X-PAD
Portable Audio Device
Item ref: 173.640 UK
User Manual
Version 1.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
173.640UK User Manual
Introduction
Thank you for choosing a Citronic X-PAD for digital audio recording and playback with special effects
processing. Suitable for operation with a PC or smart phone for music production, rehearsal and online
media. Please read this manual in full and keep for future reference to get the best from your product and
avoid damage through misuse.
SAFETY SYMBOL AND MESSAGE CONVENTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC
ELECTRIQUE NE PAS
OUVRIR
This symbol indicates that dangerous voltage constituting a risk of
electric shock is present within this unit
This symbol indicates that there are important operating and
maintenance instructions in the literature accompanying this unit.
Warning
To prevent the risk of fir or electric shock, do not expose any components to rain or moisture. If liquids e
enter the housing, stop using immediately, allow the unit to dry out and have checked by qualified it
personnel before further use. Avoid impact, extreme pressure or heavy vibration to the case.
No user serviceable rts inside Do not open the case refer all servicing to qualified service personnel. pa – –
Safety
• Charge the internal battery from a 5Vdc USB port or charger via the USB type-C Charge input.
Avoid ingress of water or particles into any part of the hou ng. If liquids are spilled on si
the X-PAD, stop using immediately, allow the unit to dry out and have checked by
qualified personnel before further use.
Placement
• Keep the console out of direct sunlight and away from heat sources.
• Do not place heavy objects on top of the control surface.
• K the control surface and connections free from damp or dust eep .
Cleaning
• Use a soft cloth with a neutral detergent to clean the housing as required.
• A soft brush can be used to clear debris from be een controls without damaging them. tw
• Do not use solvents for cleaning the unit.
173.640UK User Manual
USB type-C connections
1. 5V USB type-C power only connection dc 2A
2. USB type- data connection and - - C PC On The Go
Th X-PAD can be used as a standalone audio processor or as a plug play audio device when connected e +
to a laptop or smart phone When connecting the X-PAD to a laptop smart phone, use the USB type-. or C
PC/OTG data connection (2 on the bottom edge and connect to a USB port on the host device. )
Alongside the PC/OTG data connect is another USB type- connector (1), which is for charging the ion C
internal battery using a suitable USB power supply delivering 5Vdc 2A output (not supplied).
Audio connections
Audio connections to the X-PAD are on the top edge and all are 3.5mm jack type.
1. Balanced 3.5mm m input +ic 48V phantom power
2. 3.5mm mic input +5V phantom power
3. 3.5mm headset with mic in/out connection
4. 3.5mm stereo headphones output
5. 3.5mm stereo BackGround Music input
6. 3.5mm stereo on-AIR connection (smart phone in+out live)
Jack number 3 is a balanced (TRS) microphone input whic has 5V h
phantom power but can provide 48V phantom power when
switched in. This is most often a requirement for professional studio
condenser microphones. An XLRF to 3.5mm TRS plug balanced lead
is provided the package for this purpose. in
Jack number 4 is an additional microphone input, which has 5V
phantom power and can accept dynamic low voltage condenser or
microphones, such as some -clip and headset microphones. tie
Jack number 5 is a 4-pole (TRRS) connector for a headset. Thi has s
connection for stereo headphones (output) and microphone (input)
combined into a single jack.
Jack number 6 is a stereo headphones jack, which can be used for
monitoring recordings and playback of tracks through standard
wired headphones or earbuds.
Jack number 7 is a stereo line input for B kGround Music (BGM) ac
playback from a phone, mp3 player or other line level source.
Jack number 8 is a 4-pole (TRRS) connector for a smart phone
providing -AIR live recording with connections for left & right audio and microphone to record 2-way on
audio through the phone.
