Operation manual
Daikin room air conditioner English
Operation manual
Daikin room air conditioner
CTXA15A2V1BW
FTXA20A2V1BW
FTXA25A2V1BW
FTXA35A2V1BW
FTXA42A2V1BW
FTXA50A2V1BW
CTXA15A2V1BS
FTXA20A2V1BS
FTXA25A2V1BS
FTXA35A2V1BS
FTXA42A2V1BS
FTXA50A2V1BS
CTXA15A2V1BT
FTXA20A2V1BT
FTXA25A2V1BT
FTXA35A2V1BT
FTXA42A2V1BT
FTXA50A2V1BT
Table of Contents
Operation manual
2
(C)(F)TXA15~50A2V1B(W)(S)(T)
Daikin room air conditioner
3P485919-7C – 2017.12
Table of Contents
1 About the documentation 2
1.1 About this document.................................................................. 2
2 About the system 2
2.1 Indoor unit ................................................................................. 3
2.2 About the user interface ............................................................ 3
2.2.1 Components: User interface ....................................... 3
2.2.2 Status: User interface LCD ......................................... 4
2.2.3 To operate the user interface...................................... 4
3 Before operation 4
3.1 To fix the user interface to the wall............................................ 4
3.2 To insert the batteries................................................................ 4
3.3 Clock ......................................................................................... 5
3.3.1 To set the clock........................................................... 5
3.4 Brightness of the indoor unit display ......................................... 5
3.4.1 To set the brightness of the indoor unit display .......... 5
3.5 To turn on the power supply...................................................... 5
3.6 To change indoor unit position setting....................................... 5
4 Operation 6
4.1 Operation range ........................................................................ 6
4.2 When to use which feature ........................................................ 6
4.3 Operation mode and temperature setpoint................................ 6
4.3.1 To start/stop operation and to set the temperature..... 7
4.3.2 Airflow rate.................................................................. 7
4.3.3 Airflow direction........................................................... 7
4.3.4 Comfort airflow and Intelligent eye operation.............. 8
4.3.5 Powerful operation...................................................... 9
4.3.6 Econo and Outdoor unit quiet operation ..................... 9
4.4 Flash streamer air cleaning operation ....................................... 9
4.4.1 To start/stop Flash Streamer operation ...................... 9
4.5 OFF/ON timer operation............................................................ 9
4.5.1 To start/stop OFF timer operation............................... 10
4.5.2 To start/stop ON timer operation................................. 10
4.5.3 To combine OFF timer and ON timer.......................... 10
4.6 Weekly timer operation.............................................................. 10
4.6.1 To set Weekly timer operation .................................... 11
4.6.2 To copy reservations................................................... 11
4.6.3 To confirm reservations .............................................. 11
4.6.4 To deactivate and reactivate Weekly timer operation . 12
4.6.5 To delete reservations ................................................ 12
4.7 Wireless LAN connection .......................................................... 12
4.7.1 Precautions when using the wireless adapter............. 12
4.7.2 To install the Daikin Online Controller application ...... 12
4.7.3 To set the wireless connection.................................... 12
5 Energy saving and optimum operation 14
6 Maintenance and service 14
6.1 Overview: Maintenance and service ......................................... 14
6.2 To clean the indoor unit and user interface ............................... 15
6.3 To clean the front panel............................................................. 15
6.4 To open the front panel ............................................................. 15
6.5 About the air filter ...................................................................... 15
6.6 To clean the air filters ................................................................ 15
6.7 To clean the titanium apatite deodorizing filter and the silver
particle filter (Ag-ion filter) ......................................................... 16
6.8 To replace the titanium apatite deodorizing filter and the silver
particle filter (Ag-ion filter) ......................................................... 16
6.9 To close the front panel............................................................. 16
6.10 To remove the front panel ......................................................... 16
6.11 To take following items into account before a long idle period .. 17
7 Troubleshooting 17
7.1 Symptoms that are NOT system malfunctions .......................... 18
7.1.1 Symptom: A sound like water flowing is heard ........... 18
7.1.2 Symptom: A blowing sound is heard............................ 18
7.1.3 Symptom: A ticking sound is heard.............................. 18
7.1.4 Symptom: A whistling sound is heard.......................... 18
7.1.5 Symptom: A clicking sound during operation or idle
time is heard ................................................................ 18
7.1.6 Symptom: A clapping sound is heard .......................... 18
7.1.7 Symptom: White mist comes out of a unit (Indoor
unit, outdoor unit) ......................................................... 18
7.1.8 Symptom: The units can give off odours...................... 18
7.1.9 Symptom: The outdoor fan rotates while the air
conditioner is not in operation ...................................... 19
7.2 Solving problems based on error codes..................................... 19
7.3 Troubleshooting for wireless connection adapter....................... 19
8 Disposal 20
1 About the documentation
1.1 About this document
Thank you for purchasing this product. Please:
â–ª Keep the documentation for future reference.
Target audience
Endusers
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry, and on farms, or for
commercial and household use by lay persons.
Documentation set
This document is part of a documentation set. The complete set
consists of:
â–ªGeneral safety precautions:
â–ª Safety instructions that you must read before operating your
system
â–ª Format: Paper (in the box of the indoor unit)
â–ªOperation manual:
â–ª Quick guide for basic usage
â–ª Format: Paper (in the box of the indoor unit)
â–ªUser reference guide:
â–ª Detailed step-by-step instructions and background information
for basic and advanced usage
â–ª Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your installer.
The original documentation is written in English. All other languages
are translations.
2 About the system
WARNING: FLAMMABLE MATERIAL
The refrigerant inside this unit is mildly flammable.
CAUTION
The indoor unit contains radio equipment, minimum
separation distance between the radiating part of the
equipment and the user is 10 cm.
2 About the system
Operation manual
3
(C)(F)TXA15~50A2V1B(W)(S)(T)
Daikin room air conditioner
3P485919-7C – 2017.12
2.1 Indoor unit
CAUTION
Do NOT insert fingers, rods or other objects into the air
inlet or outlet. When the fan is rotating at high speed, it will
cause injury.
INFORMATION
The sound pressure level is less than 70dBA.
WARNING
â–ª Do not modify, disassemble, remove, reinstall or repair
the unit yourself as incorrect dismantling or installation
may cause an electric shock or fire. Contact your
dealer.
â–ª In case of accidental refrigerant leaks, make sure there
are no naked flames. The refrigerant itself is entirely
safe, non-toxic and mildly flammable, but it will
generate toxic gas when it accidentally leaks into a
room where combustible air from fan heaters, gas
cookers, etc. is present. Always have qualified service
personnel confirm that the point of leakage has been
repaired or corrected before resuming operation.
e
f
p
p
g
h
i
b
ac dd
j k
o
lmn
aAir inlet
bAir outlet
cTitanium apatite deodorizing filter and silver particle filter
(Ag-ion filter)
dAir filter
eFront panel
fService cover
gIntelligent eye sensor
hDisplay
iRoom temperature and humidity sensor
jON/OFF button and operation lamp (green)
kSignal receiver
lTimer lamp (orange)
mIntelligent eye lamp (green)
nWireless adapter ON/OFF button
oLouvers (vertical blades)
pFlaps (horizontal blades)
Note: Position of titanium apatite deodorizing filter and silver
particle filter is interchangeable.
ON/OFF button
If the user interface is missing, you can use the ON/OFF button on
the indoor unit to start/stop operation. When operation is started
using this button, the following settings are used:
â–ª Operation mode = Automatic
▪ Temperature setting = 25°C
â–ª Airflow rate = Automatic
2.2 About the user interface
â–ª Do NOT expose the user interface to directDirect sunlight.
sunlight.
â–ª Dust on the signal transmitter or receiver will reduceDust.
sensitivity. Wipe off dust with a soft cloth.
â–ª Signal communication might be disabled ifFluorescent lights.
fluorescent lamps are in the room. In that case, contact your
installer.
â–ª If the user interface signals operate otherOther appliances.
appliances, move the other appliances, or contact your installer.
â–ª Make sure that the signal between the unit and the userCurtains.
interface is NOT blocked by curtains or other objects.
NOTICE
â–ª Do NOT drop the user interface.
â–ª Do NOT let the user interface get wet.
2.2.1 Components: User interface
aSignal transmitter
bLCD display
cTemperature adjustment button
dON/OFF button
eVertical swing button and menu (push 2seconds)
fHorizontal swing button
gComfort airflow and Intelligent eye operation button
hSelect button
iClock button and open panel (push 2seconds)
jButtons for ON/OFF timer operation
kButtons for Weekly timer operation
lStreamer
mEcono and Outdoor unit quiet operation button
nMode button
oPowerful button
pFan button
INFORMATION
Use (hold for 2seconds) to open the front panel when
you clean the air filters. See "6.4 To open the front
panel"on page15.

