ADLN-I USER MANUAL
i
Disclaimer
The information in this document is subject to change without notice. The manufacturer
makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any
particular purpose. The manufacturer reserves the right to revise this publication and
to make changes from time to time in the content hereof without obligation of the
manufacturer to notify any person of such revision or changes.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment onto an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Shielded interconnect cables and a shielded AC power cable must be employed with this
equipment to ensure compliance with the pertinent RF emission limits governing this
device. Changes or modifications not expressly approved by the system’s manufacturer
could void the user’s authority to operate the equipment.
Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the following
conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that
may cause undesired operation.
This device is in conformity with the following EC/EMC directives:
EN 55032 Electromagnetic compatibility of multimedia equipment - Emission
requirements
EN 61000-3-2 Electromagnetic Compatibility(EMC)
Part 3-2: Limits-Limits for harmonic current emissions (equipment
input current ≤ 16A per phase)
EN 61000-3-3 Electromagnetic Compatibility(EMC)
Part 3-3: Limits-Limitation of voltage changes, voltage fluctuations and
flicker in public low-voltage supply systems, for equipment with rated
current ≤ 16A per phase and not subject to conditional connection
EN 55024 Information technology equipment-Immunity characteristics-Limits
and methods of measurement
EN 60950 Safety for information technology equipment including electrical
business equipment
CE marking
ADLN-I USER MANUAL
ii
Preface i ....................................................................................
Brief Introduction 1 ...................................................................
Specifications 1 ............................................................................
Motherboard Components....................................................... 3
Header Pin Definition and Jumper Settings 5 ..............................
I/O Ports 8 ...................................................................................
Multi-language Quick Installation Guide 9 .................................
English 9 ......................................................................................
Simplified Chinese 11 ..................................................................
Korean 13 ....................................................................................
Indonesian 15 ..............................................................................
Japanese 17 .................................................................................
Vietnamese 19 .............................................................................
TABLE OF CONTENTS
ADLN-I USER MANUAL
1
Brief Introduction
Specifications
SoC • Onboard Intel® Alder Lake-N Series
Memory • Single channel DDR4 SO-DIMM memory architecture
•1 x 260-pin DDR4 SO-DIMM sockets support up to 16 GB
•Supports DDR4 3200 MHz SDRAM
Note: Please go to ECS website for the latest Memory support list.
Expansion
Slots
•1 x M.2 slot (Socket key M 2280 for PCIE p3-x1 Gen3 and SATA SSD)
•1 x M.2 slot (Socket key E 2230 for WiFi/BT supports CNVi)
Storage • Supported by Intel® Alder Lake-N Series
- 2 x Serial ATA 6Gb/s devices (SATA2 share signal to M.2 slot)
Audio • Realtek ALC897 High Definition Audio
- 6-Channel High Definition Audio Codec
- Compliant with HD audio specification
LAN •Realtek RTL8111H Gigabit LAN
Rear Panel I/O • 1 x PS/2 Keyboard & PS/2 Mouse connectors
•2 x USB 3.2 Gen2x1 (10Gbps) ports
• 1 x RJ45 LAN connector
•2 x USB 2.0 ports
•1 x D-sub (VGA) port
• 1 x DP port
• 1 x COM port
• 1 x HDMITM port
•1 x Audio 6-ch jacks (line-in, line-out, microphone)
• 1 x DC-IN (Opt.)
Internal I/O
Connectors &
Headers
• 1 x 24-pin ATX Power Supply connector (Opt.)
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
•1 x USB 3.2 Gen1x1 (5Gbps) header supports additional two USB
3.2 Gen1x1 ports
•2 x USB 2.0 headers support additional four USB 2.0 ports
•2 x SATA 6Gb/s connectors
•1 x Buzzer
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x Case open header
• 1 x COM header (COM2)
• 1 x Trusted platform module header (TPM)
• 1 x Onboard parallel port header
• 1 x SPKR header
•1 x SATA_PWR header
