PUB. DIE-0416-000B
HD Camcorder
Instruction Manual
- ,
COPY
2
In t rod uct ion
Important Usage Instructions
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
COPYRIGHT WARNING:
Unauthorized recording of copyrighted materials may infringe on the rights of copyright
owners and be contrary to copyright laws.
The Mains plug is used as the disconnect device. The Mains plug shall remain readily operable
to disconnect the plug in case of an accident.
CAUTION:
• Danger of explosion if the wrong type of batteries are attached. Use only the same type of batteries.
• Do not expose batteries or product to excessive heat such as the inside of a car under
direct sunlight, fire, etc.
While using the compact power adapter, do not wrap it or cover it with a piece of cloth, and do
not place it in confined narrow spaces.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point, within an equilateral triangle, is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanying
the product.
COPY
3
FCC/IC NOTICE
HD Camcorder, VIXIA HF M52 / VIXIA HF M50 / VIXIA HF M500 systems
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and use in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the manual.
If such changes or modifications should be made, you could be required to stop operation of the
equipment.
Model ID0008 (including WLAN Module Model WM217)
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of the device.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
The available scientific evidence does not show that any health problems are associated with using
low-power wireless devices. There is no proof, however, that these low power wireless devices are
absolutely safe. Low-power wireless devices emit low levels of radio frequency energy (RF) in the
microwave range while being used. Whereas high levels of RF can produce health effects (by heating
tissue), exposure to low-level RF that does not produce heating effects causes no known adverse
health effects. Many studies of low-level RF exposures have not found any biological effects. Some
studies have suggested that some biological effects might occur, but such findings have not been
confirmed by additional research. This model has been tested and found to comply with FCC/IC
radiation exposure limits set forth for an uncontrolled equipment and meets the FCC radio frequency
(RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF)
Exposure rules.
Canon U.S.A., Inc.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
Tel No. (516)328-5600
This Class B digital apparatus complies with Canadian ICES-003.
COPY
5
Trademark Acknowledgements
• SD, SDHC and SDXC Logos are trademarks of SD-3C, LLC.
• Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States
and/or other countries.
• App Store, iPhone, iTunes, Mac OS and Macintosh are trademarks of Apple Inc., registered in the U.S. and
other countries.
• “x.v.Color” and the “x.v.Color” logo are trademarks.
• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
• “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation
and Sony Corporation.
• Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
• YouTube is a trademark of Google Inc.
• Facebook is a registered trademark of Facebook, Inc.
• Wi-Fi is a registered trademark of the Wi-Fi Alliance.
• Wi-Fi Certified, WPA, WPA2, and the Wi-Fi Certified logo are trademarks of the Wi-Fi Alliance.
• WPS as used on the camcorder's settings, onscreen displays and in this manual signifies Wi-Fi Protected
Setup.
• DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks, or certification marks of the Digital
Living Network Alliance.
• Other names and products not mentioned above may be trademarks or registered trademarks of their
respective companies.
• This device incorporates exFAT technology licensed from Microsoft.
• “Full HD 1080” refers to Canon camcorders compliant with high-definition video
composed of 1,080 vertical pixels (scanning lines).
• ANY USE OF THIS PRODUCT OTHER THAN CONSUMER PERSONAL USE IN ANY MANNER
THAT COMPLIES WITH THE MPEG-2 STANDARD FOR ENCODING VIDEO INFORMATION FOR PACKAGED MEDIA
IS EXPRESSLY PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2 PATENT
PORTFOLIO, WHICH LICENSE IS AVAILABLE FROM MPEG LA, L.L.C., 250 STEELE STREET, SUITE 300, DENVER,
COLORADO 80206.
• This product is licensed under AT&T patents for the MPEG-4 standard and may be used for encoding MPEG-4
compliant video and/or decoding MPEG-4 compliant video that was encoded only (1) for a personal and non-
commercial purpose or (2) by a video provider licensed under the AT&T patents to provide MPEG-4 compliant
video. No license is granted or implied for any other use for MPEG-4 standard.
COPY
7
Smart AUTO (A47)
Smart AUTO automatically selects the best
scene mode for the scene you want to
shoot. You get spectacular recordings
every time without worrying about settings.
Video Snapshot
(A71)
Face Detection
(A100)
Shoot or capture short scenes
and arrange them into a video
clip set to your favorite
background music.
The camcorder automatically
detects people’s faces and
adjusts the focus and other
settings accordingly for beautiful
results.
- ,/
Memory Save (A151) Image Stabilization
Easily save the whole content of
the built-in memory or a memory
card onto an external hard drive
connected directly to the
camcorder. With no need for a
computer, this is a very
convenient way to save backup
copies of your recordings.
Dynamic IS (A98)
compensates for camcorder
shake when you shoot video
while walking. Powered IS
(A98) will produce stable shots
when you zoom in on distant
subjects (full telephoto).
Intelligent IS (A49) selects the
type of image stabilization for the
recording situation.
COPY
8
Enjoying Your Recordings on Other Devices
MPEG-2AVCHD
MP4
Eye-Fi
Connect the camcorder
to an HDTV (A142) Use an Eye-Fi card
(A160) to wirelessly
upload recordings to
your computer or a video
sharing Web site.
Upload MP4 movies to
your computer (A148). Save your recordings.
You can also create discs
from your recordings.*
Standard Definition
Upload AVCHD movies to your computer. - ,/ You
can also choose to convert your AVCHD movies to standard
definition files (A156) before uploading.
High Definition
Use the supplied PIXELA’s
software (A146).
Upload your AVCHD
movies* (A156) or
MP4 movies
(A162) to the Web.
* /- , only.
