Quick Setup Guide
Read the Product Safety Guide Quick Setup Guide ๏ฌrst, then read this for the correct installation procedure. D01R2A001-00
USA /CAN
Version 0
EN FR
1Unpack the machine and check the components
Remove the protective tape or ๏ฌlm covering the machine and the supplies. The components included in the box may differ depending on your country.
MFC-J4335DW
MFC-J4345DW
MFC-J4535DW
NOTE
โข Save all packing materials and the box in case you must ship your machine.
โข You must purchase the correct interface cable for the interface you want to use.
USB cable
Use a USB 2.0 cable (Type A/B) that is no more than 6 feet (2 meters) long.
Ethernet (Network) cable (MFC-J4535DW only)
Use a straight-through Category 5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX
Fast Ethernet Network.
NOTE
You can adjust the control panel angle
to read the LCD more easily.
NOTE
The first time you install the
ink cartridges, the machine
will use extra ink to fill the
ink delivery tubes. This is a
one-time process that enables
high-quality printing.
Open the ink cartridge
cover.
The latest manuals are available at the Brother support website:
support.brother.com/manuals
Video setup instructions:
support.brother.com/videos
Manuals in Spanish for this model are available at support.brother.com.
Manuales en Espaรฑol para este modelo estรกn disponibles en support.brother.com.
Pull the paper tray
completely out of the
machine.
Fan the paper well and load it
in the tray.
Adjust the paper guides. Slowly push the paper tray
completely into the machine.
Pull out the paper support , a
and unfold the paper support
flap b so that the printed
pages do not fall.
Quickly shake just the
black ink cartridge
horizontally 15 times as
shown, before inserting
it into the machine.
Follow the LCD instructions
to install the ink cartridges.
Close the ink cartridge
cover. The machine will
prepare the ink tube
system for printing.
Follow the LCD instructions to set
the date and time.
After setting the date and time,
you can set the Firmware Update
defaults.
Follow the LCD instructions,
and then press the or [OK] c.
The machine prints the Print
Quality Check Sheet.
Follow the LCD instructions to
check the quality of the four color
blocks on the sheet, and then
start the cleaning procedure.
Follow the LCD instructions
to print the Adjustment Sheet.
The black circle mark is
located in the upper left corner
of the sheet.
Place the Adjustment Sheet
face down on the scanner
glass.
Make sure the black circle
mark is in the upper left corner
of the scanner glass.
Follow the LCD
instructions and
complete adjusting the
alignment.
When finished, remove
the Adjustment Sheet
from the scanner glass.
For more information about paper handling and sizes, see the Online
Userโs Guide at support.brother.com/manuals.
OK Poor
2Load plain Letter paper in the paper tray
4Install the starter ink cartridges
3Connect the
power cord
6Check the print quality 7Adjust the print alignment (recommended)
To adjust the print alignment before using your machine, press or .[Start] c
5Set the date and
time
1
2
* Most of the illustrations in this show the MFC-J4535DW.Quick Setup Guide
Canโt Connect? Check the following:
Wireless network
Wired network
(MFC-J4535DW only)
USB connection
Restart your wireless access point/
router (if possible). If still not successful, go to 14 .
Disconnect the cable. If still not successful, visit support.brother.com
for FAQs and Troubleshooting.
Restart your machine and
computer, and then go to 13 .
Follow the LCD instructions to configure
the machine settings.
โข (MFC-J4535DW only) Configure the tray
setting.
โข Check the software installation
information.
If you are not using your machine as a fax, go
to 13 . For more information on using the fax
feature, see the Online Userโs Guide.
๎MFC-J4535DW
1. Press [Settings]
> > [All Settings]
[Initial Setup] >
[Local Language].
2. Press your language.
3. Press .
๎MFC-J4335DW / MFC-J4345DW
1. Press .Settings
2. Press or to select the a b
following:
a. Select , and then press [Fax]
OK.
b. Select , [Setup Receive]
and then press .OK
c. Select , [Receive Mode]
and then press .OK
d. Select your Receive Mode,
and then press .OK
3. Press .Stop/Exit
๎MFC-J4535DW
1. Press > [Settings]
[All Settings] [Fax] > >
[Setup Receive] >
[Receive Mode].
2. Press your preferred Receive
Mode.
3. Press .
๎MFC-J4335DW / MFC-J4345DW
1. Press .Settings
2. Press or to select the following:a b
a. Select , and then [Initial Setup]
press .OK
b. Select , and then press [Station ID]
OK.
c. Select , and then press .[Fax] OK
3. Enter your fax number (up to 20 digits),
and then press .OK
4. Enter your name (up to 20 characters),
and then press .OK
5. Press .Stop/Exit
๎MFC-J4535DW
1. Press > [Settings]
[All Settings] [Initial Setup] >
> > [Station ID] [Fax].
2. Enter your fax number (up to 20 digits) on
the touchscreen and then press .[OK]
3. Press .[Name]
4. Enter your name (up to 20 characters)
using the touchscreen, and then press
[OK].
5. Press .
Visit setup.brother.com to download and install
Brother software.
Follow the on-screen instructions and prompts.
NOTE
For Wired Network Connection (MFC-J4535DW only) and
USB Connection, locate the correct port (based on the
cable you are using) inside the machine as shown.
Setup Finished
You can now print and scan using your machine.
To check for the latest firmware, visit
support.brother.com/up7.
Find your SSID (Network Name) and Network Key
(Password) on your wireless access point/router
and write them in the table provided below.
SSID (Network Name)
Network Key (Password)
๎MFC-J4335DW / MFC-J4345DW
1. Go to your machine, and press
on the panel.
2. Press to select OK
[Find WiโFi Network]. The
[Enable WLAN?] message
appears on the LCD.
3. Press to select Yes.c
๎MFC-J4535DW
Go to your machine, and press >
[Find WiโFi Network] > [Yes].
Go to 13 to install
software.
SSID: XXXXXXX
Network key: XXXX
If you cannot find this information, ask your network
administrator or wireless access point/router
manufacturer.
If setup is not successful, restart
your Brother machine and your
wireless access point/router, and
repeat 14 .
Important Notice for Network Security:
The default password to manage this machineโs
settings is located on the back of the machine
and marked โ โ. We recommend immediately Pwd
changing the default password to protect your
machine from unauthorized access.
For detailed machine information and product specifications, see the Online User's Guide at support.brother.com/manuals.
ยฉ 2020 Brother Industries, Ltd. All rights reserved.
Store your name and fax number so the machine prints it on all outgoing fax pages. For more
information, see Enter Text on Your Brother Machine Online Userโs Guide in the .
14 Manual wireless setup
If the wireless setup is not successful, try to set up the connection manually.
13 Connect your computer or mobile device to your machine
Follow these steps to complete the setup using one of the connection types available on your machine.
11 Select the correct Receive Mode
If you are not using your machine as a fax, go to 13 .12 Set your Station ID
If you are not using your machine as a fax, go to 13 .
9Select your language (if needed) 10 Connect the
telephone line cord
8Machine settings
setup.brother.com
Select the SSID (Network
Name) for your access point/
router and enter the Network Key
(Password).
When the wireless setup is
successful, the LCD displays
[Connected].
๎MFC-J4335DW / MFC-J4345DW
1. Press .Settings
2. Press or to select the a b
following:
a. Select , [Initial Setup]
and then press .OK
b. Select , [Local Language]
and then press .OK
c. Select your language, and then
press .OK
3. Press .Stop/Exit
