For more product details, please visit GIGABYTE's website.

To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

B360M D3P

User's Manual

Rev. 1001

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or

by any means without GIGABYTE's prior written permission.

In order to assist in the use of this product, carefully read the User's Manual.

For product-related information, check on our website at: http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means

the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard

BIOS, drivers, or when looking for technical information.

Example:

Motherboard

B360M D3P

Mar. 9, 2018

Motherboard

B360M D3P

- 3 -

Table of Contents

B360M D3P Motherboard Layout 4 ....................................................................................

Chapter 1 Hardware Installation 5 .....................................................................................

1-1 Installation Precautions 5 ....................................................................................

1-2 ProductSpecications ...................................................................................... 6

1-3 Installing the CPU 9 ............................................................................................

1-4 Installing the Memory 9 .......................................................................................

1-5 Installing an Expansion Card 10 .........................................................................

1-6 Back Panel Connectors 10 ..................................................................................

1-7 Internal Connectors 13 ........................................................................................

Chapter 2 BIOS Setup 19 ..................................................................................................

2-1 Startup Screen 19 ...............................................................................................

2-2 The Main Menu 20 ..............................................................................................

2-3 M.I.T. .............................................................................................................. 21

2-4 System ........................................................................................................... 27

2-5 BIOS ............................................................................................................... 28

2-6 Peripherals ..................................................................................................... 31

2-7 Chipset ........................................................................................................... 34

2-8 Power ............................................................................................................. 35

2-9 Save & Exit 37 .....................................................................................................

Chapter 3 Appendix 38 ......................................................................................................

3-1 Installing an Intel® Optane™ Memory 38 ..............................................................

3-2 Drivers Installation 39 ..........................................................................................

Regulatory Statements 40 ..............................................................................................

Contact Us 44 ................................................................................................................

Product specificaties

Merk:	Gigabyte
Categorie:	Moederbord
Model:	B360M D3P
Breedte:	244 mm
Diepte:	230 mm
Gebruikershandleiding:	Ja
Grafische adapter:	HD Graphics
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2304 Pixels
Type stroombron:	ATX
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	2
Aantal Ethernet LAN (RJ-45)-poorten:	1
HDCP:	Ja
Plug and play:	Ja
Aantal DisplayPorts:	2
Meegeleverde software:	Norton Internet Security, cFosSpeed
Ondersteunt Windows:	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Processor socket:	LGA 1151 (Socket H4)
Processorfabrikant:	Intel
Maximum intern geheugen:	64 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	7.1 kanalen
ECC:	Ja
Ethernet interface type:	Gigabit Ethernet
DVI-I poorten:	1
Chipset moederbord:	Intel B360 Express
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	1
DisplayPort versie:	1.2
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC892
Meegeleverde drivers:	Ja
PCI Express x1 slots:	2
PCI Express x16 slots:	2
Grafische adapter-familie:	Intel
Geheugen kanaal:	Dubbelkanaals
Intel® Optane™ Memory Ready:	Ja
Aantal displays ondersteund:	3
PS/2 poort(en):	1
Component voor:	PC
Maximum geheugen grafische adapter:	1024 MB
Aantal SATA III connectors:	6
Non-ECC:	Ja
Compatibele processors:	Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Ondersteunde geheugen types:	DDR4-SDRAM
Max. aantal SMP-processoren:	1
Moederbord chipset familie:	Intel
Moederbord form factor:	micro ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	2133,2400,2666 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	128 Mbit
ACPI version:	5.0
Systeem Management BIOS (SMBIOS) versie:	2.7
Ondersteuning voor parallel processing:	CrossFire
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	3
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	FAN, Temperature, Voltage
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
S/PDIF uitgang:	Ja
Clear CMOS jumper:	Ja
Intel® Extreme Memory Profile (XMP):	Ja
Aantal M.2 (M) slots:	1
12V vermogen-connector:	Ja
Thunderbolt-headers:	1
Serial port headers:	1
Versie Desktop Management Interface (DMI):	2.7