COPY
10
Table of contents
Introduction
6 Exciting Features and New Functions
14 About this Manual
16 Getting to Know the Camcorder
16 Supplied Accessories and CD-ROMs
18 Names of Parts
Preparations
21 Getting Started
21 Charging the Battery Pack
24 Preparing the Accessories
26 Adjusting the LCD Screen
27 Basic Operation of the Camcorder
27 Using the Touch Screen
28 Using the Menus
31 Operating Modes
34 First Time Settings
34 Setting the Date and Time
35 Changing the Language
36 Changing the Time Zone
37 Using a Memory Card
37 Memory Cards Compatible for Use with the Camcorder
39 Inserting and Removing a Memory Card
40 - ,/ Selecting the Memory (Built-in Memory/
Memory Card) for the Recordings
40 - ,/ Relay Recording
41 Initializing the Memory
43 Using the Optional Wireless Controller
Table of contents
COPY
Table of contents 11
AUTO Mode
45 Basic Recording
45 Shooting Video and Taking Photos in AUTO Mode
47 About the Smart AUTO function
49 Intelligent IS
50 Zooming
52 Quick Start
Video
54 Basic Playback
54 Playing Back Video
58 3D Flip View
59 The [Index Selection] Screen: Selecting the Content to
Play Back
60 Deleting Scenes and Stories
64 Selecting the Playback Starting Point
66 Onscreen Displays and Data Code
67 Video Stories and Cinema Style
67 Using Story Creator to Create Compelling Stories
70 Cinema Mode and Cinema-Look Filters
71 Video Snapshot
72 Decoration: Adding a Personal Touch
78 Playing Back Stories from the Gallery
80 Rating Scenes
82 Playback with Background Music
86 Copying and Moving Scenes Within/Between Stories
87 Selecting a Story’s Thumbnail Image
87 Changing a Story’s Title
89 Advanced Functions
89 Recording in Manual Mode
91 Selecting the Video Quality (Recording Mode)
94 Selecting the Frame Rate
95 Special Scene Recording Programs
98 Advanced Image Stabilization
98 Powered IS
99 Pre-Recording
100 Face Detection
COPY
12
Table of contents
102 Touch & Track
103 Faders
104 Manually Setting the Shutter Speed or Aperture
106 Manual Exposure Adjustment
107 Automatic Gain Control (AGC) Limit
108 Manual Focus Adjustment
109 Tele Macro
110 White Balance
112 Image Effects
113 Self Timer
114 Audio Scenes and Other Audio Settings
118 Audio Recording Level
120 Using Headphones
122 Using the Mini Advanced Shoe
123 Using an External Microphone
126 Using an External Video Light
126 Audio Mix
127 Capturing Video Snapshot Scenes and Photos from a
Movie
130 Dividing Scenes
Photos
132 Viewing Photos
134 Deleting Photos
136 Slideshow
External Connections
138 Terminals on the Camcorder
139 Connection Diagrams
142 Playback on a TV Screen
143 Saving and Sharing Your Recordings
143 - ,/ Copying Movies and Photos to a Memory
Card
146 Saving Recordings on a Computer
151 - ,/ Memory Save: Saving an Entire Memory
onto an External Hard Drive
155 Copying Recordings to an External Video Recorder
COPY
Table of contents 13
156 - ,/ Uploading AVCHD Movies to the Web
162 Uploading MP4 Movies and Photos to the Web
- ,/ Wi-Fi Functions
163 Introduction to Wi-Fi
165 Connecting to a Wi-Fi Network
170 Transferring Files to a Computer or FTP server
174 Uploading Recordings to YouTube and Facebook
175 Uploading Videos Using an iOS Device
178 Wireless Playback on a DLNA-Compatible Device
Additional Information
182 Appendix: Menu Options Lists
182 [Main Functions] Panel
186 [Other Settings] Menus
198 Appendix: Onscreen Icons and Displays
203 Trouble?
203 Troubleshooting
211 List of Messages
222 Do’s and Don’ts
222 Handling Precautions
227 Maintenance/Others
228 Using the Camcorder Abroad
229 General Information
229 Accessories
230 Optional Accessories
236 Specifications
240 Index
COPY
14
Introduction
About this Manual
Thank you for purchasing the Canon VIXIA HF M52 / VIXIA HF M50 /
VIXIA HF M500. Please read this manual carefully before you use the
camcorder and retain it for future reference. Should your camcorder fail
to operate correctly, refer to Troubleshooting (A203).
Conventions Used in this Manual
• IMPORTANT: Precautions related to the camcorder’s operation.
• NOTES: Additional topics that complement the basic operating
procedures.
• POINTS TO CHECK: Restrictions or requirements regarding the
function described.
• A: Reference page number within this manual.
• - : Text that applies only to the models shown in the icon.
• The following terms are used in this manual:
When not specified as “memory card” or “built-in memory”, the term
“memory” by itself refers to both.
“Scene” refers to one movie unit from the point you press the
Y button to start recording until you press again to pause
the recording.
“Photo” and “still image” are used interchangeably with the same
meaning.
• The photos included in this manual are simulated pictures taken with
a still camera. Unless indicated otherwise, illustrations and menu
icons refer to the -.
COPY
16
Introduction
Getti ng to Kno w the Ca mcorde r
Supplied Accessories and CD-ROMs
The following accessories are supplied with the camcorder:
* CA-110E including power cord, in Asia.
** - ,/ only.
XCA-110 Compact Power Adapter*
BP-718 Battery PackW
XIFC-300PCU/S USB Cable
HTC-100/S HDMI CableW
XQuick Guide
XWi-Fi Basic Setup Guide**
Stylus PenW
COPY
Introduction 17
The following CD-ROMs and software are supplied with the camcorder:
• PIXELA CD-ROM
- /- , You can use VideoBrowser for managing, editing, and
playing back AVCHD movies, and Network Utility when transferring
recordings wirelessly to a computer.
- . Use Transfer Utility for saving and transferring AVCHD
movies and music files you can use as background music.
- A printed Startup Guide for PIXELA's software is also supplied. Refer
to this Startup Guide for details about the supplied software.
• Canon VIXIA CD-ROM. Contains the following components.
- Instruction Manual - The full-version instruction manual of the
camcorder (this PDF file).
- ImageBrowser EX - This CD-ROM contains an automatic installer for
the supplied software ImageBrowser EX, which allows you to save
and manage MP4 movies and photos; and upload MP4 movies to
CANON iMAGE GATEWAY**, YouTube and Facebook. This CD-ROM
contains an automatic installer for the supplied software
ImageBrowser EX, which allows you to save and manage MP4 movies
and photos, and share MP4 movies. An Internet connection is
required for installation.
- Music data - Music files that can be used as background music during
playback. These music files are for exclusive use with the supplied
PIXELA’s software. The disc cannot be played back on CD players.
- Image mix data - Image files that can be used with the image mix
function (image mix frames).
* The CD-ROM includes the instruction manual of the software (on PDF file).
**CANON iMAGE GATEWAY is an online service that allows you to share mov-
ies and photos, make photo albums, and more. This service may not be
available in all countries/regions.
COPY
18
Introduction
Names of Parts
1 VIDEO SNAP (video snapshot) button
(A71)
2HOME (home) button (A28)
3U A (camera/play) button ( 33)
4BATTERY RELEASE switch (A22)
5USB terminal (A138, 140, 151, 155)
6HDMI OUT terminal (A138, 139)
7AV OUT terminal (A138, 140)/
×(headphones) terminal (A120)
8MIC terminal (A124)
9START/STOP button (A45)
Aq Wi-Fi antenna (- ,/ only)
Aa Strap mount (A24)
As Grip belt (A24)
Ad Memory card slot (A39)
Af Stereo microphone (A118, 126)
Ag Remote sensor (A43)
Ah Instant AF sensor (A187)
AgAf Af Ah
Left side view
9 Aq
Ad
AsAa
Right side view
Front view
COPY
Introduction 19
Aj Speaker (A56)
Ak Zoom lever (A50)
Al Mini advanced shoe (A122)
Sq ACCESS (access) indicator (A45)
Sa POWER button
Ss ON/OFF (CHG) (charge) indicator:
Green – On
Orange – Standby (A52)
Red – Charging (A21)
Sd LCD touch screen (A26, 27)
Sd
Top view
AkAj Sq
Sa Ss
Al
LCD panel
COPY
20
Introduction
Sf DC IN terminal (A21)
Sg Battery attachment unit (A21)
Sh Serial number
Sj Tripod socket (A223)
Sf
Sg
Sh Sj
Bottom view
Back view
COPY
Preparations 21
Preparations
This chapter describes basic operations, such as using the
touch panel, navigating the menus, and first time settings to
help you learn more about your camcorder.
Getting Started
Charging the Battery Pack
The camcorder can be powered with a battery pack or directly using
the compact power adapter.
For approximate charging times and recording/playback times with a
fully charged battery pack, refer to Charging, Recording and Playback
Times (A231).
1 Plug the power cord into a
power outlet.
For Asia only: Connect the power
cord to the compact power
adapter before plugging the
power cord into the power outlet.
2 Connect the compact power
adapter to the camcorder’s DC
IN terminal.
3 Attach the battery pack to the
camcorder.
Press the battery pack softly into
the battery attachment unit and
slide it up until it clicks in place.
DC IN terminal
For Asia only:
COPY
22
Preparations
4 Charging will start when the
camcorder is turned off.
• If the camcorder was on, the
green ON/OFF (CHG) indicator
will go out when you turn off the
camcorder. After a moment,
the ON/OFF (CHG) indicator
will turn on in red (battery pack
charging). The red ON/OFF
(CHG) indicator will go out
when the battery pack is fully
charged.
• If the indicator flashes, refer to Troubleshooting (A207).
To remove the battery pack
1 Slide d in the
direction of the arrow and hold it
pressed down.
2 Slide the battery pack and
then pull it out.
IMPORTANT
• Turn off the camcorder before connecting or disconnecting the com-
pact power adapter. After pressing P to turn off the camcorder,
important data is updated in the memory. Be sure to wait until the green
ON/OFF (CHG) indicator goes out.
• Do not connect to the camcorder’s DC IN terminal or to the compact
power adapter any electrical equipment that is not expressly recom-
mended for use with this camcorder.
ON/OFF (CHG) (charge) indicator
BATTERY RELEASE
switch
COPY
Preparations 23
• To prevent equipment breakdowns and excessive heating, do not con-
nect the supplied compact power adapter to voltage converters for
overseas travels or special power sources such as those on aircraft and
ships, DC-AC inverters, etc.
NOTES
• We recommend charging the battery pack in temperatures between
10 °C and 30 °C (50 °F and 86 °F). If either the ambient temperature or
the battery pack’s temperature is outside the range of approx. 0 °C to
40 °C (32 °F to 104 °F), charging will not start.
• The battery pack will be charged only when the camcorder is off.
• If the power supply was disconnected while charging a battery pack,
make sure the ON/OFF (CHG) indicator has gone out before restoring
the power supply.
• If remaining battery time is an issue, you can power the camcorder
using the compact power adapter so the battery pack will not be con-
sumed.
