DRAWMER
MX60
FRONT END ONE
OPERATORS MANUAL
CONTENTS
SAFETY CONSIDERATIONS page 2
INSTALLATION page 3
INTRODUCTION page 4
• page 6Audio Connections
• page 8Power Connection
CONTROL DESCRIPTIONS page 9
OPERATION page 13
IF A FAULT DEVELOPS page 16
CONTACTING DRAW MER page 16
TECHNICAL SPECIFICATION page 17
BLOCK DIAGRAM page 18
SESSION RECALL page 19
1
COPYRIGHT
This manual is copyrighted © 2011 by Drawmer Electronics, Ltd. With all rights
reserved. Under copyright laws, this manual may not be duplicated in whole
or in part without the written consent of Drawmer.
ONE YEAR LIMITED WARRANTY
Drawmer Electronics Ltd., warrants the Drawmer MX60 Front End One to
conform substantially to the specifications of this manual for a period of one
year from the original date of purchase when used in accordance with the
specifications detailed in this manual. In the case of a valid warranty claim,
your sole and exclusive remedy and Drawmer’s entire liability under any
theory of liability will be to, at Drawmer’s discretion, repair or replace the
product without charge, or, if not possible, to refund the purchase price to
you. This warranty is not transferable. It applies only to the original
purchaser of the product.
For warranty service please call your local Drawmer dealer. Alternatively
call Drawmer Electronics Ltd. at +44 (0)1709 527574. Then ship the
defective product, with transportation and insurance charges pre-paid, to
Drawmer Electronics Ltd., Coleman Street, Parkgate, Rotherham, S62 6EL
UK. Write the RA number in large letters in a prominent position on the
shipping box. Enclose your name, address, telephone number, copy of the
original sales invoice and a detailed description of the problem. Drawmer
will not accept responsibility for loss or damage during transit.
This warranty is void if the product has been damaged by misuse,
modification or unauthorised repair.
THIS WARRANTY IS IN LIEU OF ALL WARRANTIES, W HETHER ORAL
OR WRITTEN, EXPRESSED, IMPLIED OR STATUTORY. DRAWMER
MAKES NO OTHER WARRANTY EITHER EXPRESS OR IMPLIED,
INCLUDING, WITHOUT LIMITATION, ANY IMPLIED W ARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-
INFRINGEMENT. PURCHASER’S SOLE AND EXCLUSIVE REMEDY
UNDER THIS WARRANTY SHALL BE REPAIR OR REPLACEMENT AS
SPECIFIED HEREIN.
IN NO EVENT WILL DRAW MER ELECTRONICS LTD. BE LIABLE FOR
ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY DEFECT IN THE PRODUCT,
INCLUDING LOST PROFITS, DAMAGE TO PROPERTY, AND, TO THE
EXTENT PERMITTED BY LAW, DAMAGE FOR PERSONAL INJURY, EVEN
IF DRAWMER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
Some states and specific countries do not allow the exclusion of implied
warranties or limitations on how long an implied warranty may last, so the
above limitations may not apply to you. This warranty gives you specific
legal rights. You may have additional rights that vary from state to state,
and country to country.
In the interests of product development, Drawmer reserve the right to
modify or improve specifications of this product at any time, without prior
notice.
2
DRAWMER MX60
Front End One
SAFETY CONSIDERATIONS
CAUTION - MAINS FUS E
TO REDUCE THE RISK OF FIRE REPLACE THE MAINS FUSE ONLY W ITH
THE SAME TYPE, W HICH MUST BE A CLASS 3, 230 VOLT, TIME DELAY
TYPE, RATED AT 63mA WHERE THE MAINS INPUT VOLTAGE SWITCH IS
SET TO 230 VOLTS AC. AND 125mA WHERE THE MAINS INPUT VOLTAGE
IS 115 VOLTS AC.
ALL FUSES MUST COMPLY WITH IEC 127-2.
THE FUSE BODY SIZE IS 20mm x 5mm.
CAUTION - MAINS CABLE
DO NOT ATTEMPT TO CHANGE OR TAMPER WITH THE SUPPLIED MAINS
CABLE.
CAUTION - SERVICING
DO NOT PERFORM ANY SERVICING. REFER ALL SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE.
INSTALLATION
The MX60 is designed for standard 19" rack mounting and occupies 1U of rack
space. Avoid mounting the unit directly above power amplifiers or power
supplies that radiate significant amounts of heat. connect the mainsAlways
earth to the unit. Use fibre or plastic washers to prevent the front panel
becoming marked by the mounting bolts.
3
