 1 Hardware Installation 5 .....................................................................................

1-1 Installation Precautions 5 ....................................................................................

1-2 Product Specications ...................................................................................... 6

1-3 Installing the CPU 8 ............................................................................................

1-4 Installing the Memory 8 .......................................................................................

1-5 Installing an Expansion Card 9 ...........................................................................

1-6 Back Panel Connectors 9 ....................................................................................

1-7 Internal Connectors 10 ........................................................................................

Chapter 2 BIOS Setup 15 ..................................................................................................

2-1 Startup Screen 15 ...............................................................................................

2-2 M.I.T. .............................................................................................................. 16

2-3 System Information 20 ........................................................................................

2-4 BIOS Features 21 ...............................................................................................

2-5 Peripherals ..................................................................................................... 23

2-6 Power Management 25 .......................................................................................

2-7 Save & Exit 26 .....................................................................................................

Chapter 3 Appendix 27 ......................................................................................................

3-1 Conguring a RAID Set .................................................................................. 27

3-2 Drivers Installation 30 ..........................................................................................

Regulatory Statements 31 ..............................................................................................

Contact Us 32 ................................................................................................................

Product specificaties

Merk:	Gigabyte
Categorie:	Moederbord
Model:	GA-970A-DS3P FX
Breedte:	305 mm
Diepte:	214 mm
Ethernet LAN:	Ja
Type stroombron:	ATX
Aantal USB 2.0-poorten:	6
Aantal Ethernet LAN (RJ-45)-poorten:	1
Meegeleverde software:	Norton Internet Security
Ondersteunt Windows:	Windows 10, Windows 7, Windows 8.1
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Processor socket:	Socket AM3+
Processorfabrikant:	AMD
Maximum intern geheugen:	32 GB
Audio-uitgangskanalen:	7.1 kanalen
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	AMD 990FX
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC887
PCI Express x1 slots:	3
PCI Express x16 slots:	2
Geheugen kanaal:	Dubbelkanaals
PS/2 poort(en):	2
Component voor:	PC
Soorten RAID:	0, 1,5, 10, JBOD
Aantal SATA III connectors:	6
PCI-slots:	2
Compatibele processors:	AMD FX, AMD Phenom II Dual-Core Mobile, AMD Phenom II Quad-Core Mobile, AMD Phenom II Triple-Core Mobile
Ondersteunde geheugen types:	DDR3-SDRAM
Moederbord southbridge:	AMD SB950
Max. aantal SMP-processoren:	1
Moederbord chipset familie:	AMD
Moederbord form factor:	ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	1066,1333,1600,1866,2000 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	64 Mbit
ACPI version:	5.0
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	2
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
Aansluiting voor ventilator van voeding:	Ja
USB 2.0 aansluitingen:	3
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	CPU, FAN, Temperature, Voltage
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
S/PDIF uitgang:	Ja
Clear CMOS jumper:	Ja
12V vermogen-connector:	Ja
