Pagina 1/4
Haze 1200
Please read the manual before using the product
USER´S
MANUAL
7
Haze 1200
Address Setup:
Use the DIP switch on the rear panel to set the start address. The base/start address is
defined as a first channel, where responsive to the device. Check if no overlapping channels
are used!
Example addressing:
Clean procedure
Run clean procedure in a well-ventilated area
• Remove fog liquid from the tank, add cleaning solution to tank
• Switch fazer machine and wait until it is warm up
• Press the button to switch the liquid pumped through the machine
• Perform the above operation until the tank is empty
• Fill the tank with liquid smoke
Specifications
Power supply: 220-240V AC/50Hz
Heating element: 1200 watts
Heat up time: 3 minutes
Smoke production: ca. 150m³/minute
Tank capacity: 1,2 liters
Dims: 535 x 210 x 230mm
Weight: 6,1 kg
USER´S
MANUAL
Haze 1200
1 6
recommended to produce haze with small pauses in between so that the temperature is
maintained and the thermostat doesn’t switch off.
Make sure that there is always enough liquid contained in the tank. Use of the fazer machine
without liquid can permanently damage the unit. Once the fazer machine generates little
haze or pump generates another 'rattling' sound i turn off the unit direct. Check the fluid
level and fill the tank when it is empty, check the hose and filter blockages and restore it.
Plug in the unit and check if the problem is resolved. If problem persists, switch unit direct off
to prevent further damage and contact your dealer.
Timer remote control
Connect the remote control to the connector on the back of the fogger.
After some warm-up time, the device is ready for use; the LED will light up on the remote.
During use, it may happen that the machine stops, in this case the LED will go out, indicating
that the machine is warming up.
Timer function:
Press the yellow button and set the interval, duration and volume controls to the desired
level.
Interval: time between the smoke moments (10-200 seconds)
Volume: amount of smoke (0-100%)
Duration: duration of the smoking time
Continuous function:
Press the red button and set the volume to the desired level. The machine will continuously
produce an amount of smoke. It may be that the machine in between have to warm up,
during this period no smoke is produced. How many times this is done depends on the
amount of smoke.
Manual Mode:
Press the green button to produce 100% smoke immediately; this button overrides all
previous settings.
DMX control (DIP)
Connect the device directly to a DMX controller or a DMX loop with multiple DMX effects.
The machine has a 3- pin XLR connector for DMX connection.
Warning:
- The fazer machine must be placed at least 100 cm away from inflammable materials such
as curtains, books, etc. Make sure that the housing cannot be touched by accident.
- Use only water-based fluid recommended by your dealer.
- Poor liquid caused permanent damage, bad effect, clogging, spitting of unevaporated
liquid etc.
- Never add flammable fluids (oil, gas, perfume) to the fog liquid.
- Always keep enough liquid in the tank.
Use of the device without liquid will cause damage to the pump and heater.
- Do not obstruct the openings on top of the case to guarantee good ventilation.
- Don’t put any objects on the Hazer machine.
- For indoor use only.
- During installation, nobody should stand beneath the mounting area.
- Prior to the first use, have the unit checked by a qualified person.
- The unit contains voltage carrying parts. DO NOT open the haze machine
- Never plug or unplug the unit with wet hands.
- If the plug and/or mains lead are damaged, they need to be repaired by a qualified
technician.
- If the unit is damaged to an extent that you can see internal parts, do not plug the unit into
a mains outlet. It needs to be repaired by a qualified technician.
- Only connect this unit to an earthed mains outlet of 220-240Vac/50Hz .
- Always unplug the unit during a thunderstorm or when it is not in use.
- If the unit has not been used for a longer period of time, condensation can occur inside the
housing. Please let the unit reach room temperature prior to use.
- When you unplug the unit from the mains always pull the plug, never the lead.
- In order to prevent dropping of the unit, a safety fastening needs to be installed. This can
be a solid chain, a steel cable, etc. which has to be fastened separately from the mounting
bracket.
- The supplied bracket is the main fixing and must be used to solidly mount the light effect.
- In order to avoid accidents in public premises, the local legal requirements and safety
regulations/warnings must be fulfilled.
- Keep out of the reach of children.
Location
Select a location where it is easy to fill the tank. It is also possible to hang the unit by means
of the supplied holder and fixing screws.
Installation and Use
Unpack the fazer machine. Do not connect yet the net cable. Connect the remote control
to the connector on the back of the fogger. Fill the fluid tank by means of a funnel. Plug the
unit into a mains outlet. Thus the heating element is automatically switched on. Depending
on the room temperature, it takes about 4 minutes until the working temperature is reached.
Then the thermostat is clicking and the LED on the manual control lights up. Push the switch
once and the fazer machine will produce a nice thick fog. Once the fazer machine has
reached its working temperature (the LED is lit) the fazer machine can produce fog
continuously. After this period of time, the fog generator is cooled so much down that the
thermostat switches off. Wait a while until the working temperature is reached again. It is
Haze 1200
Por favor, lea el manual antes de usar el producto
MANUAL
DE USUARIO
7
Haze 1200
Configuración de dirección:
Use el interruptor DIP en el panel posterior para establecer la dirección de inicio. La
dirección base/de inicio se define como un primer canal, donde responde al dispositivo.
¡Compruebe si no se utilizan canales superpuestos!
Ejemplo de direccionamiento:
Procedimiento de limpieza
Ejecute el procedimiento de limpieza en un área bien ventilada
• Retire el lÃquido de niebla del tanque, agregue solución de limpieza al tanque
• Cambie la máquina fazer y espere hasta que se caliente
• Presione el botón para cambiar el lÃquido bombeado a través de la máquina
• Realizar la operación anterior hasta vaciar el depósito
• Llene el tanque con humo lÃquido
Especificaciones
Fuente de alimentación: 220-240V CA/50Hz
Elemento de calefacción: 1200 vatios
Tiempo de calentamiento: 3 minutos
Producción de humo: ca. 150m³/minuto
Capacidad del tanque: 1,2 litros
Dimensiones: 535x210x230mm
Peso: 6,1 kg
Dirección
DMX
Dipswitch