• Charged battery packs continue to discharge naturally. Therefore,
charge them on the day of use, or the day before, to ensure a full
charge.
• The first time you use a battery pack, fully charge it and then use the
camcorder until the battery pack is completely exhausted. Doing so will
ensure that the remaining recording time will be displayed accurately.
• We recommend that you prepare battery packs to last 2 to 3 times
longer than you think you might need.
• USA and Canada only: The Lithium ion/polymer battery that
powers the product is recyclable. Please call
1-800-8-BATTERY for information on how to recycle this
battery.
COPY
24
Preparations
Preparing the Accessories
Grip Belt and Straps
Fasten the grip belt.
Adjust the grip belt so that you can
reach the zoom lever with your
index finger, and the Y
button with your thumb.
You can attach the supplied stylus
pen to the grip belt.
To remove the grip belt
1 Lift the padded handgrip’s flap and detach the strap from the Velcro
pad.
2 Pull the strap to remove it first from the front bracket on the
camcorder, then to unthread it from the handgrip and finally to
remove it from the rear bracket on the camcorder.
COPY
Preparations 25
To attach an optional wrist strap
Attach the wrist strap to the rear
bracket on the camcorder, adjust
the length and fasten.
You can also attach the wrist strap
to the strap mount on the grip belt
to use both for extra convenience
and protection.
To attach an optional shoulder strap
Pass the ends of the shoulder strap through the strap mount on the grip
belt and adjust the length of the strap.
COPY
26
Preparations
Adjusting the LCD Screen
Rotating the LCD Panel
Open the LCD panel 90 degrees.
• You can rotate the panel 90 degrees downward.
• You can rotate the panel 180 degrees toward the lens. Rotating the
LCD panel 180 degrees can be useful to allow the camcorder to include
yourself in the picture when recording with the self timer.
NOTES
• About the LCD screen: The screen is produced using extremely high-pre-
cision manufacturing techniques, with more than 99.99% of the pixels
operating to specification. Less than 0.01% of the pixels may occasion-
ally misfire or appear as black, red, blue or green dots. This has no
effect on the recorded image and does not constitute a malfunction.
• For details about how to take care of the touch screen, refer to Handling
Precautions (A222), Cleaning (A227).
• You can adjust the screen's brightness using the q > [LCD Bright-
ness] and [LCD Backlight] settings. When the compact power adapter
is connected, [LCD Backlight] will automatically change to [H Bright].
180°
90° Subject can monitor the LCD screen
180°
COPY
Preparations 27
Basic Operation of the Camcorder
Using the Touch Screen
The control buttons and menu items that appear on the touch screen
change dynamically depending on the operating mode and the task
you are performing. With the intuitive touch screen interface you have
all the controls at your fingertips. You can also use the supplied stylus
pen for a more precise operation.
Touch
Press firmly on an element displayed on the
touch screen.
Used to start playing back a scene in an
index screen, to select a setting from the
menus, to select the subject whom the cam-
corder will recognize as the main subject of
the scene, etc.
Drag
While applying pressure, swipe your finger
up and down or left and right across the
screen.
Used to scroll menus, to browse through
index screen pages or to adjust slider
controls like the volume.
IMPORTANT
• The camcorder uses a pressure-sensitive touch screen. Press
firmly when using touch operations.
• In the following cases, you may not be able to perform touch operations
correctly.
- Using your fingernails or hard-tipped objects other than the supplied
stylus pen, such as ballpoint pens.
- Operating the touch screen with wet or gloved hands.
- Applying excessive force or forcefully scratching the touch screen.
- Attaching commercially available screen protectors or adhesive film
onto the touch screen’s surface.
COPY
28
Preparations
Using the Menus
Many of the camcorder's functions can be adjusted from the [ Main
Functions] panel and [ Other Settings] menus in the HOME menu.
For details about the available menu options and settings, refer to the
appendix Menu Options Lists (A182).
HOME Menu
Operating modes:
The HOME menu is the gateway to
most of the camcorder's functions
and settings. After you press
, the HOME menu will
appear and you can select from
the following control buttons. The
available control buttons depend
on whether the camcorder is in
recording or playback mode.
• [ Main Functions] - This contains functions commonly used while
shooting, such as focus and exposure. Available only in recording
mode.
• [ Other Settings] - Selecting this control button will open up the
[Other Settings] menus, which gives you access to settings such as the
video quality (recording mode) and LCD brightness.
In recording mode
In playback mode
for - ,/
COPY
Preparations 31
1 Press to open the HOME
menu.
2 Touch [ Other Settings] to open
the [Other Settings] menus.
3 Touch the tab of the desired
menu.
4 Drag your finger up and down to
bring the setting you want to
change into the orange selection bar.
• You can also use the [ ] and [ ] icons for scrolling.
• Menu items not available appear grayed out.
• You can touch any menu item on the screen to bring it directly into
the selection bar.
5 When the desired menu item is inside the selection bar, touch
[ ].
6 Touch the desired option and touch [X].
You can touch [X] to close the menu at any time.
Operating Modes
Recording
When recording, the camcorder's operating mode is determined by the
[ Camera Mode] and [ Recording Standard] menus in the HOME
menu. First, set the camera mode.
1 Press to open the
HOME menu.
2 Touch [ Camera Mode] and
then touch the desired camera
mode.
3 Touch [OK].
COPY
32
Preparations
Next, set the recording standard. The recording standard determines
the type of data the movie is recorded as — namely, AVCHD or MP4.
1 Press to open the HOME menu.
2 Touch [ Recording Standard] and then touch the desired
recording standard.
3 Touch [OK].
Camera mode Operation
(AUTO mode)
Let the camcorder take care of most of the settings while you
concentrate on recording (A45). Great for beginners or if you just
prefer not to bother with detailed camcorder settings.
(Manual mode) Enjoy full access to menus, settings and advanced functions (A89).
(Cinema mode)
Give your recordings a cinematic look and use cinema-look filters to
create unique movies (A70).
Recording
standard
Control
button Operation
v
Movies are recorded in AVCHD, which is designed for
playback on HDTVs. Select this recording standard if you
plan to show off your movies and you want to impress your
audience with fantastic picture quality.
é
Movies are recorded in AVCHD using Story Creator
(A67), which allows you to create compelling video
stories. Because Story Creator mode records in AVCHD,
your movies will look amazing when played back on an
HDTV.
By recording movies in MP4, your movies are smaller in
size but retain high quality. This is especially useful for
playback on portable devices or sharing on the Web.
COPY
Preparations 33
NOTES
• You can adjust the video quality using the r > [Recording Mode]
setting.
• Some portable devices may not be able to play back MP4 movies
recorded with this camcorder.
Playback
Press the camera/play button
T to switch the camcorder
between camera (recording) mode
and playback mode. You can press
T when the camcorder is off
to turn it on directly in playback
mode.
NOTES
• /- , When switching to a playback mode, the memory
selected for playback will be the same currently used for recording.
Playback mode Operation
Play ng back movies (i A54).
Viewing photos (A132).
COPY
34
Preparations
First Time Settings
Setting the Date and Time
You will need to set the date and time of
the camcorder before you can start
using it. The [Date/Time] screen (date
and time setup screen) will appear auto-
matically when the camcorder’s clock is
not set.
When the [Date/Time] screen appears, the year will be selected.
1 Touch a field you want to change (year, month, day, hours or
minutes).
2 Touch [Î Í] or [ ] to change the field as necessary.
3 Set the correct date and time by changing all the fields in the
same way.
4 Touch [Y.M.D], [M.D,Y] or [D.M.Y] to select the date format you
prefer.
In some screens, the date will be displayed in short form (numbers
instead of month names), but it will still follow the order you selected.
5 Touch [24H] to use 24-hour clock or leave it unselected to use
12-hour clock (AM/PM).
6 Touch [OK] to start the clock and close the setup screen.
NOTES
• You can adjust the date and time later on with the q > [Date/Time]
setting.
• When you do not use the camcorder for about 3 months, the built-in
rechargeable lithium battery may discharge completely and the date
and time setting may be lost. In such case, recharge the built-in lithium
battery (A225) and set the time zone, date and time again.
COPY
Preparations 35
Changing the Language
The default language of the camcorder
is English. You can set it to one of 27
languages.
Operating modes:
1 Press .
2 Select the desired language.
* After changing the camcoder’s language to English, select q >
[Language !] to change the language.
