I N S T A L L A T I O N I N S T R U C T I O N S
(LW 48" 200 x 200)
VESA Adapter for Kiosk Mounts
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
FHBUL
FHBUL Installation Instructions
2
DISCLAIMER
Legrand AV and its affiliated corporations and subsidiaries |
(collectively “Legrand AV”), intend to make this manual |
accurate and complete. However, Legrand AV makes no claim |
that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Legrand AV |
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Legrand AV |
assumes no responsibility for accuracy, completeness or
sufficiency of the information contained in this document.
Chief® is a registered trademark of Legrand AV Inc.
DEFINITIONS
MOUNTING SYSTEM: A MOUNTING SYSTEM is the
primary Chief product to which an accessory and/or component
is attached.
ACCESSORY: AN ACCESSORY is the secondary Chief
product which is attached to a primary Chief product, and may
have a component attached or setting on it.
COMPONENT: A COMPONENT is an audiovisual item
designed to be attached or resting on an accessory or mounting
system such as a video camera, CPU, screen, display,
projector, etc.
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all accessories are
properly assembled and installed using the instructions
provided.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached to the FHBUL interface brackets up
to and including the display does not exceed the LESSER of:
• 200 lbs (90.7 kg) or
• [the weight limit of the mounting system to which
it is attached] minus 5 lbs (2.26 kg)
WARNING: Use this accessory only for its intended use as
described in these instructions. Do not use attachments not
recommended by the manufacturer.
WARNING: Never operate this accessory if it is damaged.
Return the accessory to a service center for examination and
repair.
WARNING: Do not use this product outdoors.
--SAVE THESE INSTRUCTIONS--
DIMENSIONS
7.87
200.0
7.87
200.0
3
77
MAXIMUM OFFSET OF PATTERN FROM CENTER
2X 0.34
8.7
1.97
50.0
1.97
50.0
Installation Instructions FHBUL
3
DIMENSIONS (CONTINUED)
23.62
600.0
23.62
600.0
1.97
50.0
MAXIMUM OFFSET OF PATTERN FROM CENTER
7.87
200.0
7.87
200.0
1
26
MAXIMUM OFFSET OF PATTERN FROM CENTER
2X
0.34
8.7
1.97
50.0
23.62
600.0
23.62
600.0
1.97
50.0
MAXIMUM OFFSET OF PATTERN FROM CENTER
7.87
200.0
7.87
200.0
1
26
MAXIMUM OFFSET OF PATTERN FROM CENTER
2X
0.34
8.7
1.97
50.0
1.97
50.0
