user manual

Integrated BBQ 600/300mm

INTBBQ600/300_Jun11.indd 1 30/06/11 11:52 AM

2 contents electrolux integrated bbq 600/300mm

Congratulations

Congratulations and thank you for choosing our barbecue.

We are sure you will ﬁnd your new appliance a pleasure to

use. Before you use the appliance, we recommend that you

read through the entire user manual, which provides the

description of the appliance and its functions.

To avoid the risks that are always present when you use a

gas appliance, it is important that the appliance is installed

correctly and that you read the safety instructions carefully

to avoid misuse and hazards.

We recommend that you keep this instruction booklet

for future reference and pass it on to any future owners.

After unpacking the appliance please check it is not damaged.

If in doubt, do not use the appliance but contact your local

Electrolux Customer Care Centre.

CONDITIONS OF USE

This appliance is intended to be used in household and

similar applications such as:

• Farm houses

• By clients in holiday apartments and other residential

type environments.

Contents

• Important safety instructions 3

• Product Description 4

• Contents of Integrated BBQ 600/300mm 7

• Assembling the barbecue 8

• Gas specications 9

• Gas connection detail 9

• Natural gas installation 10

• Universal LPG installation 11

• Gas bottle safety information 12

• Leak test procedure 12

• Installation warnings 13

• Installation instructions 13

• Gas requirements 17

• Fitting the slimline lid or roasting hood 17

• Options for conguration of hotplates and grills 18

• Operating instructions 18

• Using the roasting hood 19

• Lid safety leg – slimline lid only 19

• Cleaning and care 20

• Maintenance 21

• Troubleshooting 21

• Notes 22

• Warranty 23

INTBBQ600/300_Jun11.indd 2 30/06/11 11:52 AM

electrolux integrated bbq 600/300mm important safety instructions 3

before you call

Please ensure you read the instruction manual fully

before you call for service, or a full service fee could

be applicable.

warning

This appliance MUST be installed and serviced by a

qualiﬁed licensed person only.

Improper installation, adjustment, alteration or maintenance

can cause injury or property damage. Please contact

your nearest Electrolux Service Department for additional

information or assistance for an approved installer.

NOTE TO THE INSTALLER

THIS MANUAL MUST REMAIN WITH THE OWNER FOR

FUTURE REFERENCE

warning

IF YOU SMELL GAS, do not attempt to light the barbecue.

Locate the leak and re-tighten the leaking joint. Carry out

the Leak Test procedure as described in this manual. If the

leak persists, turn off the gas supply and call Electrolux

Service or a Licensed Gas Fitter.

warning

Do not lean over barbecue when lighting.

Do not leave the barbecue unattended when alight.

Do not delay lighting once the gas has been turned on.

Do not store or use aerosol cans in the vicinity of

the barbecue.

Do not store ammable liquids in the vicinity of

the barbecue.

Do not use caustic or abrasive based cleaners

on the barbecue.

Do not operate the barbecue with the cover on.

Do not attempt to dismantle or adjust the

control valves.

Do not attempt to dismantle or adjust the regulator.

Do not test for leaks with a naked ame.

Do not modify the construction of this appliance or

modify the injector orice size.

Do not obstruct any ventilation of the barbecue.

Do not allow children to operate or play near

the barbecue.

caution

This barbecue is supplied set up for Natural Gas and

is labelled accordingly. A Universal LPG conversion

kit is available for purchase from Electrolux Service

or Spare Parts. Conversion of this unit to Universal

LPG must be carried out by a qualied licensed

person and a Certicate of Compliance must be

issued to the owner on completion of the

installation and conversion.

Important safety instructions

For your safety please read this user manual carefully

before operating your barbecue and store in a handy place

for later reference. Pass the user manual on to possible

new owners of the barbecue.

The symbols you will see in this booklet have these meanings:

warning

This symbol indicates information concerning your

personal safety

caution

This symbol indicates information on how to avoid

damaging the barbecue

tips and information

This symbol indicates tips and information about use

of the barbecue

environmental tip

This symbol indicates tips and information about

economical and ecological use of the barbecue

This symbol indicates never to do this

This symbol indicates always do this

environmental tip

Information on disposal for users

• Most of the packing materials are recyclable.

Please dispose of those materials through your local

recycling depot or by placing them in appropriate

collection containers.

