R32
REFRIGERANT
This Air Conditioner contains and
operates with ref rigerant R32.
THIS PRODUCT MUST ON BE INSTALLED OR SERVICEDLY
BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation,
regulations, codes, installation & operation manuals, before
the installation, maintenance or service of this product.
AIR CONDITIONER
MODEL:
Wall Mounted Type
OPERATING MANUAL
Before using this product, read these instructions
thoroughly. Also, keep this manual for future
reference, together with the installation manuals for
the indoor and outdoor units.
PART No. 9387081237
* Please write down the model name.
(Refer to the rating label.)
En-1
1. SAFETY PRECAUTIONS
To prevent personal injury or property damage, read this section
carefully before you use this product, and be sure to comply
with the following safety precautions.
Incorrect operation due to failure to follow the instructions may
cause harm or damage, the seriousness of which is classiîš¿ed
as follows:
WARNING
This mark warns of death or serious injury.
CAUTION
This mark warns of injury or damage to property.
This mark denotes an action that is PROHIBITED.
This mark denotes an action that is COMPULSORY.
Explanation of symbols displayed on the indoor unit or outdoor unit.
WARNING
This symbol shows that this product uses a
ammable refrigerant. If the refrigerant is leaked and
exposed to an external ignition source, there is a risk
of îš¿re.
CAUTION
This symbol shows that the operating manual should
be read carefully.
CAUTION
This symbol shows that a service personnel should
be handling this equipment with reference to the
installation manual.
CAUTION
This symbol shows that information is available such
as the operating manual or installation manual.
WARNING
• The appliance shall be installed, operated and stored
in a room with a oor area larger than X m².
Amount of refrigerant charge
M (kg)
Minimum room area
X (m2)
M ≤ 1.22
-
1.22 < M ≤ 1.23 1.45
1.23 < M ≤ 1.50 2.15
1.50 < M ≤ 1.75
2.92
1.75 < M ≤ 2.0 3.82
2.0 < M ≤ 2.5 5.96
2.5 < M ≤ 3.0
8.59
3.0 < M ≤ 3.5 11.68
3.5 < M ≤ 4.0 15.26
(IEC 60335-2-40)
• This product contains no user-serviceable parts.
Always consult authorized service personnel for
repairing, installation, and relocation of this product.
Improper installation or handling will cause leakage,
electric shock, or îš¿re.
• In the event of a malfunction such as burning smell,
immediately stop operation of the air conditioner, and
disconnect all the power supply by turning o󰀨 the
electrical breaker or disconnecting the power plug.
Then consult authorized service personnel.
• Take care not to damage the power supply cable.
If it is damaged, it should be replaced only by
authorized service personnel in order to avoid a
hazard.
• In the event of refrigerant leakage, be sure to keep
away from re or any ammables, and consult
authorized service personnel.
• In the event of a thunder storm or any prior sign
of a lightning strike, turn o󰀨 the air conditioner via
the remote controller, and refrain from touching the
product or the power source to prevent any electrical
hazards.
• This product shall be stored in a room without
continuously operating ignition sources (for example:
open ames, an operating gas appliance or an
operating electric heater).
• This product shall be stored in a well-ventilated area.
• Be aware that refrigerants may not contain an odour.
• This product shall be stored so as to prevent
mechanical damage from occurring.
• Disposing of the product shall be done properly, in
compliance with national or regional regulations.
• During transportation or relocation of the indoor unit,
pipes shall be covered with the wall hook bracket for
protection.
Do not move this product by holding the indoor unit pipes.
(The stress applied to the pipe joints may cause the
ammable gas to leak during operation).
Contents
1. SAFETY PRECAUTIONS 1 ..........................................
2. PREPARATION ......................................................... 2
3. NAME OF PARTS 3 .....................................................
3.1. Indoor unit 3 ........................................................
3.2. Remote controller 3 .............................................
4. BASIC OPERATIONS 5 ...............................................
5. AIRFLOW SETTINGS 5 ...............................................
5.1. Fan speed setting 5 .............................................
5.2. Airow direction setting .................................... 5
6. TIMER OPERATIONS 5 ...............................................
6.1. Weekly timer 6 .....................................................
6.2. On timer or O󰀨 timer ......................................... 6
6.3. Program timer 6 ...................................................
6.4. Sleep timer 6 ......................................................
7. ENERGY SAVING OPERATIONS 7 ............................
7.1. Economy operation 7 ..........................................
7.2. Human sensor for energy saving 7 .....................
7.3. Fan control for energy saving 7 ...........................
7.4. Demand Response 7 ...........................................
8. OTHER OPERATIONS 8 .............................................
8.1. Powerful operation 8 ...........................................
8.2. Outdoor Unit Low Noise operation 8 ...................
8.3. 10 °C Heat operation 8 ........................................