NOTES
• Some control buttons, such as [ZOOM] or [PHOTO], will appear in
English regardless of the language selected.
[ Other Settings] > > q [Language !]* >
Desired language > [OK] > [X]
COPY
36
Preparations
Changing the Time Zone
Change the time zone to match your location. The default setting is
New York.
Operating modes:
1 Press .
2 Open the [Time Zone/DST] screen.
3 Touch [" #] to set the home time zone, or [ ] to set the time zone
of your destination when you are traveling.
4 Touch [Í Î] or [ ] to set the desired time zone. If necessary, touch
[$] to adjust for daylight saving time.
5 Touch [X] to close the menu.
[ Other Settings] > > q [Time Zone/DST]
COPY
Preparations 37
Using a Memory Card
Memory Cards Compatible for Use with the Camcorder
You can use the following types of commercially available Secure Digi-
tal (SD) cards with this camcorder.
As of December 2011, the movie recording function has been tested
using SD/SDHC/SDXC memory cards made by Panasonic, Toshiba
and SanDisk. For the latest information on cards that can be used, visit
your local Canon Web site.
* When using an SD memory card without a speed class rating, you may not be able
to record movies, depending on the memory card used.
**SD memory cards with a capacity of 64 MB or smaller cannot be used to record
movies.
NOTES
• About the Speed Class: Speed Class is a standard that indicates the mini-
mum guaranteed data transfer speed of memory cards. When you buy
a new memory card, look for the Speed Class logo on the package.
We recommend using memory cards rated SD Speed Class 4, 6 or 10.
SDXC Memory Cards
You can use SDXC memory cards with this camcorder. When using
memory cards with other devices, such as digital recorders, computers
and card readers, make sure that the external device is compatible
with SDXC cards. The table below summarizes compatibility by com-
puter operating system, as of December 2011. For the latest informa-
tion, however, contact the computer, operating system or memory card
manufacturer.
Memory card type: . SD memory card, / SDHC memory card,
0 SDXC memory card
SD Speed Class*:
Capacity: 128 MB or larger**.
COPY
38
Preparations
Compatible operating systems for SDXC memory cards
IMPORTANT
• If you use an SDXC memory card with a computer OS that is not SDXC-
compatible, you may be prompted to format the memory card. In such
case, cancel the operation to prevent data loss.
• After repeatedly recording, deleting and editing scenes (fragmented
memory), it will take longer to write data on the memory and recording
may stop. Save your recordings and initialize the memory.
Eye-Fi Cards
This product is not guaranteed to support Eye-Fi card functions
(including wireless transfer). In case of an issue with an Eye-Fi card,
please check with the card manufacturer.
Also note that an approval is required to use Eye-Fi cards in many
countries or regions. Without approval, use of the card is not permit-
ted. If it is unclear whether the card has been approved for use in the
area, please check with the card manufacturer.
Operating system Compatibility
Windows 7 Compatible
Windows Vista Compatible (requires Service Pack 1 or later)
Windows XP Compatible (requires Service Pack 3 and KB955704 update)
Mac OS X Compatible (requires version 10.6.5 or later)
COPY
Preparations 39
Inserting and Removing a Memory Card
Make sure to initialize (A41) all memory cards before using them with
this camcorder.
1 Turn off the camcorder.
Make sure the ON/OFF (CHG)
indicator is off.
2 Open the memory card slot
cover.
3 Insert the memory card
straight, with the label facing
away from the camcorder, all
the way into the memory card
slot until it clicks.
• Be sure you understand the
information provided in Eye-Fi
Cards (A38) before using an
Eye-Fi card.
4 Close the memory card slot cover.
Do not force the cover closed if the memory card is not correctly
inserted.
To remove the memory card
Push the memory card once to release it. When the memory card
springs out, pull it all the way out.
IMPORTANT
• Memory cards have front and back sides that are not interchangeable.
Inserting a memory card facing the wrong direction can cause a mal-
function of the camcorder. Be sure to insert the memory card as
described in step 3.
COPY
40
Preparations
- ,/ Selecting the Memory (Built-in Memory/Memory
Card) for the Recordings
You can select to record your movies and photos in the built-in mem-
ory or on a memory card. The default memory for recording both is the
built-in memory.
Operating modes:
POINTS TO CHECK
• Be sure you understand the information provided in Eye-Fi Cards
(A38) before using an Eye-Fi card.
1 Press .
2 Select the desired memory.
* When selecting the memory, you can check the approximate available recording
time/number of photos, based on currently used settings.
- ,/ Relay Recording
You can activate the relay recording so if the built-in memory becomes
full while recording movies, the recording will continue uninterrupted
on the memory card.
Operating modes:
1 Insert a memory card that contains no video recordings into the
memory card slot.
2 Press .
[ Other Settings] >
>
>
>> r>
>
>
>> [Rec Media for Movies]
or [Rec Media for Photos] >
>
>
>> [&] (built-in memory) or
[*] (memory card)* >
>
>
>> [X]
COPY
Preparations 41
3 Activate the relay recording.
* The approximate available recording time will now reflect the combined space in
the memories used for relay recording.
NOTES
• There will be a momentary stop in the scene at the point where the
camcorder switches from one memory to another.
• Any of the following actions will deactivate the relay recording function:
- Turning off the camcorder.
- Opening the memory card slot cover.
- Changing the camcorder’s operating mode.
- Changing the memory used for recording movies.
Initializing the Memory
Initialize memory cards when you use them with this camcorder for the
first time. You can also initialize a memory card or the built-in memory
( /- , only) to permanently delete all the recordings it con-
tains.
- ,/ At the time of purchase, the built-in memory comes pre-
initialized and contains music files for use as background music and
images for use with the image mix function (image mix frames).
Operating modes:
1 Power the camcorder using the compact power adapter.
Do not disconnect the power source or turn off the camcorder until the
initialization is completed.
2 Press .
[
Other Settings]
>
>
>
>>
r
>
>
>
>>
[Rec Media for Movies]
>
>
>
>>
[
&
]
>
>
>
>>
[Relay Recording]
>
>
>
>>
[
%
]*
>
>
>
>>
[
X
]
COPY
Preparations 43
Using the Optional Wireless Controller
When you use the optional WL-D89 Wireless Controller, you can con-
veniently operate the camcorder from a distance when, for example,
you are using a tripod to achieve a stable shot. To use the wireless
controller, first perform the following procedure to turn on the cam-
corder's remote sensor.
Operating modes:
1 Press .
2 Turn on the remote sensor.
3 Point the wireless controller at the camcorder’s remote sensor
when you press the buttons.
You can rotate the LCD panel 180 degrees to view the screen while
using the wireless controller.
[ Other Settings] > > q
[Wireless Remote Control] > [iOn] > [X]
COPY
44
Preparations
Wireless Controller’s Buttons
NOTES
• The wireless controller may not work properly when the remote sensor
is situated under strong light sources or direct sunlight.
1START/STOP button (A45)
2 G (index selection) button
• In any index screen (during playback
mode), press to open the [G Index
Selection] screen (A59).
• Press and hold for more than
2 seconds to switch between
shooting and playback mode.
3MENU button (A30, 186)
Functions the same as on the
camcorder.
4 DISP. (onscreen display) button
(A66)
Selects whether to display onscreen
information during playback.
5 SET button
Selects an onscreen item.
6Ñ A (stop) button ( 54)
7PHOTO button (A45)
8Zoom buttons (A50)
9 Navigation buttons (Í Î Ï Ð/ / / )
Aq Ò A (play/pause) button ( 54)
COPY
AUTO Mode 45
AUTO Mode
This chapter covers how to easily record video and photos in
mode, and how to use basic shooting functions like zoom
and Quick Start. To enjoy full access to menus and more
advanced functions, refer to Recording in Manual Mode
(A89).
Basic Recording
Shooting Video and Taking Photos in AUTO Mode
With mode, you can take great-looking videos and photos by let-
ting the camcorder automatically adjust settings based on the record-
ing situation.
Operating modes:
POINTS TO CHECK
• Before you begin recording, make a test recording first to check that
the camcorder is operating correctly.
1 Press P to turn on the
camcorder.
• - ,/ By default,
movies and photos are
recorded in the built-in
memory. You can select the
memory that will be used to
record movies and photos
(A40).
• Please read the
IMPORTANT section
(A49) before using an
Eye-Fi card.