• If you wish to discard this product, please contact

your local authorities and ask for the correct method

of disposal.

INTBBQ600/300_Jun11.indd 3 30/06/11 11:52 AM

4 product description electrolux integrated bbq 600/300mm

Product description EQBH60AS

1 Roasting hood

2 Temperature indicator

3 Burner controls

4 Warming racks

5 Grill

6 Hotplate

7 Gas connection point

INTBBQ600/300_Jun11.indd 4 30/06/11 11:52 AM

electrolux integrated bbq 600/300mm product description 5

Product description EQBL60AS

1 Slimline lid cover

2 Burner controls

3 Grill

4 Hotplate

5 Gas connection point

6 Pivoting leg

INTBBQ600/300_Jun11.indd 5 30/06/11 11:52 AM

electrolux integrated bbq 600/300mm contents of integrated bbq 7

Contents of 600mm Integrated Barbecue Contents of 300mm Integrated Barbecue

item description qty

• EQB3BAS –

30cm mobile base

• EQB3LAS –

Small ﬂat lid with

mounting brackets

• Ribbed hotplate 1

• Rear heat shield 1

• Oil reservoir 1

• Hose 1

• Natural Gas

regulator

• Natural Gas hose 1

• Regulator mounting

bracket

Plastic bag containing

this instruction book,

match holder and chain,

trim panel screws,

regulator mounting

screws, and a blue

ﬁbre washer

item description qty

• EQB6BAS –

60cm built in base

• EQB6HAS –

Roasting hood and

warming racks

• EQB6LAS –

Flat lid with

mounting brackets

• Grills 2

• Hotplate 1

• Rear heat shield 1

• Flame tamers 2

• Oil reservoirs 2

• Natural Gas

installation pipe

• Natural Gas

regulator

• Natural Gas hose 1

Plastic bag containing

this instruction book,

match holder and chain,

trim panel screws and

2 blue ﬁbre washers

INTBBQ600/300_Jun11.indd 7 30/06/11 11:52 AM

8 assembling the bbq electrolux integrated bbq 600/300mm

Assembling the Barbecue

1. Remove packaging & remove all components

from packaging.

2. Attach rear heat shield to rear of unit by inserting the

top tabs into the rear holes and sliding the shield down.

3. Position ﬂame tamers (60cm model only) into desired

locations (under where grill sections will be ﬁtted) and ﬁx

back edge of the ﬂame tamer into rear of barbecue body

4. Ensure left and right hand oil reservoirs are ﬁtted

correctly at front of barbecue.

5. Place cooking plates into desired positions ensuring

that the ﬂame tamers are under the grill sections.

NOTE:

Ensure that all cooking plates are orientated correctly so

that the surface is sloping forward to allow oil to drain into

oil reservoirs.

6. After installation in a bench, attach a slimline lid or

roasting hood as described in “Fitting the slimline lid

or roasting hood” section of this manual.

INTBBQ600/300_Jun11.indd 8 30/06/11 11:52 AM

electrolux integrated bbq 600/300mm gas speciﬁcations 9

model EQBH60AS &

EQBL60AS

EQBL30AS

Gas type Natural

gas

Universal

LPG

Natural

gas

Universal

LPG

Maximum gas

consumption

46 MJ/h 46 MJ/h 11.5 MJ/h 11.5 MJ/h

Injector oriﬁce

diameter (mm)

1.50 1.500.90 0.90

Number of

injectors

4 4 1 1

Regulator

pressure

1.00kPa* 1.00kPa*2.75kPa 2.75kPa

NOTE:

• This appliance MUST be installed and serviced by

a qualiﬁed licensed person only.

• This product is intended for outdoor use only.

• This product must be installed as per instructions

which requires the installation of venting to enable

the barbecue to operate correctly. Failure to provide

adequate ventillation for supply of air to the appliance

may result in poor burner performance or excessive

heat build-up within the mounting enclosure.

• Ventillation holes in the unit must not be obscured

by installation.

* The outlet pressure at the natural gas regulator will be

lower with all burners operating. Burner pressure should

read 1.0kPa with one burner operating and approximately

0.90kPa with four burners operating.

For conversion to Universal LPG a conversion kit will need

to be purchased from Electrolux Spare Parts.

