MAGNAVIEW BINOCULARS
INSTRUCTIONS
#830/834 #832/838
Parts
01. Ocular Lens
02. Center Focus
03. Rubber Eyecup
04. Diopter
05. Strap Attachment
06. Objective Lens
© 2019 Alpen Optics
1010 S 48th Street, Springdale, AR 72762
explorescienticusa.com | alpenoptics.com | 866.252.3811 | All rights reserved. Made in China.
CONTENTS AND COLORS MAY VARY
SUN HAZARD
— Never look directly at the sun with this device.
WARNING:
01
02
05
06
04
03
01
05
06
02
04
03
Eyecup Adjustment
Your ALPEN binocular is fitted with eyecups which can be rolled or twisted up or down
(depending on your model) to optimize the view for your eyes and to exclude extraneous
light. If you are not wearing eyeglasses or sunglasses, keep the eyecups fully extended
(“up” position). If you are wearing glasses, roll down the eyecups or twist them to the down
position. This will bring your eyes closer to the binocular’s eyepiece (ocular) lens to ensure
you can see the entire image (full field of view with no “cutoff” or “tunnel vision”).
IPD (Interpupillary Distance) Adjustment
The distance or spacing between the center of the pupils, called “interpupillary distance”
(IPD) varies from person to person. To adjust the binocular to match your eyes, follow these
simple steps:
1. Hold your binocular in the normal viewing position. Grasp each barrel firmly.
2. Move the barrels closer together or further apart until you see a single circular field
(don’t worry about focus yet).
3. Always re-set your binocular to this position before using it.
Twisted Eyecup Rolled Eyecup
Diopter Adjustment and Focusing
1. Adjust eyecups interpupillary distance as described in the previous sections.
2. Set the diopter adjustment ring to zero and view a distant object.
3. Keep both eyes open at all times.
4. Using a lens cover or your hand, cover the objective (front) lens of the same side of the
binocular that has the diopter adjustment ring. This is usually the right side.
5. Using the center focus wheel, focus on a distant object with fine detail (e.g., brick wall,
tree branches, etc.) until it appears as sharp as possible.
6. Uncover the objective lens on the diopter side, cover the other objective lens, the left
side, then view the same object.
7. Using the diopter adjustment ring, move the dipoter adjustment marker to the “ ” or “ ” + -
till you reach focus.
Caution should be used as over turning or forcing the diopter ring can cause damage or
cause the eyepiece to break away from the chassis.
8. Your binocular should now be adjusted for your eyesight. Focusing for any distance can
now be done simply by turning the center focus wheel. Make a note of your diopter
setting for future reference.
Neckstrap Attachment
To securely attach your binocular to the binocular strap:
1. Thread the end of the strap from the bottom up through the strap attachment loop.
2. Hold the buckle and thread the end of the strap inside the buckle.
3. Adjust the overall length and pull the strap webbing tight so it is secure within the buckle.
Waterproof / Fogproof Models
ALPEN binoculars are designed and built utilizing the latest waterproof and fogproof
technology (this will be noted on the product packaging). Waterproof models are O-ring
sealed for complete moisture protection. Fogproof protection is achieved from dry nitrogen
purging that removes all internal moisture.
Diopter
Adjustment
Ring
Diopter
Adjustment
Marker
Care and Cleaning
Your BRESSER binocular will provide years of trouble-free service if it receives the normal
care you would give any fine optical instrument.
• Do not expose non-waterproof models to heavy rain or other excessive moisture.
• If your binocular has roll-down, flexible eyecups, store it with the eyecups up. This avoids
excessive stress and wear on the eyecups in the down position.
• Avoid sharp impacts. Use the included neckstrap to avoid accidentally dropping the
binoculars to prevent mis-alignment of the optics.
• When not using them, store your binoculars in the provided case in a cool, dry place.
• Avoid storing the binoculars in hot places, such as the passenger compartment of a
vehicle
on a hot day. The high temperature could adversely affect the lubricants and sealants.
Never leave the binocular where direct sunlight can enter either the objective or the
eyepiece lens. Damage may result from the concentration (burning glass effect) of the
sun’s rays.
• All moving parts of the binocular are permanently lubricated. Do not try to lubricate them.
To Clean Your Binoculars Lenses
1. Blow away any dust or debris on the lens (or use a soft lens brush).
2. To remove fingerprints or other smears, clean with a soft cotton cloth rubbing in a circular
motion. A “microfiber”cleaning cloth (available from camera or computer retailers) is ideal
for the routine cleaning of your optics.
3. For a more thorough cleaning, photographic lens tissue and photographic-type lens
cleaning fluid or isopropyl alcohol may be used. Always apply the fluid to the cleaning
cloth – never directly on the lens.
For assistance or to return an item, contact Alpen at 866.252.3811
or visit for return procedures. explorescientific.supportsync.com
Drawing may not match binocular model.