COPY
46
AUTO Mode
2 Press .
To change the recording standard, refer to Recording (A31).
3 Set the camcorder to mode.
To record video
Press Y to begin recording.
• Press Y again to pause the recording.
• You can also press Y on the optional WL-D89 Wireless Con-
troller.
• The ACCESS indicator will flash from time to time while the scene is
being recorded.
• You can turn on the scene rating option in recording mode with the
r > [Rate Scenes (Recording)] setting.
To take photos
Touch [PHOTO].
• You can record photos simultaneously while recording a movie.
• A green icon ( ) will appear momentarily on the screen and the
ACCESS indicator will flash as the photo is recorded. However, if you
record a photo while recording a movie, the green icon will not appear.
Instead, a Ð icon will appear in the upper right of the screen.
• You can also press Z on the optional wireless controller.
When you have finished recording
1 Make sure that the ACCESS indicator is off.
2 Turn off the camcorder.
3 Close the LCD panel.
[ Camera Mode] >
>
>
>> [N] > [OK]
COPY
AUTO Mode 47
About AUTO mode
• Only the following functions are available in mode.
- Zoom (A50).
- Quick Start (A52).
- Video snapshot (A71).
- Face detection (A100) to get beautiful shots of people every
time, tracking the subject even if the person moves.
- Touch & Track (A102) to track other moving subjects, keeping
them in focus and using the best settings to record them.
- Story Creator (A67) to transform your movies into compelling
video stories by following simple scripts for various scenarios.
- Decoration (A72) to add a fun personal touch using stamps,
drawings, image mix and more.
About the Smart AUTO function
In mode, the camcorder will automatically detect certain
characteristics of the subject, background, lighting conditions, etc.
It will then adjust various settings (focus, exposure, color, image
stabilization, image quality, among others), selecting the best set-
tings for the scene you want to shoot. The Smart AUTO icon will
change to one of the following icons.
COPY
AUTO Mode 49
IMPORTANT
• Observe the following precautions while the ACCESS indicator is on or
flashing. Failing to do so may result in permanent data loss or damage
to the memory.
- Do not open the memory card slot cover.
- Do not disconnect the power source or turn off the camcorder.
- Do not change the camcorder’s operating mode.
• Be sure to save your recordings regularly (A143), especially after
making important recordings. Canon shall not be liable for any loss or
corruption of data.
• Recordings on an Eye-Fi card will be uploaded automatically after set-
ting the camcorder to playback mode, if you are within the range of a
configured network. Always verify that Eye-Fi cards have been
approved in the country/region of use. See also Using an Eye-Fi card
(A161).
NOTES
• About the power saving mode: If q > [Power Saving Mode] > [Auto
Power Off] is set to [iOn], the camcorder will shut off automatically
to save power when it is powered by a battery pack and is left without
any operation for 5 minutes. Press P to turn on the camcorder.
Intelligent IS
Intelligent IS allows the camcorder to select the best image stabilization option
based on your shooting method. The Intelligent IS icon will change to one of the
following icons. In and modes, you can set the image stabilization
manually (A98).
* You can turn off Powered IS through the [ Main Functions] panel (A 98).
Shooting method Icon
Most general situations; Zooming out (zooming toward
T
); Following subjects at a distance moving left or right
Ä (Dynamic IS)
Zooming in (zooming toward S)È (Powered IS)*
Close-up of a subject (Macro IS)
Remaining stationary, such as when using a tripod (Tripod mode)
COPY
50
AUTO Mode
• When recording in bright places, it may be difficult to use the LCD
screen. In such cases, you can adjust the LCD backlight with the q
> [LCD Backlight] setting or adjust the brightness of the LCD screen
with the q > [LCD Brightness] setting.
• Under certain conditions, the Smart AUTO icon that appears on the
screen may not match the actual scene. Especially when shooting
against orange or blue backgrounds, the Sunset or one of the Blue
Skies icons may appear and the colors may not look natural. In such
case, we recommend recording in mode (A89).
• Photos are recorded as JPG files. The photo size (1920x1080) and
quality cannot be changed. At this size, a 1 GB memory card can hold
approximately 670 photos. However, the actual number of photos that
can be recorded will vary depending on the subject and shooting condi-
tions.
Zooming
There are three ways you can zoom in and out: using the zoom lever on
the camcorder, using the zoom buttons on the optional WL-D89 Wire-
less Controller or using the zoom controls on the touch screen.
In addition to the 10x optical zoom, in mode, you can turn on the
digital zoom (40x or 200x) with the p > [Digital Zoom] setting.
Operating modes:
Using the Zoom Lever
Move the zoom lever toward T
(wide angle) to zoom out. Move it
toward S (telephoto) to zoom in.
• By default, the zoom lever
operates at a variable speed –
press gently for a slow zoom;
press harder for faster zooms.
• You can also use the zoom
buttons on the optional wireless
controller.
T Zoom out S Zoom in
COPY
AUTO Mode 51
Using the Touch Screen’s Zoom Controls
1 Display the zoom controls on the touch screen.
• The zoom controls appear on the left side of the screen.
2 Touch the zoom controls to operate
the zoom.
Touch anywhere within the T area to
zoom out or anywhere within the S area
to zoom in. Touch closer to the center for
a slow zoom; touch closer to the V U/
icons for faster zooms.
3 Touch [X] to hide the zoom controls.
NOTES
• Keep at least 1 m (3.3 ft.) away from the subject. At full wide angle, you
can focus on a subject as close as 1 cm (0.39 in.). Using tele macro
(A109), you can focus on a subject as close as 40 cm (1.3 ft.) at full
telephoto.
• In or mode, you can also set p > [Zoom Speed] to
one of three constant speeds (3 is the fastest, 1 the slowest). When
[Zoom Speed] is set to [YVariable]:
- When you use the S and T buttons on the optional wireless
controller, the zoom speed will be constant at [ZSpeed 3].
- The zoom speed will be faster in record pause mode than when
actually recording, except when pre-recording (A99) is activated.
• See Specifications (A238) for notes about this function when the
recording program is set to [šSCN: Underwater] or [ŸSCN: Sur-
face].
[FUNC.] > [ZOOM Zoom]
COPY
52
AUTO Mode
Quick Start
When you close the LCD panel with the camcorder on, the camcorder
enters the standby mode. In standby mode the camcorder consumes
only about 1/3 the power used when recording, saving energy when
you are using a battery pack. Additionally, when you open the LCD
panel, the camcorder is ready to start recording in approximately
1 second*, allowing you to record the subject right away.
* The actual time required varies depending on the shooting conditions.
Operating modes:
1 With the camcorder on and in a recording mode, close the LCD
panel.
A beep will sound and the green ON/OFF (CHG) indicator will change
to orange to indicate the camcorder entered standby mode.
2 When you wish to resume recording, open the LCD panel.
The ON/OFF (CHG) indicator turns back green and the camcorder is
ready to record.
IMPORTANT
• Do not disconnect the power source during standby mode (while the
ON/OFF (CHG) indicator is lit in orange).
NOTES
• The camcorder will not enter standby mode if the LCD panel is closed
while the ACCESS indicator is on or flashing or while the HOME menu
or menus contained therein (not including the [ Main Functions]
panel) are being displayed. The camcorder may also not enter standby
mode when the battery charge is too low. Check that the ON/OFF
(CHG) indicator changes to orange.
COPY
AUTO Mode 53
• About standby mode and auto power off:
- The camcorder will power off automatically if left in standby mode for
10 minutes. Press P to turn on the camcorder.
- You can select the length of time until shut-off or turn off the Quick
Start function altogether with the q> [Power Saving Mode] >
[Quick Start (Standby)] setting.
- The usual 5-minute auto power off setting of [Power Saving Mode] is
not applicable while the camcorder is in standby mode.
COPY
Video 55
3 Look for the scene you want to play back.
Move the zoom lever toward T to show 15 scenes per page; move it
toward S to show 6 scenes per page.
4 Touch the desired scene to play it back.
• For AVCHD movies, the camcorder will play back the scene selected
and continue until the end of the last scene in the index screen. For
MP4 movies, the camcorder will play back only one scene.
• Touch the screen to display the playback controls. During playback,
the playback controls will disappear automatically after a few
seconds without operation. In playback pause, touch the screen
again to hide the playback controls.
! Open the index selection screen.
" Memory being read.