EQBH60AS & EQBL60AS

EQBL30AS

Gas Speciﬁcations Gas connection detail

INTBBQ600/300_Jun11.indd 9 30/06/11 11:52 AM

10 natural gas installation electrolux integrated bbq 600/300mm

Preparing the unit for Natural Gas installation

This barbecue is supplied set up for Natural Gas and

is labelled accordingly. A Universal LPG conversion

kit is available from Electrolux Spare Parts if required.

Conversion of this unit to Universal LPG must be carried

out by a qualiﬁed licensed person.

A Certiﬁcate of Compliance must be issued to the owner

on completion of the installation and conversion.

EQBH60AS & EQBL60AS

1. Fitting the Natural Gas installation pipe

• Fit the pipe ensuring the blue sealing washer is in place.

Do not over-tighten.

2. Fitting the regulator

• Fit the regulator ensuring the blue sealing washer

is in place and the arrow indicating gas ﬂow direction

is correct. Do not over-tighten.

3. Fit the hose

• Apply thread tape or sealant to the male thread on the

hose and screw into the regulator. Do not over-tighten.

barbecue gas inlet

sealing washer

regulator – ensure arrow is

pointing in the right direction

1/2” BSP tapered thread hose

– thread tape required

natural gas installation pipe

4. Fit to mains

• Connect the bayonet end to mains.

EQBL30AS

1. Fit ﬂexible black hose to the gas inlet. Do not over-tighten.

2. Fit the brass adaptor to the black ﬂexible hose. Do not

over-tighten.

3. Fit the regulator to the adaptor with ﬁbre washer

ensuring that ﬁbre washer seated correctly into adaptor.

Do not over-tighten.

4. Fit the hose to the regulator

• Apply thread tape or sealant to the male thread on the

hose and screw into the regulator. Do not over-tighten.

gas hose 500mm

brass adaptor

sealing washer

securing bracket

1/2” BSP tapered

thread hose – thread

tape required

regulator – ensure

arrow is pointing in

the right direction

5. Secure regulator using bracket supplied

6. Fit to mains

• Connect the bayonet end to mains.

7. Ensure routing of gas supply hose prevents the hose from

contacting hot surfaces of burner base or burner box.

8. Complete leak test of ﬁnal assemby. (refer to page 12)

Natural Gas installation

INTBBQ600/300_Jun11.indd 10 30/06/11 11:52 AM

electrolux integrated bbq 600/300mm universal LPG installation 11

Preparing the unit for Universal LPG installation

This barbecue is supplied set up for Natural Gas and is

labelled accordingly. A Universal LPG conversion kit is

available from Electrolux Spare Parts to enable conversion

to Universal LPG and connection to a 9kg bottle.

Remote ULPG supply

The barbecue can be plumbed into a remote or

household ULPG supply. Never connect the barbecue

to an unregulated supply, ensure supply pressure at the

barbecue is 2.75kPa. Electrolux strongly recommends that

a manual shut off valve be installed in the gas supply line in

an accessible position so that gas can be turned off in the

event of an emergency, or during servicing.

NOTE:

Conversion of this unit to Universal LPG must be carried

out by a qualiﬁed licensed person and a Certiﬁcate of

Compliance must be issued to the owner on completion

of the installation and conversion. The components are:

For models EQBH60AS & EQBL60AS

• Hose and regulator assembly

• Small plastic bag containing 4 brass injectors (0.90mm)

• 1 Universal LPG sticker

• 1 brass adaptor

• 1 sealing washer

For models EQBL30AS

• Hose and regulator assembly

• Small plastic bag containing 1 brass injector (0.90mm)

• 1 Universal LPG sticker

1. Change the injectors

• Remove the front cover.

• Remove the burner retaining clips as shown.

remove spring clip

by rotating over

burner tube end

front cover

• Unscrew and replace the injector nipples located in the

end of each tube feeding the burners. The Universal LPG

injectors have a 0.90mm diameter oriﬁce in them. They

appear substantially smaller than the Natural Gas injectors.

LPG injector

• Re-fasten the clip to retain the tube in the burner.

Do not over tighten or distort supply tube.

• Fit the front cover back on and fasten screws.

2. Adjust the turndown setting on the valve

• Remove the knobs from the valves.

• Remove rubber grommets from control panel holes.

