Pagina 1/38

B760I AORUS PRO

B760I AORUS PRO DDR4

User's Manual

Rev. 1103

GIGABYTE will reduce paper use in order to fulll the responsibilities of a global citizen.

Also, to reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

For more product details, please visit GIGABYTE's website.

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without

prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

For detailed product information, carefully read the User's Manual.

For quick set-up of the product, refer to the Quick Installation Guide on GIGABYTE's

website.

https://download.gigabyte.com/FileList/Manual/mb_manual_quick-guide_am5.pdf?m=sw

For product-related information, check on our website at: https://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"

means the revision of the motherboard is 1.0. Check your motherboard revision before updating

motherboard BIOS, drivers, or when looking for technical information.

Example:

- 3 -

Table of Contents

Chapter 1 Product Introduction .......................................................................................4

1-1 Motherboard Layout ......................................................................................... 4

1-2 Motherboard Block Diagram ............................................................................ 6

Chapter 2 Hardware Installation .....................................................................................7

2-1 Installation Precautions .................................................................................... 7

2-2 Product Specications ...................................................................................... 8

2-3 Installing the CPU and CPU Cooler ............................................................... 11

2-4 Installing the Memory ..................................................................................... 14

2-5 Installing an Expansion Card 15 .........................................................................

2-6 Back Panel Connectors .................................................................................. 16

2-7 Internal Connectors 18 ........................................................................................

Chapter 3 BIOS Setup ..................................................................................................29

Chapter 4 Installing the Operating System and Drivers ................................................31

4-1 Operating System Installation ........................................................................ 31

4-2 Drivers Installation 32 ..........................................................................................

Chapter 5 Appendix ......................................................................................................33

5-1 Conguring a RAID Set .................................................................................. 33

Regulatory Notices .................................................................................................... 34

Contact Us 38 ................................................................................................................

Product specificaties

Merk:	Gigabyte
Categorie:	Moederbord
Model:	B760I Aorus Pro
Breedte:	170 mm
Diepte:	170 mm
Bluetooth:	Ja
Wi-Fi-standaarden:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth-versie:	5.3
USB-connectortype:	USB Type-A, USB Type-C
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2304 Pixels
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	2
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
Hoofdtelefoonuitgangen:	2
HDCP:	Ja
HDMI versie:	2.0
Aantal DisplayPorts:	1
Meegeleverde software:	Norton Internet Security
Wifi-standaard:	Wi-Fi 6E (802.11ax)
Ondersteunt Windows:	Windows 10 x64, Windows 11 x64
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	4
Processor socket:	LGA 1700
Processorfabrikant:	Intel
Maximum intern geheugen:	96 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	7.1 kanalen
ECC:	Ja
Ethernet interface type:	2.5 Gigabit Ethernet
Chipset moederbord:	Intel B760 Express
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	1
DisplayPort versie:	1.2
Geheugen slots type:	DIMM
PCI Express x16 slots:	1
S/PDIF-uitgang:	Ja
RAID support:	Ja
Geheugen kanaal:	Dubbelkanaals
Ondersteunde opslagstationinterfaces:	M.2, SATA III
Component voor:	PC
Soorten RAID:	0, 1
Aantal SATA III connectors:	2
Non-ECC:	Ja
Compatibele processors:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold
Aantal storage drives ondersteund:	4
Ondersteunde geheugen types:	DDR5-SDRAM
Wifi:	Ja
Ondersteunde types opslag-drives:	HDD & SSD
Moederbord chipset familie:	Intel
Moederbord form factor:	mini ITX
Aantal geheugenslots:	2
Supported memory clock speeds:	4000,4800,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,8000 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	256 Mbit
ACPI version:	5.0
Systeem Management BIOS (SMBIOS) versie:	2.7
Ondersteuning voor parallel processing:	Niet ondersteund
Aansluiting voor CPU koeler:	Ja
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
USB 2.0 aansluitingen:	1
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	FAN, Temperature, Voltage, Water cooling
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	2
Chassis intrusion aansluiting:	Ja
EPS power connector (8-pin):	Ja
WiFi-AP antenna jack:	2
Clear CMOS jumper:	Ja
Supported processor sockets:	LGA 1700
Aantal M.2 (M) slots:	2
12V vermogen-connector:	Ja
RGB LED-aansluitrail:	Ja
Audioconnector:	Ja
Versie Desktop Management Interface (DMI):	2.7
Ondersteunde geheugenkloksnelheid (max):	8000 MHz