# Recording date.**
$ Division line between recording dates.
% Drag your finger left/right for the next/previous index
page*.
& Display the next/previous index page.
' Scene's timeline (A64)**.
( A3D Flip View ( 58)**.
* While browsing through index pages, a larger scroll bar will appear
at the bottom of the screen for a few seconds. When you have a
large number of scenes it may be more convenient to drag your fin-
ger along the scroll bar.
**Not available for MP4 movies.
COPY
56
Video
During playback:
Adjusting the volume for AVCHD movies
1 During playback, touch the screen to display the playback controls.
2 Touch [Ý], drag your finger along the [Speaker Volume]* bar to
adjust the volume and touch [K].
* When q > [AV/Headphones] is set to [Ó Headphones], adjust the [Head-
phone Volume] bar instead.
Adjusting the volume for MP4 movies
1 During playback, touch the screen to display the playback controls.
2 Drag your finger across the volume bar to adjust the volume.
! Jump to the beginning of the scene. Double-tap to jump to the previ-
ous scene*.
" Jump to the beginning of the next scene*.
# Pause the playback.
$ Fast playback** backward/forward.
% ADisplay the volume ( 56) and background music mix balance
(A82) controls.
& Stop the playback.
' Decoration (A72).
( Volume.
) Recording date.
* Not available for MP4 movies.
**Touch several times to increase the playback speed to approximately 5x → 15x →
60x (for AVCHD movies) or 5x → 15x (for MP4 movies) normal speed.
AVCHD movies MP4 movies
COPY
Video 57
During playback pause:
IMPORTANT
• Observe the following precautions while the ACCESS indicator is on or
flashing. Failing to do so may result in permanent data loss.
- Do not open the memory card slot cover.
- Do not disconnect the power source or turn off the camcorder.
- Do not change the camcorder’s operating mode.
• You may not be able to play back with this camcorder movies recorded
on a memory card using another device.
NOTES
• Depending on the recording conditions, you may notice brief stops in
video or sound playback between scenes.
• During fast/slow playback, you may notice some anomalies (blocky
video artifacts, banding, etc.) in the playback picture.
• The speed indicated on the screen is approximate.
• Slow reverse playback will look the same as continuous frame reverse.
! Resume playback.
" Slow playback* backward/forward.
# Capture the displayed frame as a photo (A128)**.
$ Decoration (A72)**.
* Touch several times to increase the playback speed 1/8 → 1/4 the
normal speed.
**Not available for MP4 movies.
COPY
Video 59
The [Index Selection] Screen: Selecting the Content to Play Back
From the [G Index Selection] screen you can select the content you
want to play back (original scenes by date or by story, or photos, for
example). - ,/ You can also select the memory from which
you want to play back your recordings.
Operating modes:
In any index screen:
Touch [G].
During single photo view, touch the screen once to display the controls
then touch [f] to open the [ Photos] index screen.
Options
[y
y
y
yy Movies] Scenes recorded in AVCHD organized by
recording date.
[ê
ê
ê
êê Gallery] Scenes recorded in AVCHD organized by story
(A78).
[ Movies] Scenes recorded in MP4.
[ Photos] Photos’ index screen.
[z
z
z
zz SD Movies] (- ,/ only when a memory card is
selected) Scenes that were converted to standard definition to
upload them to the Web (A156).
! - ,/ Touch the tab of the desired memory:
built-in memory or memory card.
" Touch a control button to select the content you want to
play back.
COPY
60
Video
NOTES
• - ,/ Fast/slow playback modes are not available for scenes
converted to standard definition. Scenes in the [SD Movies] index
screen can only be played back at normal speed.
• You cannot jump to the previous or next scene with MP4 movies.
Deleting Scenes and Stories
You can delete those scenes and stories that you are not interested in
keeping. Deleting scenes allows you also to free up space on the mem-
ory.
Deleting a Single Scene
Operating modes:
1 Play back the scene you wish to delete.
When playing back a scene in the gallery, pause the scene you wish to
delete and then continue to step 2.
2 Touch the screen to display the playback controls.
Two playback modes for AVCHD movies: the [ Movies]
index screen vs. the gallery
In the [ Movies] index screen you can find all the AVCHD mov-
ies you have recorded, conveniently organized by recording date.
When you play back scenes from the [ Movies] index screen
they will be played back in chronological order.
In the gallery, you can find your scenes grouped as video stories. If
you record movies using the Story Creator function (A67), your
scenes will appear in the story you created; scenes recorded with-
out using this function will appear in the [Unsorted] story (or [Video
Snapshot] story, in the case of video snapshot scenes). When you
play back a story from the gallery, scenes will be played back in the
order of the story’s outline, regardless of their recording date.
COPY
Video 61
3 Delete the scene.
Deleting Scenes from the [ Movies] or [ Movies] Index Screen
Operating modes:
1 Open the [ Movies] or [ Movies] index screen.
For AVCHD movies, to delete all the scenes recorded on a specific
date, drag your finger left/right until the desired date appears in the title
bar.
2 Delete the scenes.
* When you select [Select], perform the following procedure to select the individ-
ual scenes you want to delete before touching [Yes].
**Touch [Stop] to interrupt the operation while it is in progress. Some scenes may
be deleted nevertheless.
To select individual scenes
1 Touch on the individual scenes you want to delete.
• A checkmark ! will appear on the scenes you touch. The total
number of selected scenes will appear next to the " icon.
• Touch a selected scene to remove the checkmark. To remove all
checkmarks at once, touch [Remove All] > [Yes].
2 After selecting all the desired scenes, touch [OK].
Options
[ date]Delete all the scenes recorded on the date shown in the
control button. For AVCHD movies only.
[Select] Select individual scenes to delete.
[All Scenes] Delete all the scenes.
[Ý] > [Edit] > [Delete] > [Yes] > [OK]
[Edit] > > > [Delete] Desired option* [Yes]** > [OK]
COPY
62
Video
Deleting a Single Scene from a Story
Operating modes:
1 Open the list of scenes of the story that contains the scene you
want to delete.
2 In the [Scene List] screen, drag your finger up/down to select the
scene you want to delete.
3 Touch the orange [ ] icon on the left to open the [Edit Scene]
screen.
4 Delete the scene.
Deleting Scenes from a Story by Rating
Operating modes:
1 Open the information screen of the story that contains the scenes
you want to delete.
2 Open the rating selection screen.
[G] > [ Gallery] > Bring the desired story to the
front > [Scene List]
[ ] > [Yes] > [OK] > [K]
[G] > [ Gallery] > Bring the desired story to the
front > [Story Details]
[Edit Story] > [Delete]
COPY
Video 63
3 Touch one or more of the rating buttons to select all the
applicable scenes.
• A grayed out rating button indicates that no scenes in the story have
been given that particular rating.
• The number of selected scenes appears on the screen.
• Touch the rating button again to remove those scenes from the
selection.
4 Delete all applicable scenes.
* Touch [Stop] to interrupt the operation while it is in progress. Some scenes may
be deleted nevertheless.
Deleting Stories
Operating modes:
Deleting a story permanently deletes all the scenes it contains. The two
preexisting stories, [Unsorted] and [Video Snapshot], cannot be
deleted.
1 Open the gallery.
2 Select the story you want to delete.
Drag your finger right/left to bring the desired story to the front.
3 Delete the story.
* Touch [Stop] to interrupt the operation while it is in progress. Some scenes may
be deleted nevertheless.
[Set] > [Yes]* [OK] > > [K]
[G] > [ Gallery]
[Story Details] > [Edit Story] > [Delete Story] > [Yes]*
> [OK]
COPY
64
Video
IMPORTANT
• Be careful when deleting recordings. Once deleted, scenes cannot be
recovered.
• Deleting a story permanently deletes all the scenes it contains.
• When deleting scenes, scenes will be removed from the [ Movies]
or [ Movies] index screen and from any stories in the gallery they
may have belonged to, regardless of the method used to delete them.
• Save copies of important scenes before deleting them (A146).
• Observe the following precautions while the ACCESS indicator is on or
flashing (while scenes are being deleted).
- Do not open the memory card slot cover.
- Do not disconnect the power source or turn off the camcorder.
- Do not change the camcorder’s operating mode.
NOTES
• To delete all movies and make all recordable space available again you
may prefer to initialize the memory (A41).