• For each valve rotate the valve rotation limiting screw

anti-clockwise using a Philips head screw driver until

valve shaft is able to be rotated more than 180°

(approx 3 turns).

Valve rotation

limiting screw

• Re-t grommets and knobs

3. For EQBH60AS & EQBL60AS only, connect the adaptor

to the barbecue gas inlet. Ensure the blue sealing

washer is in place. Do not over tighten.

4. Connect the hose. Do not over tighten.

5. Following connection to gas bottle, conduct a leak test

for all joints made (refer leak test procedure page 12).

6. Light all burners and one at a time set the burner to the

lowest setting and check a small steady ﬂame is achieved.

EQBH60AS & EQBL60AS

barbecue gas inlet

sealing washer

brass adaptor

LPG hose and

regulator assembly

EQBL30AS

LPG hose and regulator assembly

gas inlet

7. Replace the ‘gas type’ sticker

• Locate the ‘Natural Gas’ sticker located on or near the gas

inlet and remove it. Put the Universal LPG sticker in its place.

Universal LPG installation

INTBBQ600/300_Jun11.indd 11 30/06/11 11:52 AM

12 gas bottle safety & leak test electrolux integrated bbq 600/300mm

• This appliance is designed to use a Universal LPG

9kg (20 lbs) gas cylinder.

• The gas cylinder must be made and marked in

accordance with speciﬁcations for LPG cylinders.

• It is recommended to turn off the cylinder valve when

the appliance is not in use.

• Gas cylinders must be stored in an approved housing

out of reach of children.

• When disconnecting the gas bottle ensure that all the

control valves are in the ‘OFF’ position.

• Remove the bottle from any housing in which it may be

stored before disconnection.

• When reconnecting the hose to the bottle, ensure that

all connections are tight before replacing in the storage

compartment.

• Carry out a leakage check as detailed on this page after

each re-connection.

• Ensure all gas valves are in the ‘OFF’ position.

• In a small container, mix a solution of water and

detergent or soap.

• After connection of the hose, turn on the valve at the

gas bottle or mains as appropriate.

• Using a brush apply the solution to the gas connection

points and look for bubbles forming.

• Bubbling will indicate a leak.

• Turn off the valve and re-tighten the joint. Repeat the

leak test.

• If the leak persists, turn off the gas at the isolation valve

and contact a licensed gas ﬁtter to correct.

EQBH60AS & EQBL60AS

check for leaks

check hose for signs of

abrasions, cracks or leaks

EQBL30AS

leak test points

Gas bottle safety information Leak test procedure

INTBBQ600/300_Jun11.indd 12 30/06/11 11:52 AM

Product specificaties

Merk:	Electrolux
Categorie:	Niet gecategoriseerd
Model:	EQBL30

Heb je hulp nodig?

Als je hulp nodig hebt met Electrolux EQBL30 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Niet gecategoriseerd Electrolux

Electrolux EW7W4602QT Handleiding

21 Maart 2025

Electrolux EW8FG5602CDT Handleiding

21 Maart 2025

Electrolux EW8F7417QT Handleiding

21 Maart 2025

Electrolux EW8D795MCT Handleiding

21 Maart 2025

Electrolux EW8W7607AT Handleiding

21 Maart 2025

Electrolux EW8D394MT Handleiding

21 Maart 2025

Electrolux EW8D595MTC Handleiding

21 Maart 2025

Electrolux EW6F2497UT Handleiding

21 Maart 2025

Electrolux EW6F3414UT Handleiding

21 Maart 2025

Electrolux EW7F5412CT Handleiding

21 Maart 2025

Handleiding Niet gecategoriseerd

Nieuwste handleidingen voor Niet gecategoriseerd

Panasonic Lumix DMW-AC11 Handleiding

9 April 2025

Soundstream VRN-64HBL Handleiding

9 April 2025

MOZA SR-P Handleiding

9 April 2025

Creality3D Ender-3 S1 Pro Handleiding

9 April 2025

Act AC6020 Handleiding

9 April 2025

BlueBuilt BBMA2M Handleiding

9 April 2025

Act AC6015 Handleiding

9 April 2025

Diamond Audio MSHD9813SG Handleiding

9 April 2025

Daikin ETVZ12S18EJ6V Handleiding

9 April 2025

Daikin FXFQ80AVEB Handleiding

9 April 2025