Product specificaties

Merk: Daikin
Categorie: Niet gecategoriseerd
Model: CTXA15A2V1BT

Heb je hulp nodig?

Als je hulp nodig hebt met Daikin CTXA15A2V1BT stel dan hieronder een vraag en andere gebruikers zullen je antwoorden


Handleiding Niet gecategoriseerd Daikin

Daikin

Daikin FXNA40A2VEB Handleiding

20 December 2024
Daikin

Daikin FXNA25A2VEB Handleiding

20 December 2024
Daikin

Daikin FVXTM30B2V1B Handleiding

20 December 2024
Daikin

Daikin FXNA50A2VEB Handleiding

20 December 2024
Daikin

Daikin Altherma 4 H Handleiding

20 December 2024
Daikin

Daikin FTXF71F2V1B Handleiding

20 December 2024
Daikin

Daikin ATXF35G5V1B Handleiding

20 December 2024
Daikin

Daikin BRC1HHDAW Handleiding

4 December 2024
Daikin

Daikin FTK20GVLT Handleiding

4 December 2024
Daikin

Daikin BRC7EB530W Handleiding

22 Oktober 2024

Handleiding Niet gecategoriseerd

Nieuwste handleidingen voor Niet gecategoriseerd

Voltcraft

Voltcraft MSW 3000-12-G Handleiding

30 December 2025
Voltcraft

Voltcraft AL6000 Handleiding

30 December 2025
Voltcraft

Voltcraft BC2500 Handleiding

30 December 2025
Voltcraft

Voltcraft PSW 3000-12-G Handleiding

30 December 2025
Voltcraft

Voltcraft PSW 1500-12-G Handleiding

30 December 2025
Voltcraft

Voltcraft PSW 2000-12-G Handleiding

30 December 2025
Einhell

Einhell WB 50 Handleiding

30 December 2025
Hisense

Hisense HAF1800D Handleiding

30 December 2025
Eufy

Eufy Outdoor / Indoor Siren Handleiding

30 December 2025
Lenco

Lenco TTA-180TN Handleiding

30 December 2025