9. SETTINGS ON INSTALLATION 8 ................................
9.1. Remote controller custom code setting 8 ............
10. CLEANING AND CARE 9 .............................................
11. GENERAL INFORMATION ..................................... 11
12. OPTIONAL PARTS ................................................. 11
12.1. Wired remote controller 11 ..................................
12.2. Wireless LAN control 11 ......................................
13. TROUBLESHOOTING ............................................ 13
En-2
WARNING
• This product is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of this product by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with this product.
• Dispose of the packing materials safely. Tear and
dispose of the plastic packing bags so that children
cannot play with them. There is danger of su󰀨ocation
if children play with the original plastic bags.
• Do not install the unit in area lled with mineral oil
such as a factory or area containing a large amount of
splashed oil or steam such as a kitchen.
• Do not start or stop the operation of this product by
inserting or pulling out the power plug, or by turning
on or o󰀨 the circuit breaker.
• Do not use ammable gases near this product.
• Do not expose yourself directly to the cooling airow
for many hours.
• Do not insert your ngers or any other objects into
outlet port or inlet port.
• Do not operate with wet hands.
• Do not use means to accelerate the defrosting
process or to clean this product, other than those
recommended by the manufacturer.
• Do not pierce or burn.
CAUTION
• Provide occasional ventilation during use.
• Always operate this product with air lters installed.
• Ensure that any electronic equipment is at least 1 m
(40 in) away from this product.
• Disconnect all the power supply when not using this
product for extended periods.
• After a long period of use, ensure to get the mounting
of the indoor unit checked to prevent this product from
falling down.
• The airow direction and the room temperature should
be carefully considered when you use this product in a
room with infants, children, elderly or sick persons.
• Keep the surroundings of the outdoor unit clean and
tidy, and do not place items around it. Any objects
blocking or entering from the outlet ports may cause
product malfunction.
• Do not direct the airow at replaces or heating apparatus.
• Do not block or cover the intake grille and the outlet port.
• Do not apply any heavy pressure to radiator ns.
• Do not climb on, place objects on, or hang objects
from this product.
• Do not place any other electrical products or household
belongings under this product. Dripping condensation
from this product might get them wet, and may cause
damage or malfunction of your property.
• Do not expose this product directly to water.
• Do not use this product for preservation of food, plants,
animals, precision equipment, art work, or other objects.
This may cause quality deterioration of those items.
• Do not expose animals or plants to the direct airow.
• Do not drink the drainage from the air conditioner.
• Do not pull the power supply cable.
• Do not touch the aluminum ns of heat exchanger
built-in this product to avoid personal injury when you
maintain the unit.
• Do not stand on unstable steps when operating or cleaning
this product. It may overturn and can cause injury.
This product contains uorinated greenhouse gases.
2. PREPARATION
WARNING
• Take care to prevent infants and young children from
accidentally swallowing the batteries.
CAUTION
• If leaking battery uid comes in contact with your skin,
eyes, or mouth, immediately rinse with plenty of clean
water, and consult your physician.
• Exhausted batteries must be removed immediately, and be
disposed according to the local laws and regulations of your region.
• Do not attempt to recharge dry batteries.
• Do not use dry batteries that has been recharged.
Indoor unit accessories
Please check that the following accessories are included.
Remote controller
Remote controller holder
Tapping screws
Batteries Filter holdersAir cleaning îš¿lters
Remote controller holder installation
321
Battery loading and remote controller preparation
(R03/LR03/AAA x 2)
5
7
6
4
8
1
2
3
1~3. Put batteries as shown in the îš¿gure above.
4. Press to start clock setting.
5.
Press
( )
to set day of the week (Monday to Sunday).
* By pressing , the time indicator can be changed
from a 24-hour to a 12-hour clock.
6. Press to continue.
7. Press
( )
to set the clock.
Press the buttons to change the clock by a minute.
Press down the buttons to change the clock by 10 minutes.
8. Press to complete the setting.
Be close to the indoor unit. If you press the button from a
distance, settings may not be properly sent.
NOTES:
• Use specied type of batteries only.
• Do not mix di󰀨erent types or new and used batteries together.
• Batteries can be used about 1 year in ordinary use.
