Pagina 1/2
Manual
RECHARGEABLE HEADLIGHT
HL-EL042RC
Design Pat. Pending
Copyright© 2021 CATEYE Co., Ltd.
HLEL042RC-210305
1
1
3
2
OK
NO!
360°
*2
(MICRO USB)
(AMPP200)
LITHIUM-ION BATTERIES
Recharge the battery for first time use or after long period of storage:
The voltage of the battery may drop due to self-discharge during long
period of storage. Always fully charge the battery before use.
Cautions for charging and usage:
• Using a PC or USB battery charger with an output current of 500 mA or
more is recommended for charging.
• Be sure that no dust or other foreign objects are attached to the plug of
the USB cable before charging.
• Do not subject the light to vibrations while charging.
• When your PC is in sleep state, the unit cannot be charged.
• Once charging is completed, be sure to disconnect the USB cable from
the charging port.
• Charging and lighting times are approximate values, and will vary by
environmental and user conditions.
• Charging, discharging, and storing in high temperatures will cause the
rechargeable battery to deteriorate faster. Do not place the light inside a
vehicle or near a heater. Make sure to charge only when the ambient
temperature is between 41˚F and 104˚F (5°C and 40°C).
•
If the illumination time is significantly reduced even after proper charging,
the rechargeable battery may be nearing the end of its service life.
Cautions on storage:
• If the device will not be used for a long period of time, store it in a
location that is not too hot or too humid.
• Charge the battery for about 30 minutes every 6 months.
Cautions for dispose:
When disposing the light unit, please do so in accordance with your
local regulations.
CAUTION!:
• Always charge the product before use.
• Once charging is completed, securely close the charging port cover.
*1: When turning the light on, it lights up in the mode that was used the last time.
(Mode memory function)
Remaining battery capacity:
If the switch (indicator) turns red, charge the product as soon as possible.
ENG 1
WARNING!!! (Risk of death; Prevention of accidents)
• Do not look directly at the light source. In addition, when mounting the
light unit, ensure that the light will not dazzle other road users.
• Before riding, make sure the light unit is securely attached to the handlebar
and that the light turns on. Do not use a damaged rubber band.
• Always attention to the remaining battery power by checking the indicator
periodically while using.
• Do not disassemble or modify the light or any of the included items.
CAUTION! (Prevention of injury, damage, or property damage)
• Operating the light while riding is dangerous. Always ride safely.
• Note that the light becomes hot while illuminated. Do not block the lens or
cover the light.
• Do not place it within children’ s reach.
• Carrying a spare headlight is recommended in case the battery runs out.
• When used with a cyclocomputer, attach the headlight as far away from
the cyclocomputer as possible, as it may affect measurement.
• This device is rated IPX4 based on JIS C0920. Do not immerse the device
in water. Doing so may cause a malfunction. Wipe off any moisture after
using the device in rainy weather.
• Do not subject the light to strong vibrations, impacts, or excessive force.
Discontinue use if any abnormality occurs.
• Do not charge the battery in any way or at any voltage other than that
specified. Do not short-circuit the battery.
• Do not drop the light into a fire or heat the light.
• If the light unit or parts become dirty with mud, etc., clean with a soft cloth
which is moistened with mild soap. Never apply paint thinner, benzine or
alcohol; damage will result.
CHARGING / SWITCH OPERATION
2HOW TO MOUNT TO A BICYCLE
Light unit + Rubber band
USB cable
Before using the light, read this manual thoroughly and keep
it for future reference. Do not use the light in any way other
than as described in this manual.
Approx. 2.5 h (0.5A)
Standard charging time
USB cable
Charging port cover
To PC or USB
battery charger
Charging Charging is completed
Switch (Indicator)
Rubber band
Bracket spacer (hook)
*3 Adjusting the lighting angle
*
A flashing light indicates a charging error.
Remove the USB cable and try again.
Turn the light unit 90 degrees (perpendicular to rubber band), and attach the headlight to
the handlebar.
Pull the rubber band tight and secure it to the hook on the bracket spacer so that the light
unit is not loose.
Turn the light unit back toward the direction of travel.
*2: The light unit can be turned 360 degrees.
*3: When mounting the light unit, ensure that the light will not dazzle other road users.
1
2
3
Included Items
Fold back Ø22 – 35 mm
Switching the lighting mode
LowLow
FlashingFlashing
HighHigh
Double-click
Press and hold
Press and holdPress and hold
Click
Click
OFF ON
*1
(MICRO USB)
5343530
Rubber band
5342730
USB cable
Standard accessories
SPECIFICATIONS
Light source High-intensity LED x 1
Battery type Li-ion 3.7 v - 800 mAh
Charge terminal Micro B USB
Operating time High : Approx. 1.5 hours
Low : Approx. 13 hours
Flashing : Approx. 30 hours
* Average runtime at 68˚F (20˚C).
Standard charging time Approx. 2.5 hours (0.5 A)
Charge voltage 5 v - 500 mA
Temperature range Charging : 41˚F – 104˚F (5˚C – 40˚C)
Operating : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times
About 300 times (until the rated capacity drops to 70%)
Waterproof IPX4
Dimensions/Weight
3-25/64” x 1-3/8” x 1-19/64” (86 x 35 x 33 mm)
(Excluding rubber band)
/ 2.19 oz (62 g)
* The specifications and design are subject to change without notice.
LIMITED WARRANTY
2-year Warranty: Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materials and workman-
ship for a period of 2 years from original purchase. If the product fails to work
during normal use, CatEye will repair or replace the defect at no charge. Service
must be performed by CatEye or an authorized retailer. To return the product, pack
it carefully and enclose the warranty certificate (proof of purchase) with instruction
for repair. Please write or type your name and address clearly on the warranty
certificate. Insurance, handling and transportation charges to CatEye shall be borne
by person desiring service.
For UK and REPUBLIC OF IRELAND consumers, please return to the place of
purchase. This does not affect your statutory rights.
2-8-25, KUWAZU, HIGASHI SUMIYOSHI-KU, OSAKA, JAPAN 546-0041
For inquiries, please visit https://cateye.com/intl/contact/
[For US Customers]
CATEYE AMERICA, INC.
Please visit https://www.cateyeamerica.com/contact-us/
Toll Free : 800.5.CATEYE
CO.,LTD.