Selecting the Playback Starting Point
If you have a very long scene, you may want to start playing back the
scene from a certain point. You can use the movie timeline to break the
scene to segments at fixed time intervals ranging from 6 seconds to
6 minutes.
Operating modes:
1 Open the [ Movies] index screen.
2 Open the scene’s [Timeline] screen.
The [Timeline] screen appears. The large thumbnail will show the first
frame of the scene. Below it, the timeline ruler shows frames taken
from the scene at fixed intervals.
[I] > Desired scene
COPY
Video 65
3 Touch the desired frame in the timeline ruler to start playing back
the scene from that point.
To change the interval between frames
! Touch twice to return to the index screen.
" Previous/next scene.
# Drag your finger left along the ruler to display the next 5 frames.
$ Scene’s recording mode and length.
% Recording date and time.
& Drag your finger right along the ruler to display the previous
5 frames.
' Current scene / Total number of scenes.
( Currently selected interval between frames.
[6 sec] > Desired interval > [K]
COPY
66
Video
Onscreen Displays and Data Code
With every scene or photo recorded, the camcorder keeps a data
code. For AVCHD movies, the data code includes date/time of record-
ing, information about the camera setup, etc. For MP4 movies, the
data code is the date of recording. You can choose the information to
be displayed.
Operating modes:
1 Press .
2 Select the information to be displayed.
NOTES
• The data code will appear when the screen is touched, regardless of the
selected option.
[ Other Settings] > [y] or [ ] > [Data Code] >
Desired option > [X]
COPY
Video 67
Video Stories and Cinema Style
Using Story Creator to Create Compelling Stories
Story Creator is a helpful function that offers suggestions for typical
scenes in a number of situations. With Story Creator, creating interest-
ing video stories is as easy as selecting one of the story themes, such
as [Travel], [Party] or [Kids & Pets], and following the suggested cate-
gories to record video. During playback, select your story from the gal-
lery to play back the scenes you recorded as a single, compelling video
story (A78).
Operating modes:
Creating a New Story
1 Press .
2 Start Story Creator mode.
3 Touch [Create New Story] and select the desired theme.
Drag your finger left/right to bring the desired story theme to the front.
4 Touch [Create Story] and then select the story scene (category).
Initially, the current date will be used as the story’s title, but you can
change it by touching [ì] (A87).
[ Recording Standard] > [é] > [OK]
[ë] (including the story scene title) > Desired story
scene > Orange [ ] icon on the left
COPY
68
Video
5 Touch [To Recording Screen].
A confirmation screen will appear that shows the selected theme, story
scene (category), shooting advice and the recommended shooting
length.
6 Touch [OK].
• A new story will be created and the camcorder will enter record
pause mode. The selected story scene category will appear at the
bottom of the screen.
• If you touch [?], a screen showing the selected theme, story scene
(category), shooting advice and the recommended shooting length
will appear.
Recording a Scene within a Story
Press Y to record movies within the selected story scene
(category).
• Use the displayed recommended length as a reference when recording
scenes.
• Scenes will be recorded under the story and story scene currently
selected.
• You can also record video snapshot scenes (A71).
! Shooting tip for the current category.
" Recommended length of scenes in this category.
# Currently selected story scene (category). You can
touch here to return to the list of story scenes.
COPY
70
Video
Cinema Mode and Cinema-Look Filters
In (cinema) mode, the camcorder will adjust the frame rate and
several other picture-related settings to give your recordings a cine-
matic look. In this mode you can also use a variety of professional cin-
ema-look filters to create unique movies with a distinctive appearance.
Operating modes:
1 Press .
2 Set the camcorder to mode.
3 Select the desired cinema-look filter.
* When you select a cinema-look filter other than [Cinema Standard], you can
change the effect level with the following procedure before touching [OK].
• The selected cinema-look filter will be applied and its number will
appear on the control button.
To select the effect level of the cinema-look filter
[Camera Mode] > [ ] > [OK]
[FILTER 1] > Desired cinema-look filter* > [OK]
[w] > [L] (low), [M] (medium) or [H] (high) > [K]
COPY
Video 71
Options ( Default value)
The camcorder offers 7 cinema-
look filters. Select the desired filter
while previewing the effect on the
screen.
NOTES
• Photos cannot be recorded while the camcorder is set to mode.
Video Snapshot
Record a series of short scenes. Then, play back your video snapshot
scenes set to your favorite music (A82) to create your own fun music
video. You will be surprised how by changing the background music,
you can give your scenes an entirely new feel.
The default length of a video snapshot scene is 4 seconds but you can
change it to 2 or 8 seconds, or to the length recommended for the
selected story scene (category) in Story Creator, with the r >
[Video Snapshot Length] setting.
Operating modes:
[1: Cinema Standard]
[2: Vivid]
[3: Dream]
[4: Cool]
[5: Nostalgic]
[6: Sepia]
[7: Old Movies]
[8: Memory]
[9: Dramatic B&W]
! Filter number (will appear on
the control button)
" Filter name
# Preview the effect on the
screen
$ Select the effect level
% Brief description (onscreen
guidance)
COPY
72
Video
1 Press V.
• A blue border appears on the
screen.
• Press V again to
return to normal video
recording mode.
2 Press Y.
• The camcorder records for a
few seconds (the blue frame
serves as a visual progress
bar*) and then automatically
returns to record pause mode.
• When the camcorder stops recording, the screen will momentarily
turn black as if a camera shutter had released.
* When the recording program is set to [šSCN: Underwater], the visual
progress bar will be red.
NOTES
• Changing the camcorder to playback mode will deactivate the video
snapshot mode.
Decoration: Adding a Personal Touch
Add a new level of enjoyment to
your scenes by decorating
them. You can add animated
graphics, stamps and even your
own freehand drawings. The
supplied stylus pen will be espe-
cially useful for decorating
scenes.
You can decorate scenes as
they are being recorded. For
AVCHD movies, you can also
decorate scenes during play-
back or when converting them to standard definition (- ,/
only; A157).
COPY
Video 73
Decorating Scenes while Recording
Operating modes:
1 Open the decoration screen.
• The decoration screen will open automatically also when you stow
the LCD panel with the touch screen facing out.
2 Use a tool from the toolbar as explained in the following
procedures.
3 Press Y to record movies with your decorations.
You can add decorations even while recording a scene.
4 Touch [X] to exit the decoration screen.
! Canvas - The area where you will draw and see your decorations
in action.
" Toolbar.
# [Ó Pens and Stamps] Select the type of pen or stamp and its
color. You can also save a canvas or load a previously saved
canvas.
$ [× Animated Stamps] Select animated stamps to add to your
decoration.
% [Ø Captions] Add the date, date and time, story title* or story
theme* as a caption that will be included in the recording.
[FUNC.] > [ÒDecoration]
COPY
74
Video
& [Ü]** (Image Mix) Choose one of 27 different frames to add
onto the canvas. Image mix can be used in combination with the
pens, stamps and animated stamps.
' [Ý]** In recording mode: pause the live video. Touch [Ý] again to
restore the live video. You can add decorations to and record the
frozen image.
In playback mode: pause the playback. Touch [Ð] to resume
playing back the scene.
( [ß] Minimize the toolbar to the top of the screen to view almost
all of the canvas. Touch [ à] to restore the toolbar.
* Not available in mode.
**Not available in mode and for MP4 movies.
To use [Pens and Stamps]
1 Touch [Ó].
The [Pens and Stamps] screen will appear.
2 Select the desired pen or stamp from [Tools].
3 Select white or black from [Colors].
Alternatively, you can touch [Ö] and select a color from the color
palette.
4 Draw freely on the canvas.
Touch [Ó] > [Clear] > [Yes] to clear the canvas and start again.
5 When you finish drawing, save the canvas.
* The freehand drawings and stamps will be saved in the built-in memory (-
/ ,only) or on a memory card (. only).
To load a previously saved canvas
In the decoration screen:
* The camcorder will apply the last freehand drawings and stamps that were saved
in the built-in memory (- ,/ only) or on a memory card (. only).
[Ó] > [&Save]* or [* Save]* > [Yes] > [K]
[Ó] > [&Load]* or [* Load]* > [Yes] > [K]
COPY
Video 75
To use [Animated Stamps]
1 Touch [×].
The [Animated Stamps] screen will appear.
2 Touch one of the control buttons.
3 Touch anywhere on the canvas to place the selected animated
stamp. You can also drag some animated stamps to a different
location.