• If the remote control range noticeably shortens, replace the
batteries, and press as shown in page 4.
• When you replace the batteries, the settings will be initialized.
Insert
Screws Slide up
Product specificaties
| Merk: | Fujitsu |
| Categorie: | Airco |
| Model: | ASTG34KMTC |
Heb je hulp nodig?
Als je hulp nodig hebt met Fujitsu ASTG34KMTC stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Airco Fujitsu
6 November 2024
2 November 2024
25 September 2024
3 September 2024
3 September 2024
3 September 2024
3 September 2024
3 September 2024
3 September 2024
3 September 2024
Handleiding Airco
- Airco Electrolux
- Airco Bosch
- Airco Candy
- Airco Samsung
- Airco Delonghi
- Airco Panasonic
- Airco LG
- Airco AEG
- Airco Bauknecht
- Airco BEKO
- Airco Daewoo
- Airco Grundig
- Airco Honeywell
- Airco Inventum
- Airco Karcher
- Airco Medion
- Airco Remeha
- Airco Siemens
- Airco Toshiba
- Airco Unold
- Airco Vaillant
- Airco Whirlpool
- Airco Zanussi
- Airco Zibro
- Airco Adler
- Airco Airwell
- Airco Akai
- Airco Amana
- Airco Amcor
- Airco Apc
- Airco Arcelik
- Airco Argo
- Airco Balay
- Airco Bartscher
- Airco Bavaria
- Airco Be Cool
- Airco Bestron
- Airco Blaupunkt
- Airco Blumfeldt
- Airco Bodin
- Airco Bomann
- Airco Brandt
- Airco D-Let
- Airco Daikin
- Airco Daitsu
- Airco Defy
- Airco Dimplex
- Airco Dometic
- Airco Domo
- Airco Duracraft
- Airco Duux
- Airco Easy Home
- Airco Eco-De
- Airco Eden
- Airco Edgestar
- Airco Edy
- Airco Einhell
- Airco Emerio
- Airco Emerson
- Airco Eurom
- Airco Everglades
- Airco Evolar
- Airco Exquisit
- Airco Fairland
- Airco Ferroli
- Airco Finlux
- Airco Firstline
- Airco Fral
- Airco Frigidaire
- Airco Frilec
- Airco Fronius
- Airco Fuave
- Airco Fuji Electric
- Airco G3 Ferrari
- Airco GE
- Airco General Electric
- Airco GlobalTronics
- Airco Gorenje
- Airco Gree
- Airco Gutfels
- Airco H.Koenig
- Airco Haier
- Airco Hisense
- Airco Hitachi
- Airco Holland Electro
- Airco Home Electric
- Airco Hotpoint
- Airco Hotpoint-Ariston
- Airco HQ
- Airco Hyundai
- Airco Iceberg
- Airco Innoliving
- Airco Insignia
- Airco Itho
- Airco Kalorik
- Airco Kelvinator
- Airco Kenmore
- Airco Klarstein
- Airco Koenic
- Airco Kogan
- Airco Korona
- Airco Lanaform
- Airco Lavorwash
- Airco Livington
- Airco Livoo
- Airco Logik
- Airco Maiko
- Airco Manta
- Airco Master
- Airco Maxicool
- Airco Meaco
- Airco Meireles
- Airco Melissa
- Airco Mesko
- Airco Mestic
- Airco Midea
- Airco Mistral
- Airco Mitsubishi
- Airco Moa
- Airco MPM
- Airco MundoClima
- Airco Nabo
- Airco Nedis
- Airco Philco
- Airco Prem-i-air
- Airco Primo
- Airco Princess
- Airco Profile
- Airco Progress
- Airco Proklima
- Airco Proline
- Airco Protector
- Airco Qlima
- Airco RCA
- Airco REMKO
- Airco Rotel
- Airco Rowenta
- Airco Royal Sovereign
- Airco Russell Hobbs
- Airco Sanyo
- Airco Sauber
- Airco Saunier Duval
- Airco Sencor
- Airco Sencys
- Airco Sharp
- Airco Sigma
- Airco SMC
- Airco Sonnenkonig
- Airco SPT
- Airco Starlyf
- Airco Stirling
- Airco Suntec
- Airco Tarrington House
- Airco Taurus
- Airco TCL
- Airco Team
- Airco Technisat
- Airco Teco
- Airco Tectro
- Airco Telefunken
- Airco Termozeta
- Airco Thomson
