V850 SFX GOLD

MPY-8501-SFHAGV

MAKE IT MINI

The V SFX Gold delivers the high quality experience you’ve

come to expect from the V series in SFX form factor. Enjoy

the same great features with 80 Plus Gold efficiency, full-

modular cabling, an FDB fan, 16AWG PCIe high efficiency

cables, and a 10 year warranty. But now you can have it in a

mini-ITX case. With the V SFX Gold, the V series is now viable

for cases ranging from mini-ITX all the way up through E-

ATX systems. And with the included bracket this unit is

compatible with all of them.

FEATURES

SPECIFICATIONS

SFX Form Factor : This unit is compatible with all SFX cases and

suitable for mini-ITX system builds.

SFX- -ATX Bracket :to The included bracket allows users to install

this unit securely in traditional ATX cases.

80 PLUS Gold Certified : This certification guarantees a typical

efficiency of 90% under normal operating conditions.

Quiet FDB Fan : The 92mm FDB fan delivers effective, quiet, and

efficient cooling.

Full-Modular Cabling : Modular cables reduce clutter, increase

airflow, and improve overall efficiency and thermal performance.

10 Year Warranty : This unit comes with a standard limited

manufacturing warranty of 10 years from the date of purchase.

PACKAGE INFORMATION

Cable Type

EAN

UPC

MPY- -SFHAGV- 8501 US

4719512098714

884102071010

MPY- -SFHAGV- 8501 UK

4719512098721

884102071027

MPY- -SFHAGV- 8501 EU

4719512098738

884102071034

MPY- -SFHAGV- 8501 ST

4719512098745

884102071041

MPY- -SFHAGV- 8501 AU

4719512098752

884102071058

MPY- -SFHAGV- 8501 BR

4719512098769

884102071065

MPY- -SFHAGV- 8501 KR

4719512098776

884102071072

MPY- -SFHAGV- 8501 TW

4719512098783

884102071089

MPY- -SFHAGV- 8501 JP

4719512098790

884102071096

MPY- -SFHAGV- 8501 IN

4719512098806

884102071102

MPY- -SFHAGV- 8501 WO

4719512098813

884102071119

Nett Weight

1.42 kg

Gross Weight

1.86 kg

Package Dimensions

260 x 190 x 100mm (10.24 x 7.48 x 3.94")

Carton Dimensions

520 x 275 x 215mm (20.47 x 10.83 x 8.46")

Unit / Carton

5 pcs

Carton / Pallet

24 pcs

Product Name

V850 SFX Gold

Item Code

MPY- -SFHAGV 8501

ATX Version

SFX 12V Ver. 3.42

PFC

Active PFC

Input Voltage

100-240V

Input Current

12 6A-

Input Frequency

50-60Hz

Dimensions (L x W x H)

100 x 125 x 63.5mm

Fan Size

92mm

Fan Bearing

FDB

Efficiency

90% @ Typical Load

80 PLUS Rating

80 PLUS Gold

ETA Rating

Gold

lAMBDA Rating

Standard+

ErP 2014 Lot 3

Yes

Operating Temperature

0~50°C

Power Good Signal

100-500ms

Hold Up Time

16ms

MTBF

>100,000 hours

Protections

OVP / OPP / SCP / OCP / UVP / OTP /

Surge and Inrush Protection

Regulatory

TUV, cTUVus, CE, BSMI, FCC, CCC, EAC,

RCM, KCC, CB, UKCA

Connectors

ATX 24 Pin

x1 = 1x (300mm)

EPS 4+4 Pin

x1 = 1x (450mm)

EPS 8 Pin

x1 = 1x (450mm)

SATA

x8 = 2x (100+115+115+115mm)

Peripheral 4 Pin

x4 = 1x (100+115+115+115mm)

PCI-e 6+2 Pin

x4 = 2x (400+120mm)

AC INPUT

100 6A-240V~, -12 , -60Hz 50

DC OUTPUT

+3.3V

+5V

+12V

- 12V

+5Vstb

20A

70.8A

0.3A

TOTAL POWER

120W

849.6W

3.6W

15W

850W

CABLES

FEATURES

SFX Form Factor

SFX- -ATX Bracket to

80 PLUS Gold Certified

Quiet FDB Fan

Full-Modular Cabling

10 Year Warranty

Product specificaties

Merk:	Cooler Master
Categorie:	Computervoeding
Model:	V850 SFX Gold
Kleur van het product:	Zwart
Gewicht:	1800 g
Breedte:	125 mm
Diepte:	100 mm
Hoogte:	63.5 mm
Geluidsniveau:	- dB
Gewicht verpakking:	2100 g
Breedte verpakking:	190 mm
Diepte verpakking:	260 mm
Hoogte verpakking:	100 mm
Type verpakking:	Doos
Stroom:	12 - 6 A
Aan/uitschakelaar:	Ja
Certificering:	TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB
Bedoeld voor:	PC
Aantal ventilatoren:	1 ventilator(en)
Stroomspanning bescherming:	Over power, Over voltage, Overcharge, Overheating, Short circuit, Under voltage
80 PLUS certificatie:	80 PLUS Gold
Mean time between failures (MTBF):	100000 uur
Totaal vermogen:	850 W
Type koeling:	Actief
Efficientie:	90 procent
AC-ingangsspanning:	90 - 264 V
AC-ingangsfrequentie:	47 - 63 Hz
Bedrijfstemperatuur (T-T):	0 - 50 °C
Code geharmoniseerd systeem (HS):	84733020
Ventilator diameter:	92 mm
ATX Power connector (24-pin):	Ja
EPS power connector (8-pin):	Ja
Motherboard power connector:	24-pin ATX
Peripheral (Molex) power connectors (4-pin):	4
Vormfactor van de voeding (PSU):	SFX
Bearing technologie:	FDB
Power Factor Correctie (PFC) type:	Actief
Gecombineerd vermogen (+3.3V):	120 W
Gecombineerd vermogen (+12V):	850 W
Gecombineerd vermogen (+5V):	120 W
Max huidige output (+3.3V):	20 A
Max huidige output(+12V):	70.8 A
Max huidige output (+5V):	20 A
Max huidige output (-12V):	0.3 A
Max huidige output (+5Vsb):	3 A
Aantal SATA power connectors:	8
Bekabelingstype:	Modulair
Houd-tijd:	16 ms
PCI Express power connectors (6+2 pin):	4
Vertragingsbereik Power Good-signaal:	100 - 500 ms
EPS-voedingsconnector (4+4 pin):	Ja