To use [Captions]
1 Touch [Ø].
The [Captions] screen will appear.
2 Touch [Date] or [Time].
When recording a scene using Story Creator, you can also select [Title]
(the story’s title) or [Story Scene] (the story scene category).
3 Select the desired text settings and touch [K].
• Touch [ ] (white text on dark background), [ ] (white text) or [ ]
(black text).
4 Touch the caption and drag it to the desired location.
To use image mix
Operating modes:
1 Touch [Ü] to open the [Select Image] screen.
2 Touch [+] or [-] to select a different image mix frame.
- ,/ You can touch one of the memory icons at the bottom
of the screen to read image mix frames saved in the built-in memory
(only when recording on or playing back scenes from a memory card).
3 Touch [K] to mix the selected frame with the live video.
COPY
76
Video
To use the Chroma Key function
1 Open the [Select Image] screen of the image mix function (A75).
2 Touch [+] or [-] to select the image you created.
3 Touch [Ð] to open the [Chroma Key] screen.
4 Touch [Green] or [Blue] depending on the characteristics of the
image you want to use and touch [Ï] or [Ð] or drag your finger
along the bottom bar to adjust the chroma key setting as necessary.
5 Touch [Ð] at the top of the screen to open the [Transparency]
screen.
6 Touch [Ï Ð] or [ ] or drag your finger along the bottom bar to adjust
the overall transparency of the image as necessary.
7 Touch [K] to mix your image with live video.
Mixing Your Own Images with Live Video
You can use images you make on your computer for the image mix
(Chroma Key) function. Make sure that the image you want to use
has a blue or green area, which will be replaced by the live video
using Chroma Key mixing. Refer to About the image files for the
Image Mix function (A239) for details about the types of image
files that can be used and where to transfer them.
Blue/Green area that will be replaced
by the live video
Example of an image used for Chroma Key
COPY
Video 77
Decorating Scenes during Playback
Operating modes:
1 From the [ Movies] index screen or gallery, play back the
scene you want to decorate.
2 Touch the screen to display the playback controls.
3 Touch [Ò] to open the decoration screen.
4 Decorate the scene using the tools from the toolbar as explained
in the previous section.
In playback mode, the decorations will not be saved with the original
recording.
NOTES
• Initializing a memory will erase any [Pens and Stamps] drawing canvas
and image files you may have saved. (- ,/ The image mix
frames that come pre-installed in the built-in memory will be restored
after it is initialized.)
• When q > [Autostart Decoration] is set to [i On], the decora-
tion screen will open automatically when you stow the LCD panel with
the LCD screen facing out.
• Animated stamps and captions cannot be used at the same time.
• - ,/ When r> [Rec Media for Movies] is set to [&] (the
built-in memory), you will not be able to select image mix frames saved
on a memory card.
• For AVCHD movies, image mix cannot be selected during playback or
while converting a scene to standard definition (A156; - ,/
only). Select the image mix during playback pause or before starting the
conversion.
• For AVCHD movies, decorations will appear in the thumbnails of scenes
in the [ Movies] index screen and gallery. For MP4 movies, decora-
tions will not appear in thumbnails.
COPY
Video 79
3 Select the rating of the scenes you want to play back.
4 Touch the story’s thumbnail to start the playback.
• The complete story will be played back from the first scene to the
last. When playback ends, the camcorder will return to the gallery.
• During the playback of a story other than [Unsorted] or [Video
Snapshot], touch the screen and then touch [ë] to display the
scene’s category during playback. Touch the screen and then touch
[ë] again to turn the story scene display off.
• Playback controls are the same as when playing back scenes from
the [ Movies] or [ Movies] index screen (A56).
IMPORTANT
• Observe the following precautions while the ACCESS indicator is on or
flashing. Failing to do so may result in permanent data loss.
- Do not open the memory card slot cover.
- Do not disconnect the power source or turn off the camcorder.
- Do not change the camcorder’s operating mode.
NOTES
• If playback of a scene in the gallery is interrupted, you cannot resume
playback at the point it stopped. The story will start over from the begin-
ning the next time you play it back.
[Story Details] > [Select by Rating] > Desired rating >
[ ]K] > [K
COPY
Product specificaties
| Merk: | Canon |
| Categorie: | Camcorders |
| Model: | VIXIA HF M500 |
| Kleur van het product: | Zwart |
| Ingebouwd display: | Ja |
| Gewicht: | 310 g |
| Breedte: | 68 mm |
| Diepte: | 121 mm |
| Hoogte: | 64 mm |
| Capaciteit van de accu/batterij: | - mAh |
| Beeldscherm: | LCD |
| Beeldschermdiagonaal: | 3 " |
| Touchscreen: | Ja |
| Interne opslagcapaciteit: | - GB |
| Maximale capaciteit van de geheugenkaart: | 64 GB |
| Ondersteund audioformaat: | AAC, AC3, MP4 |
| Ondersteunde videoformaten: | AVCHD, MPEG4 |
| USB-connectortype: | Mini-USB A, Mini-USB B |
| Ondersteunde video-modi: | 1080p |
| Totaal aantal megapixels: | 2.37 MP |
| Minimale belichting: | 1.2 Lux |
| Meegeleverde kabels: | HDMI, USB |
| Compatibele geheugenkaarten: | SD, SDHC, SDXC |
| Audiosysteem: | Dolby Digital 2.0 |
| Snelstartgids: | Ja |
| Inclusief AC-adapter: | Ja |
| Aantal USB 2.0-poorten: | 1 |
| Microfoon, line-in ingang: | Ja |
| Brandpuntbereik: | 6.1 - 61 mm |
| Hoofdtelefoonuitgangen: | 1 |
| Formaat analoog signaal: | NTSC |
| Gezichtsdetectie: | Ja |
| Omvang optische sensor: | 1/3 " |
| Beeldstabilisator: | Ja |
| Aansluiting voor netstroomadapter: | Ja |
| Maximale beeldresolutie: | 1920 x 1080 Pixels |
| Type beeldsensor: | CMOS |
| Digitale zoom: | 200 x |
| Optische zoom: | 10 x |
| 35 mm cameralens equivalent: | 43.4 - 436 mm |
| Ingebouwde flitser: | Nee |
| Maximale videoresolutie: | 1920 x 1080 Pixels |
| HD type: | Full HD |
| Ingebouwde microfoon: | Ja |
| Beeldschermresolutie (numeriek): | 230000 Pixels |
| Witbalans: | Auto, Cloudy, Daylight, Fluorescent, Shade, Tungsten |
| 3D: | Nee |
| Videoresoluties: | 1920 x 1080 Pixels |
| Levensduur accu/batterij: | - uur |
| HDMI: | Ja |
| Fotoresolutie(s): | 1920 x 1080 |
| Scene modes: | Beach, Fireworks, Night, Portrait, Snow, Sports, Spotlight, Sunset, Underwater |
| Ingebouwd licht: | Nee |
| Temperatuur bij opslag: | -5 - 45 °C |
| Geheugenslots: | 1 |
| Minimum brandpunt lengte (35mm film equiv): | 43.4 mm |
| Maximale brandpuntafstand (35mm film equiv): | 436 mm |
| Normal focusing bereik: | 1 - ∞ m |
| Scherpstellen: | Automatisch/handmatig |
| Blootstelling type: | Handmatig |
| Maximum aperture number: | 3 |
| Minimum aperture number: | 1.8 |
| Maat filter: | 43 mm |
| S-Video-uitgang: | Nee |
| Camcorder media type: | Geheugenkaart |
| Werkelijk aantal megapixels (Film): | 2.07 MP |
| Werkelijk aantal megapixels (afbeelding): | 2.07 MP |
| Afbeeldings stabilisator type: | Optical Image Stabilization (OIS) |
| Camcorder type: | Handcamcorder |
| PCM digitaal geluid: | 16-bit/48 kHz |
| Sluiter snelheid (video): | 0.0005 s |
| Beeldzoeker: | Niet beschikbaar |
| Styluspen: | Ja |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Batterijtechnologie: | Lithium-Ion (Li-Ion) |
| Externe flits aansluiting: | Ja |
| Afbeeldingsprocessor: | DIGIC DV III |
| Sluiter snelheid (foto): | 0.002 s |
| Capture modes: | FXP, LP, MXP, SP, XP+ |
| Macro focusing bereik: | 0.01 - ∞ m |