- Airco Tomado
- Airco Tosot
- Airco Toyotomi
- Airco Trilec
- Airco Tristar
- Airco Tronix
- Airco Trotec
- Airco Truma
- Airco Ufesa
- Airco Vestel
- Airco Vivax
- Airco Waeco
- Airco Westinghouse
- Airco White Knight
- Airco Whynter
- Airco Woods
- Airco Zelmer
- Airco Jocca
- Airco Jocel
- Airco Just Fire
- Airco OK
- Airco Olimpia Splendid
- Airco OneConcept
- Airco Oregon Scientific
- Airco Ozito
- Airco Becken
- Airco Black And Decker
- Airco Camry
- Airco Clatronic
- Airco Concept
- Airco ECG
- Airco Elba
- Airco Essentiel B
- Airco Guzzanti
- Airco Heinner
- Airco Khind
- Airco Orbegozo
- Airco Profilo
- Airco Trisa
- Airco Vox
- Airco Wilfa
- Airco Anslut
- Airco Kunft
- Airco Soler And Palau
- Airco Conrad
- Airco Ansonic
- Airco Aspes
- Airco Comfee
- Airco Corberó
- Airco Danby
- Airco Equator
- Airco Esatto
- Airco IFB
- Airco Infiniton
- Airco Koldfront
- Airco Listo
- Airco Orima
- Airco Svan
- Airco Ardes
- Airco Eldom
- Airco Premium
- Airco Teesa
- Airco Alpatec
- Airco ElectriQ
- Airco Heylo
- Airco HTW
- Airco Prime3
- Airco Avidsen
- Airco SereneLife
- Airco DCG
- Airco Kubo
- Airco Malmbergs
- Airco Challenge
- Airco Calor
- Airco Riffel
- Airco Broan
- Airco RIDGID
- Airco KDK
- Airco Bimar
- Airco Climadiff
- Airco Tripp Lite
- Airco Mabe
- Airco Equation
- Airco Godrej
- Airco Milectric
- Airco Orava
- Airco Simplicity
- Airco Cecotec
- Airco Baxi
- Airco Thermex
- Airco Keystone
- Airco Sanus
- Airco Carrier
- Airco Furrion
- Airco Rinnai
- Airco Carson
- Airco Artrom
- Airco Carrefour Home
- Airco Céliera
- Airco Commercial Cool
- Airco Coolix
- Airco Hokkaido
- Airco Kibernetik
- Airco Norpole
- Airco Senville
- Airco SHE
- Airco CyberPower
- Airco Perfect Aire
- Airco Be Quiet!
- Airco Ariston Thermo
- Airco Element
- Airco Dantherm
- Airco Argoclima
- Airco DEXP
- Airco Chigo
- Airco Elgin
- Airco Evapolar
- Airco EcoFlow
- Airco Liebert
- Airco Avalon Bay
- Airco NewAir
- Airco Braemar
- Airco ActronAir
- Airco Klimaire
- Airco Consul
- Airco SEEGER
- Airco LERAN
- Airco Friedrich
- Airco Aerian
- Airco Polocool
- Airco Convair
- Airco Companion
- Airco Volteno
- Airco Arcoaire
- Airco AFINTEK
- Airco Brivis
- Airco MRCOOL
- Airco B-Air
- Airco Monzana
- Airco Kaden
- Airco Geist
- Airco GoldAir
- Airco Avallon
- Airco Ravanson
- Airco Create
- Airco Columbia Vac
- Airco TURBRO
- Airco House & Luft
- Airco Daizuki
- Airco Bonaire
- Airco Evapcool
- Airco Vostok
- Airco American Comfort
- Airco Ocean Breeze
- Airco Quirky
- Airco Krone
- Airco KwiKool
- Airco Big Ass Fans
- Airco Arctic King
- Airco Omega Altise
- Airco Climachill
- Airco Heat Controller
- Airco Luma Comfort
- Airco AireMax
- Airco Kaco
- Airco Middle Atlantic
- Airco Goodwe
- Airco Swegon
- Airco InAlto
- Airco JHS
- Airco FREONIC
- Airco ARCTIC WIND
- Airco Electroline
- Airco BLUEPALM
- Airco KuulAire
- Airco Cool-Space
- Airco BOSFOR
- Airco Aconatic
- Airco VänEE
- Airco Mayer
- Airco Yamazen
- Airco Corona
- Airco Symphony
Nieuwste handleidingen voor Airco
4 December 2024
4 December 2024
4 December 2024
4 December 2024
4 December 2024
4 December 2024
4 December 2024
4 December 2024
3 December 2024
3 December 2024
