1960
VACUUM TUBE COMPRESSOR
OPERATORS MANUAL
CONTENTS
SAFETY CONSIDERATIONS page 1
INTRODUCTION page 2
APPLICATIONS page 2
INSTALLATION page 3
CONTROL DESCRIPTIONS: page 5
" Compressor page 5
" page 7Microphone Pre-amplifier
" page 7Auxiliary Input
QUICK SET-UP page 8
IF A FAULT DEVELOPS page 9
CONTACTING DRAWMER page 9
TECHNICAL SPECIFICATION page 10
BLOCK DIAGRAM page 11
i
COPYRIGHT
This manual is copyrighted © 1993 by Drawmer Electronics, Ltd. W ith all rights
reserved. Under copyright laws, this manual may not be duplicated in whole or in
part without the written consent of Drawmer.
ONE YEAR LIMITED WARRANTY
Drawmer Electronics Ltd., warrants the Drawmer 1960 audio processor to
conform substantially to the specifications of this manual for a period of one year
from the original date of purchase when used in accordance with the
specifications detailed in this manual. In the case of a valid warranty claim, your
sole and exclusive remedy and Drawmer’s entire liability under any theory of
liability will be to, at Drawmer’s discretion, repair or replace the product without
charge, or, if not possible, to refund the purchase price to you. This warranty is
not transferable. It applies only to the original purchaser of the product.
For warranty service please call your local Drawmer dealer. Alternatively call
Drawmer Electronics Ltd. at +44 (0)1709 527574. Then ship the defective
product, with transportation and insurance charges pre-paid, to Drawmer
Electronics Ltd., Coleman Street, Parkgate, Rotherham, S62 6EL UK. Write the
RA number in large letters in a prominent position on the shipping box. Enclose
your name, address, telephone number, copy of the original sales invoice and a
detailed description of the problem. Drawmer will not accept responsibility for loss
or damage during transit.
This warranty is void if the product has been damaged by misuse, modification or
unauthorised repair.
THIS WARRANTY IS IN LIEU OF ALL W ARRANTIES, WHETHER ORAL OR
WRITTEN, EXPRESSED, IMPLIED OR STATUTORY. DRAWMER MAKES NO
OTHER WARRANTY EITHER EXPRESS OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. PURCHASER’S
SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY SHALL BE REPAIR
OR REPLACEMENT AS SPECIFIED HEREIN.
IN NO EVENT WILL DRAWMER ELECTRONICS LTD. BE LIABLE FOR ANY
DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM ANY DEFECT IN THE PRODUCT, INCLUDING LOST
PROFITS, DAMAGE TO PROPERTY, AND, TO THE EXTENT PERMITTED BY
LAW, DAMAGE FOR PERSONAL INJURY, EVEN IF DRAWMER HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states and specific countries do not allow the exclusion of implied
warranties or limitations on how long an implied warranty may last, so the above
limitations may not apply to you. This warranty gives you specific legal rights. You
may have additional rights that vary from state to state, and country to country.
In the interests of product development, Drawmer reserve the right to modify or
improve specifications of this product at any time, without prior notice.
ii
1960 OPERATORS’ MANUAL 1
DRAWMER 1960
Dual Vacuum Tube
Compressor
SAFETY CONSIDERATIONS
CAUTION - MAINS FUSE
TO REDUCE THE RISK OF FIRE REPLACE THE MAINS FUSE ONLY WITH A
FUSE THAT 250 VOLT W ORKING, TIME DELAY CONFORMS TO IEC 127-2.
TYPE WITH A BODY SIZE OF 20mm x 5mm.
THE MAINS INPUT FUSE MUST BE RATED AT 250mA WHERE THE MAINS
INPUT VOLTAGE SWITCH IS SET TO 230 VOLTS AC. AND 500mA WHERE
THE MAINS INPUT VOLTAGE IS 115 VOLTS AC.
THE REAR PANEL H.T. FUSE MUST ALWAYS BE RATED AT 50mA,
IRRESPECTIVE OF THE MAINS VOLTAGE SETTING.
CAUTION - MAINS CABLE
DO NOT ATTEMPT TO CHANGE OR TAMPER WITH THE SUPPLIED MAINS
CABLE.
CAUTION - SERVICING
DO NOT PERFORM ANY SERVICING. REFER ALL SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE.
