INSTALLATION & OPERATION MANUAL
EINBAU & BEDIENUNGSANLEITUNG
1- / 4-CHANNEL 24 V POWER AMPLIFIERS
AT101 AT401 I
– –2
Thank you for purchasing this AXTON ampliîšżer!
To maximize the performance of this ampliîšżer and your complete truck audio system
installation, we recommend you acquaint yourself thoroughly with all technical features
and controlling options of this AXTON ampliîšżer. Please read this manual carefully, before
attempting the installation.
If, after reading this manual, you still have questions regarding functions or the installation of
the ampliîšżer, we recommend that you consult your dealer.
SAFETY INSTRUCTIONS
n Do not turn on any function which may distract you while driving your truck.
Functions requiring sustained attention must only be used when the truck is at a
complete standstill. Make sure to always stop your truck in a safe place before
operating these functions. There are risks of causing an accident.
n Keep the volume at a low level to be able to hear exterior noises while driving
the truck. There are risks of causing an accident.
n Do not open the ampliîšżer or undertake any modiîšżcation of the product. There
is a risk of accident, îšżre or electric shock.
n Only use this ampliîšżer with 24V mobile applications. Any use other than for this
product intended are may lead to îšżre, electric shock or injury.
n Use correct amperage fuses. There are risks of îšżre or electrocution.
n Do not obstruct radiators and/or vents. Internal overheating may occur and cause
a îšżre.
n Ensure all connections are properly made. Check the section of cable and the
type of cable if it does not correspond with the use. There is a risk of îšżre, injury and/
or damage to the product.
n Do not use screw nuts or fasteners part of the steering or braking systems
for ground connection. The fasteners and nuts used for the brake and steering
systems (or any other security system) as well as various tanks must never be used
for grounding. Use of these parts as ground may deactivate the truck’s control system
and cause a îšżre or other technical problem.
n Keep all small objects which could be swallowed, such as the fasteners and
screws, out of the reach of children. Swallowing such objects may cause serious
injuries. In the event of swallowing any of these objects, immediately seek medical
advice.
n Before starting the installation, disconnect the negative terminal of the battery
to avoid any risk of injury, îšżre or damage to the equipment.
– –4
AT101 CONNECTIONS + CONTROLS
1 SIGNAL INPUTS R / L
Low-level stereo RCA signal or high-level speaker signal input terminal for connection to
head-unit.
2 INPUT MODE SELECTION
Switch to select the proper input sensitivity range: RCA signal input = Low. Speaker
signal input = Hi.
3 AUTO-TURN-ON MODE
Slide switch to select the auto-turn-on function: REM by remote wire, VOX to switch on
by music signal or DC by DC offset signal of the head units integrated ampliîšżer.
4 INPUT SENSITIVITY CONTROL
Input gain potentiometer “SENS” to match the output voltage of the head unit to the
amplier’s input.
5 SUBSONIC HIGHPASS FREQUENCY CONTROL
Control potentiometer to adjust the subsonic highpass îšżltering frequency point of the
subwoofer output channel.
6 BASS BOOST 0dB to + 18dB
Turn clockwise to get up to + 18dB bass boost or counterclockwise for no boost with a
45 Hz center frequency of the ampliîšżed output signal.
7 LOWPASS FREQUENCY CONTROL
Control potentiometer to adjust the lowpass îšżltering frequency point of the subwoofer
output channel.
8 BASS LEVEL REMOTE CONTROL INPUT
Input terminal to connect the external bass level remote to the ampliîšżer.
9 INPUT MODE SELECTION
Switch to select the proper input sensitivity range: RCA signal input = Low. Speaker
signal input = Hi.
10 POWER LED
LED to show the operating status of the ampliîšżer by blue/red illumination. Blue is
normal working state, red is protect mode of ampliîšżer.
11 SPEAKER OUTPUT TERMINAL
Output terminal to connect the speakers to the ampliîšżer.
12 “+24 V” POWER INPUT TERMINAL
Terminal to connect the ampliîšżer to the positive +24 V pole of the truck battery.
13 “REM” INPUT TERMINAL
Terminal to connect the ampliîšżer to the automatic (remote) turn-on / turn-off lead of the
head unit. By using the REM terminal, you need to switch the Auto-turn-On mode
3 to
the “REM” position.
14 “GND” POWER INPUT TERMINAL
Terminal to connect the ampliîšżer to the chassis ground or negative pole of the truck
battery.
